Installation and Operation Guide | DGS Modbus
Service
Read out of refrigerant (Gas) for the DGS is used for
Value according to "Danfoss standard list".
Gas Full scale in ppm
Hours since last calibration
Status of the sensor warm up period
0 =Ready
1 = Warming Up
When cleared, clears calibration due alarm and resets the
burning hours parameter
0 = Calibration valid
1 = Calibration due
Failsafe operation of the Relay
0 = Not failsafe
1 = Failsafe
Enables Manual control of Relays.
Automatically falls back to Off after 10 min.
Status of the high alarm relay
0 = No alarm signal
1 = alarm signal
Status of the buzzer
0 = inactive
1 = active
Status of the red LED
0 = off
1 = on
Status of the green LED
0 = off
1 = on
Alarms
Limit alarm
0 = Alarm not active
1 = Alarm, gas limit exceeded
Sensor saturated
0 = OK
1 = Fault. Out of range under test
Sensor out
0 = OK, sensor in place
1 = Fault, Sensor out or removed
Calibrate sensor
0 = OP, Sensor not due for calibration
1 = Warning, Due for calibration
Warning limit alarm
0 = OK, Gas level below warning level
1 = Warning, Gas level above warning level and delay expired
20 | RS8HJ102 |
1 42 N
0 32000 0
0 32000 0
0 1 0
0 1 0
0 1 0
0 1 0
0 1 0
0 1 0
0 1 0
0 1 0
0 1 0
0 1 0
0 1 0
0 1 0
0 1 0
- Refrigerant
ppm Fullscale ppm
hours Burning hours
- Startup flag
- Reset cal
- Relay failsafe
- Maunal Control
- Alarm Relay
- Sounder
- Red LED
- Green LED
- Limit alarm
- Sensor saturated
- Sensor out
- Calibrate sensor
- Warning limit al.
