Unitech MS840P Quick Start Manual

MS840P
Quick Start Guide
The Unitech MS840P Wireless Scanner
Installation Instructions & Popular Configuration Settings
Scan Dongle
Step 3:
Scan the barcode on the USB Dongle.
SETTINGS AND CONFIGURATION
The following section covers the most common
configuration settings for your MS840P scanner.
For additional configuration options please visit
unitechscanners.com/MS840P and select the
"Download" tab. You will find the User's Manual and a
variety of other resources.
SETUP AND INSTALLATION
The following steps will walk you through the installation process.
Step 4: Connect dongle to host
Plug the USB Dongle into a free USB port of a host computer. The
MS840P is now ready to use.
Flash Mode
Flash Mode
Scan here to switch to Flash Mode from the default Trigger Mode. In
Flash mode, the MS840P will function automatically. It will scan at a
set interval.
Power On
Step 1:
Switch the power button to the on position.
Test & Finish
Open a word processing program such as Microsoft Word or
Notepad on your host. Now scan the following barcode:
If the word "Unitech" appears on the screen you have succesfully
installed your scanner. Congratulations!
Trigger Mode
Trigger Mode
Scan here to switch back to Trigger Mode. In Trigger Mode, the
MS840P will scan only when the scanner button is pressed.
ChargE
Step 2:
Plug the power supply cable into the bottom of the MS840P and into
an electrical outlet. Charge for at least 5 hours.
Tab Mode
Tab Mode
You may wish to set your scanner to Tab Mode. In this mode, data
will tab over to the next column as you scan instead of jumping to the
next line. Scan the top barcode then the bottom barcode to switch to
Tab Mode from the default Enter Mode.
