LORUS nx04 Instruction Manual

NRENX04 05-00
I M
NSTRUCTION ANUAL
CAL. NX04 (RD9 SERIES)
C H A R A C T E R I S T I C S
1 . T i m e / c a l e n d a r d i s p l a y :
• A n a l o g u e d i s p l a y : H o u r , m i n u t e s a n d
seconds.
• D i g i t a l d i s p l a y : Hour, minutes, seconds,
date and day of the week.
• F u l l y a u t o m a t i c c a l e n d a r : C a l e n d a r
adjusts automatically for odd and even months
including February of leap years from the
year 2000 to the end of 2050.
• T i m e i n d i c a t i o n : Changeover between
12- and 24-hour indications is possible.
2 . World time: The time of 27 cities in different
t i m e z o n e s t h r o u g h o u t t h e w o r l d c a n b e
displayed together with the time difference
between the selected city and your area.
• D a y l i g h t s a v i n g t i m e s e t t i n g
3 . S t o p w a t c h : M e a s u r e s u p t o 2 3 h o u r s , 5 9
m i n u t e s a n d 5 9 s e c o n d s i n 1 / 1 0 0 s e c o n d
increments for the first hour and in 1-second
increments thereafter.
4 . R e g u l a r a l a r m : The regular alarm can be
set to ring on a 24-hour basis.
5 . S i n g l e - t i m e a l a r m : The single-time alarm
can be set to ring only once at the designated
time. As it rings, it is automatically disengaged.
6 . D e m o n s t r a t i o n f u n c t i o n : Each mode is
displayed for 2 seconds in order.
7 . Illuminating light: The light evenly illuminates
the display for easy viewing in the dark.
C R O W N / B U T T O N S A N D D I S P L A Y S
D a t e Day
B C
M i n u t e
Hour
hand
hand
C r o w n
Second
hand A D
Hour Minutes
Seconds
The selection of the mode can be made in the
following order with each press of button "A".
A
T I M E / C A L E N D A R W O R L D T I M E
m o d e m o d e
A A
A
R E G U L A R A L A R M S T O P W A T C H
m o d e m o d e
N o t e : I f t h e w a t c h i s l e f t u n t o u c h e d i n t h e
W O R L D T I M E m o d e , i t w i l l a u t o m a t i -
c a l l y r e t u r n t o t h e T I M E / C A L E N D A R
mode in 1 to 2 minutes.
By pressing button "C" in the TIME/CALENDAR
mode, the SINGLE-TIME ALARM mode is shown.
C
T I M E / C A L E N D A R S I N G L E - T I M E
m o d e A L A R M m o d e
W i t h e a c h p r e s s o f b u t t o n " D " i n t h e T I M E /
CALENDAR mode, the display changes over in
the following order.
D
T i m e / c a l e n d a r C a l e n d a r
d i s p l a y d i s p l a y
D
D
B l a n k d i s p l a y
HOW TO SET THE TIME/CALENDAR
• Before setting the analogue time, be sure to
set the digital time.
D I G I T A L T I M E / C A L E N D A R S E T T I N G
• Once the time/calendar of your area is set in
t h e T I M E / C A L E N D A R m o d e , t h e t i m e s o f
t h e 2 7 c i t i e s c o v e r e d i n t h e W O R L D T I M E
mode will be set automatically.
B
C
Date
Day
A D
Hour Seconds
Minutes
1. Press button "A" to show the TIME/CALENDAR
mode.
2 . Press button "A" for 2 to 3 seconds to show
the TIME/CALENDAR SETTING display.
* T h e w o r l d m a p a n d a c i t y m a r k a p p e a r ,
and the part of the map representing the
city flashes.
City mark
3. Selection of the digits/segments to be adjusted
(flashing) is made in the following order by
pressing button "C".
C ity S eco n d s Minutes Hour
→ → →
1 2 - / 2 4 - h o u r D a t e Month Year
indication
4 . Press button "D" to set the flashing digits/
segments.
* Before setting the time/calendar, be sure
to select the city representing your area.
(For the city marks and cities they represent,
see "Time differences")
* One digit is advanced with each press of
button "D". Digits except seconds and 12-
/24-hour indication move quickly by keeping
button "D" pressed.
5. A f t e r a l l t h e a d j u s t m e n t s a r e c o m p l e t e d ,
p r e s s b u t t o n " A " t o r e t u r n t o t h e T I M E /
CALENDAR mode.
S e c o n d s s e t t i n g
When the seconds digits are flashing, press
button "D" in accordance with a time signal.
The seconds are reset to "00" and start immediately.
W h e n t h e s e c o n d s c o u n t a n y n u m b e r f r o m
" 3 0 " t o " 5 9 " a n d b u t t o n " D " i s p r e s s e d , o n e
minute is added and the seconds are immediately
reset to "00".
1 2 - / 2 4 - h o u r i n d i c a t i o n s e t t i n g
Changeover between 12- and 24-hour indications
is made alternately with each press of button
"D".
N o t e s :
1. When setting the hour digits in the 12-hour
i n d i c a t i o n , c h e c k t h a t A M / P M i s p r o p e r l y
set. Only "PM" mark is displayed and there
is no indication for the AM setting. In the
24-hour indication, "24" is displayed.
2. O n c e t h e y e a r , m o n t h a n d d a t e h a v e b e e n
set, the day of the week is set automatically.
3. If the watch is left untouched in the TIME/
CALENDAR SETTING display with the digits/
segments flashing, it will automatically return
t o t h e T I M E / C A L E N D A R m o d e i n 1 t o 2
m i n u t e s .
A N A L O G U E T I M E S E T T I N G
Second hand
M i n u t e
hand
Hour
hand
a b
C r o w n
a : Normal position
b : Extended position
1. Pull out the crown when the second hand is
at the 12 o'clock position.
2. Turn the crown to set the hour and minute
hands to the time shown in the digital display.
* When setting the minute hand, advance it 4
to 5 minutes ahead of the desired time and
then turn it back to the exact minute.
3 . Push the crown back in to the normal position
w h e n t h e s e c o n d d i g i t s c o u n t " 0 0 " i n t h e
digital display.
A c o n v e n i e n t w a y o f u s i n g t h e T I M E /
C A L E N D A R m o d e
• When you travel around different time zones,
the time and calendar of the place you visit
can easily be shown in the TIME/CALENDAR
mode.
1 . P r e s s b u t t o n " A " f o r 2 t o 3 s e c o n d s i n t h e
TIME/CALENDAR mode to show the TIME/
CALENDAR SETTING display.
2. Press "D" repeatedly to select the city representing
the place you are visiting.
3 . P r e s s b u t t o n " A " t o r e t u r n t o t h e T I M E /
CALENDAR mode, and then, adjust the hands
to the digital time.
H O W T O U S E T H E W O R L D T I M E
• The times of 27 cities in different time zones
throughout the world can be displayed together
with the time difference between the selected
city and your area.
• D a y l i g h t s a v i n g t i m e c a n b e s e t f o r e a c h
city.
N o t e : To display the times of the cities cov-
ered in the WORLD TIME mode prop-
e r l y , i t i s n e c e s s a r y t o s e l e c t t h e c i t y
representing your area and set the cor-
rect time in the TIME/CALENDAR mode.
(See " HOW TO SET THE TIME/CAL-
ENDAR")
Time Daylight saving
time mark
difference
B C
City mark
Selected
a r e a
( f l a s h i n g )
A D
Time of the selected area
1. Press button "A" to show the WORLD TIME
mode.
2. Press button "C" or "D" to select the desired
city.
* With each press of button "C" and "D", the
flashing segments of the map move rightward
and leftward, respectively.
* I f a s e l e c t e d t i m e z o n e h a s n o c i t y m a r k
s e t f o r t h e w a t c h , " – – – – – – " w i l l b e
displayed in place of a city mark.
D i s p l a y i n g t h e d a y l i g h t s a v i n g t i m e
1 . Press button "C" or "D" to select the desired
city.
2 . Press button "A" for 2 to 3 seconds to show
the DAYLIGHT SAVING TIME SETTING display.
* A flashing "DST" mark appears.
3 . With each press of button "D", the standard
time and daylight saving time of the selected
city are alternately shown.
4 . P r e s s b u t t o n " A " t o r e t u r n t o t h e W O R L D
TIME mode.
N o t e s :
1. When the daylight saving time is set for the
city selected in the TIME/CALENDAR mode,
the current time is advanced by one hour.
2. If the watch is left untouched in the DAYLIGHT
S A V I N G T I M E S E T T I N G d i s p l a y w i t h t h e
d a y l i g h t s a v i n g t i m e m a r k f l a s h i n g , i t w i l l
a u t o m a t i c a l l y r e t u r n t o t h e W O R L D T I M E
mode in 1 to 2 minutes.
T i m e d i f f e r e n c e s
UTC = coordinated universal time
UTC ± (hours)
UTC ± (hours)
C i t y C i t y
[ daylight ]
m a r k n a m e [standard time]
saving time
(–11)* –
– 1 1 :0 0 – 1 0:0 0
H N L Honolulu – 1 0 :0 0 – 0 9:0 0
A N C Anchorage – 0 9 :0 0 – 0 8:0 0
LAX Los Angeles
– 0 8 :0 0 – 0 7:0 0
DEN Denver – 0 7 :0 0 – 0 6:0 0
C H I C h i c a g o – 0 6 :0 0 – 0 5:0 0
N Y C New York
– 0 5 :0 0 – 0 4:0 0
C C S C a r a c a s – 0 4 :0 0 – 0 3:0 0
R I O Rio de Janeiro – 0 3 :0 0 – 0 2:0 0
(–2) * –
– 0 2 :0 0 – 0 1:0 0
*
(–1) – – 0 1 :0 0 + 0 0:0 0
UTC – + 0 0 :0 0 –
L O N L o n d o n
+ 0 0 :0 0 + 0 1:0 0
PAR Paris + 0 1 :0 0 + 0 2:0 0
CAI Cairo + 0 2 :0 0 + 0 3:0 0
J R S Jerusalem
+ 0 2 :0 0 + 0 3:0 0
J ED Jeddah + 0 3 :0 0 + 0 4:0 0
THR T e h r a n + 0 3 :3 0 + 0 4:3 0
D X B D u b a i
+ 0 4 :0 0 + 0 5:0 0
K B L Kabul + 0 4 :3 0 + 0 5:3 0
K H I Karachi + 0 5 :0 0 + 0 6:0 0
DEL Delhi
+ 0 5 :3 0 + 0 6:3 0
D A C Dhaka + 0 6 :0 0 + 0 7:0 0
R G N Y a n g o n + 0 6 :3 0 + 0 7:3 0
B K K B a n g k o k
+ 0 7 :0 0 + 0 8:0 0
HKG Hong Kong + 0 8 :0 0 + 0 9:0 0
TYO T o k y o
+ 0 9 :0 0 + 1 0:0 0
ADL A d e l a i d e
+ 0 9 :3 0 + 1 0:3 0
S Y D Sydney + 1 0 :0 0 + 1 1:0 0
N O U Nouméa
+ 1 1 :0 0 + 1 2:0 0
W L G W e l l i n g t o n
+ 1 2 :0 0 + 1 3:0 0
* For the time zones with "*" mark in the table
above, "– – – – – –" will be displayed in place
of a city mark.
