ironLogic Z-5R NET Operation Instructions page 3

This mode blocks all simple keys. Use of simple keys does not open the door and induces a series of short
signals. Exit from locking mode to general mode is performed using locking key (up to the series of short
signals) by short swipe of a master key (series of short signals).
*In case of supply voltage failure set before Locking mode is saved after switching-on of voltage.
8. Включение режима "Ассерт" ( 5 кМ)
Accept mode is used for the record of all swiped to contactor keys DS1990A.
In this mode the key swiped to the contactor induces door release and simultaneous record into the
contactor memory. The mode is used to recover users base without collection of clients keys.
To enter into the mode use the key.
Swipe the master key to the connector five times for a short period of time. In the moment of each swipe
connector gives signals confirming identification of all master keys and their number will correspond to the
number of swipes. In the moment of fifth swipe the connector will give five signals and one long signal
confirming entry to Accept mode. To exit from the mode swipe the master key. The signal confirming such
exit is a series of short signals.
* In case of supply voltage failure set before Accept mode is saved after switching-on of voltage.
After each swipe of the key to be deleted the controller gives short confirming signal. If the key is not
recorded in the memory, the controller gives two short signals. Exit from the mode occurs automatically in
16 seconds after the last swipe or with the swipe of the master key. Controller informs about the exit from
the mode with a series of short signals.
5. Deleting of the controller memory ( 3 к М, 1 дМ).
Swipe the key to the controller for three time for a short period of time (short swipes). At the moment of
the first swipe the controller will give a short signal confirming master key identification. At the moment of
the second swipe the controller will give two short signals confirming the second swipe of the master key in
programming mode. At the moment of the third swipe controller will give three short signals confirming the
third swipe of the master key, and not more than for 6 seconds swipe and hold the master key to the
controller (long swipe). At the moment of the forth swipe the controller gives four short signals and in 6
seconds a series of short signals confirming deleting of the controller memory and exit from programming
mode. After that master key should be removed. Entry to programming mode occurs automatically when
power is on.
* At the moment of deleting of the base using master key the programmed release time is not deleted.
3. Adding of master keys ( 1 к М, 1 дМ)
Swipe the master key to the controller for a short period of time (short swipe). In the moment of such
swipe the controller will give short signal confirming identification of the master key, hold the card not
longer than for 6 seconds at the reader (long swipe). In the moment of swipe the controller will give two
short signals indicating the second swipe of the master key in programming mode and in 6 seconds one
signal indicating entry to the mode of master keys adding. After that remove the master key. To add new
master keys swipe them in turn to the controller with an interval not longer than 16 seconds. After each
swipe of a new key the controller gives short confirming signal. If the key is already recorded in the
memory as a master key signals will not be given. Exit from the mode of master keys adding is performed
automatically in 16 seconds after the last swipe. Controller confirms exit from the mode by a series of 5
short signals.
4. Deleting of simple keys using master key ( 2 к М, 1 дМ)
Swipe the master key to the controller for a short period of time (short swipe). In the moment of the first
swipe controller will give a short signal confirming identification of the master key. In the moment of the
second swipe the controller gives two short signals indicating the second swipe of the master key in
programming mode, hold the master key not longer than for 6 seconds at the controller (long swipe). In the
moment of the third swipe, the controller will give three short signals and in 6 seconds one signal indicating
entry into the mode of simple keys deleting. To delete keys swipe them in turn to the controller with an
interval between swipes not longer than 16 seconds.
6. Release time programming (4 кМ)
Swipe master key to the controller four times for a short period of time. В At the moment of each swipe
controller gives signals confirming identification of the master key and their number will correspond to the
number of swipes. At the moment of the forth swipe controller gives four signals and enters in the mode of
door release programming. Within 6 seconds from the last swipe lock the door button for a period required
for release. After the button release controller will give a signal and record the time in the base.
*If release button cannot be set, contacts No 4 and No3 (earth) close on each other.
7. Locking mode (1 д Б )
In the locking mode the passage is open using locking keys and closed for simple keys.
Locking mode is set using locking key (using locking keys - p.2).
Locking key is used:
As a simple access key in general operating mode (i.e. access is opened for all simple and locking keys
recorded in the base)
To enter into locking mode (in this mode only locking keys can open the door).
To enter into common mode
Locking key opens by release.
To enter into locking mode hold locking key at controller for 3 seconds till the long continuous signal,
confirming entry into locking mode.
