Reely Mercury VR V2.0 Instruction Manual

Operating Instructions
Mercury VR Drone V2.0
Item No. 1602783
* Please read this instruction manual before take off.
1
WHAT'S IN THE BOX
14+
Warnings for safe use of the Mercury VR drone
AGE
• Do not turn on the controller unless drone has been turned on first.
• Keep hands, hair and loose clothing away from spinning blades.
• Turn off controller and the drone when not in use.
• Parental guidance is recommended.
• Do not submerge into water. This could damage electronic assemblies.
• Follow operating instructions exactly.
• Not intended for children under 14 years old.
• Replace any damaged or broken parts before attempting to fly.
• Do not drop the drone by suddenly reducing the throttle. This could lead
to severe damage.
• The drone's range will also be affected if the battery is not fully charged.
• Do not touch the motors after flying. They can become hot.
The Mercury VR drone is equipped with a rechargeable 7.4V LiPo
battery. Please pay attention to the following cautions for safe use:
• Do not dispose of battery into fire or heat.
• Do not use or leave battery near a heat source, such as fire or a heater.
• Do not strike battery or throw it against a hard surface
• Do not pierce battery.
• Do not disassemble or after battery.
• Turn off power switch & disconnect the battery connector
after use.
• Recycle used batteries.
Mercury VR Drone
Smartphone Clip
7.4V / 600mAh Transmitter
Screwdriver
USB Balance Charger extra Blades
Li-Po battery
2
PRODUCT DIAGRAM
Battery Requirements for Transmitter: Head Light
Requires: 6 x 1.5V AA size batteries
(not included)
Requirements for USB Charge Cord:
USB Output Jack (not included)
Battery Cautions:
• Parental guidance is recommended
when installing batteries.
• Do not power controller by mixing
different types of batteries, or old and
new batteries.
• Use only batteries of the same or
equivalent type as those recommended.
Do not touch the spinning blades
or fly over another person's head. Adult
supervision is required.
Antenna
Power Indicator
Left Stick
On/Off Switch
Light/Speed Control
Headless
* Push the 'Light/Speed control' button to the left to turn on/off the LED lights or right to change the fly speed. It's slow
as default, push the button for FAST with two beeps and EXPERT for three beeps.
GET READY TO FLY
Wonderlen VR Goggle
1
+
14 AGE
HINT: Please replace the batteries with new
* Please read this instruction manual before take off.
1
Instruction Manual ones when the power light keeps flashing in use.
Propeller Propeller Guard
Press the battery case lock & slide to
Camera
open the battery case, take out the
battery for recharging.
Camera Socket
Battery Case Lock
ON/OFF Switch
LED
CAUTION: Changes or modifications
NEVER leave the Li-Po battery unattended when charging.
to this product not expressly
DO NOT allow the USB port to power down when connected to
approved by the party responsible
the Li-Po battery.
for compliance may void the user's
Press & Push for
ALWAYS unplug the Li-Po battery when charging is complete.
authority to operate the equipment.
Acrobatic Action
5
Right Stick
* The fly range is approximately
Forward/Reverse
Trimmer 30-40 meters, playtime is around
Left/Right Trimmer
10-11 minutes which all depend on the
Auto-Hover
drone and air condition.
6
Set the drone on a level surface until the main
LEDs change from blinking fast to steady.
Pull the left stick up to the top and back to the
bottom to release the protection mode.
2
Embedding the propeller
guards is highly recommended
for beginners.
3
Once the battery is fully recharged, Push the handle on the battery case
it is required to insert back into the cover to slide to close the cover.
battery case and plug the battery
3
with a RED end into the drone.
Plug the charger into a USB port and the Li-Po
Charging time is about 1.5 to 2 hours
USB charger
battery as shown. (The battery connector will
only fit in one way. Do not force the connectors
together.)
The red LED will light when charging.
Poly lithium
battery The red LED will shut off once the charge is
complete.
4
On
Off
7
DRONE CALIBRATION
When the drone takes off and tilts slightly, land the Mercury
on a level surface, Push the left-hand control stick all the way
to the bottom left corner and the right-hand control stick to the
right corner and hold both sticks in those positions. The lights
on the quadcopter should begin blinking quickly. Hold the
sticks in that position for at least 4 seconds. The quadcopter
should now be calibrated.
