- Page 1 Operating Instructions Sophos RED 15 and RED 50 Appliances...
-
Page 2: Safety Instructions
(2) This device must accept any interference received, Sophos Ltd including interference that may cause undesired operation. Configuring the RED appliance Configure the RED appliance in the central UTM appliance as described in the Sophos UTM Administration Guide. Sophos RED Appliances... - Page 3 Internet and establish an encrypted tunnel to the central office. The Tunnel LED will now light: Tunnel up If any of the four status LEDs is not lit or if the System LED is red and blinking, please refer to “Controls and LED codes” section below to identify the error. Sophos RED Appliances...
- Page 4 The connection to the UTM appliance has been established LED error codes System Router Internet Tunnel Description DHCP or static address settings failed, default gateway not reachable Internet not reachable No connection to UTM appliance No configuration or firmware update failed Sophos RED Appliances...
-
Page 5: Technical Specifications
Operating Instructions Technical specifications Sophos RED 15 Chassis Metal housing (painted white) Power supply Input: 100-240 V AC, 50/60 Hz, 0.4 A Output: 12 V 1 .5 A Power consumption 7 W (max.) Dimensions W x H x D 165 x 134.8 x 34mm... -
Page 6: Wall Mounting Instructions
UTM appliance to which the RED 50 is connected. Wall mounting instructions The Sophos RED 50 can be mounted on the wall. Screws are not included in the scope of supply. Only use screws whose dimensions correspond with the mounting holes on the back. - Page 7 Operating Instructions RED 50 Mounting template Do not shrink to fit when printing Sophos RED Appliances...
- Page 8 Local WAN2 IP: Local PPP0 IP: UTM Hostname: 2nd UTM Hostname: Throughput ► WAN1 in/out: WAN2 in/out: Tunnel ► WAN1->UTM WAN1: WAN1->UTM WAN2: WAN2->UTM WAN1: WAN2->UTM WAN2: RED-Status ► Device ► Firmware ► Version: Uptime: 3G/UMTS-Status ► Signal Strength: Sophos RED Appliances...
- Page 9 $hostname can be hostname or IP address of UTM appliance ERROR Invalid device ID The RED device has not been provisioned correctly Technical specifications Sophos RED 50 Chassis Heavy-duty steel (painted white) Power supply Input: 100-240 V, 50-60Hz, 1.3 A Output: 12 V 3.33 A...
-
Page 10: Rack Mount Instructions
5. Reliable Earthing – Reliable earthing of rack-mounted equipment should be maintained. Particular attention should be given to supply connections other than direct connections to the branch circuit, (e.g. use of power strips). Sophos RED Appliances... - Page 11 Registered in England and Wales No. 2096520, The Pentagon, Abingdon Science Park, Abingdon, OX14 3YP, UK Sophos is the registered trademark of Sophos Ltd. All other product and company names mentioned are trademarks or registered trademarks of their respective owners.
