RFB 119 Series Floor Box
I N S T L L T I O N I N S T R U C T I O N S
Installation Instruction No.: 1 003 189R1 – Updated pril 2011
Products Covered: Floor Box Cat. Nos.: RFB9, RFB11,
Floor Box Covers: RFB119CTC, RFB119BTC
Floor Box Device Plates: RFB119 (suffix)
C UTION: Do not operate tile stripper or resurfacing equipment over top of covers. This may result in damage to the surface finish
of the product.
C UTION: When used in bare concrete or terrazzo floors, use part number: RFB119-P N (Sold separately).
Step 1 Locate and position box in accordance to floor
plans or blueprint.
[178mm]
6 5/16"
[161mm]
12 5/8"
[321mm]
Step 3 Remove mudcap and attach conduit.
14"
[356mm]
7"
Legrand/Wiremold electrical systems conform to and should be properly
grounded in compliance with requirements of the current National
Electrical Code or codes administered by local authorities.
ll electrical products may present a possible shock or fire
hazard if improperly installed or used. Legrand/Wiremold electrical
products may bear the mark of a Nationally Recognized Testing
Laboratory (NRTL) and should be installed in conformance with current
local and/or the National Electrical Code.
IMPORT NT: Please read all instructions
before beginning.
Step 2 Level & anchor box. Top of box must be flush with
concrete pour. Use screws, nails, or wire to prevent
box from floating during pour.
C UTION: Box has no post pour adjustment.
Step 4 Reinstall mudcap.
NOTE: For use in bare concrete or terrazzo floors, replace
mudcap with part number: RFB119-P N. (Sold
separately.) (See Step 19.)

Advertisement

loading
Need help?

Need help?

Do you have a question about the RFB9 and is the answer not in the manual?

Questions and answers

Summary of Contents for LEGRAND RFB9

  • Page 1 Legrand/Wiremold electrical systems conform to and should be properly grounded in compliance with requirements of the current National Electrical Code or codes administered by local authorities. ll electrical products may present a possible shock or fire hazard if improperly installed or used. Legrand/Wiremold electrical...
  • Page 2 Step 5 Screed to top of box surface. Hand troweling recommended near box edges. NOTE: If box is over-poured or the top plate is below the concrete surface, follow these steps: 1. Remove and retain mudcap and mudcap mounting screws. If mudcap is bent during removal, flatten within reason.
  • Page 3 Step 10 Determine device plate selection based on sizes illustrated below. 7/8" [22mm] Spacer Plate Cat No. RFB119-SP CER Used to close off space adjacent 4 1/2" to standard plates when used on [114mm] multi-gang mounting brackets. 1 13/16" 3 5/8" 5 7/16"...
  • Page 4 1 13/16" [46mm] spacing between gangs 6-Gang Mounting Bracket 4 1/2" [114mm] 1 13/16" [46mm] wide sectional device plate 3-Gang & (2) Single Gangs (Vertical) Mounting Bracket (RFB11) 2 7/16" 6" [62mm] [152mm] (3) Single Gangs (Horizontal) Mounting Bracket (RFB9)
  • Page 5 Step 12 Mount blanking plates and spacers between standard size plates to close off any gaps or openings. Typical layouts are illustrated below. 6-G NG MOUNTING BR CKETS USED WITH ST ND RD DEVICE PL TES 3-Gang Standard Plate (6 3/8" x 4 1/2" [162mm x 114m]) Cat.
  • Page 6 C RPET INST LL TIONS Step 13 Install carpet and cut 12 1/16" x 10 5/16" [262mm Step 14 Open cover lid and position in box opening. x 306mm] rectangular opening over box opening. Position (2) mounting brackets under box opening as shown in Step 15 and secure lid to brackets.
  • Page 7 5 1/16" [129mm] Radius 2 1/2" 1/4" [64mm] [7mm] 1 3/8" [35mm] Diameter 1 7/16" [37mm] C RPET INSERT TEMPL TE 9 5/8" [219mm] C UTION: When printing copies of this template please be sure template is scaled correctly and is the correct size once it is printed.
  • Page 8 60 Woodlawn Street • West Hartford, CT 06110 1-800-621-0049 • F X 860-232-2062 • Outside U.S.: 860-233-6251 Canada: 570 pplewood Crescent • Vaughan, Ontario L4K 4B4 1-800-723-5175 • F X 905-738-9721 1 003 189R1 0411 © Copyright 2011 Legrand/Wiremold ll Rights Reserved...
