- Page 1 200M Mono Amplifier Installation et fonctionnement Instalación y funcionamiento Einbau und Betrieb Installazione e funzionamento Installation & Operation...
-
Page 2: Table Of Contents
If, after reading your manual, you still have questions regarding this product, we recommend that you see your Rockford Fosgate dealer. If you need further assistance, you can call us direct at 1-800- 669-9899. Be sure to have your serial number, model number and date of purchase available when you call. -
Page 3: Getting Started
Installation Section of this manual. Other information can be located by using the Table of Contents. We, at Rockford Fosgate, have worked very hard to make sure all the information in this manual is current. But, as we are constantly finding new ways to improve our product, this information is subject to change without notice. -
Page 4: Design Features
ESIGN EATURES 1. Cast Aluminum Heatsink – The cast aluminum heatsink of the Punch amplifier dissipates heat generated by the amplifier's circuitry. The inherent advantage of casting provides a 30% improvement of cooling over conventional extrusion heatsink designs. 2. Variable Crossover – The amplifiers have a built-in 12dB/octave Butterworth filter with a crossover point variable from 50Hz to 210Hz. -
Page 5: Mounting Locations
This section focuses on some of the vehicle considerations for installing your new Amplifier. Pre- planning your system layout and best wiring routes will save installation time. When deciding on the layout of your new system, be sure that each component will be easily accessible for making adjustments. -
Page 6: Battery And Charging
Stock electrical systems which are in good condition should be able to handle the extra load of any Rockford Fosgate amplifier without problems, although battery and alternator life can be reduced slightly. To maximize the performance of your amplifier, we suggest the use of a heavy duty battery and an energy storage capacitor. -
Page 7: Using Passive Crossovers
10. Perform a final check of the completed system wiring to ensure that all connections are accurate. Check all power and ground connections for frayed wires and loose connections which could cause problems. NOTE: Follow the diagrams for proper signal polarity. CAUTION: These amplifiers are not recommended for impedance loads below 2Ω. -
Page 8: Operation
Next, turn the amplifier gain setting until once again distortion is audible and then back it down until the distortion is inaudible. Rockford Fosgate source units do not distort, so the volume can be used at maximum setting. -
Page 9: Troubleshooting
NOTE: If you are having problems after installation follow the Troubleshooting procedures below. Procedure 1: Check Amplifier for proper connections. Verify that POWER light is on. If POWER light is on skip to Step 2, if not continue. 1. Check in-line fuse on battery positive cable. Replace if necessary. 2. -
Page 10: Specifications
PECIFICATIONS MODEL Dynamic Power Rating - Measured at 14.4 Volts Mono into a 4Ω Load Mono into a 2Ω Load Signal-to-Noise Ratio Crossover Slope Crossover Frequency Crossover Type Dimensions: (with Endbell) Height Width Length Frequency Response Bandwidth Damping Factor @ 4Ω (at output connector ) Slew Rate IM Distortion (IHF) Source Unit Compatibility (+15dB gain overlap) -
Page 11: Limited Warranty Information
This warranty covers only the original purchaser of Rockford product purchased from an Authorized Rockford Fosgate Dealer in the United States. In order to receive service, the purchaser must provide Rockford with a copy of the receipt stating the customer name, dealer name, product purchased and date of purchase. -
Page 12: International Instructions
11/01 B.M. MAN-3773-A Rockford Fosgate Rockford Corporation 546 South Rockford Drive Tempe, Arizona 85281 U.S.A. In U.S.A., (480) 967-3565 In Europe, Fax (49) 8503-934014 In Japan, Fax (81) 559-79-1265 www.rockfordfosgate.com Printed in U.S.A...
