Architectural Area Lighting Y-LED Installation Manual

4
9 2X
B
RED
BLACK
26
BLACK RED
GRAY
25
PURPLE
RED
BLACK
WHITE
A A A
4
3
2X
2X 13
4X 16
2X 15
2-PIN FEMALE CONNECTOR
WIRE COLOR TO SLOT #
PURPLE 1
GRAY 2
20
10 2X
PURPLE
1
2
GRAY
SIDE VIEW
17
21
18
19 4X
RED
4
BROWN
3
2
YELLOW
1
GRAY
SIDE VIEW
4-PIN FEMALE CONNECTOR
WIRE COLOR TO SLOT #
RED 4
BROWN 3
YELLOW 2
1
GRAY 1
3X
3
22
24 2X
ITEM # 13 P/N
4 2X
93047432-3012
93047432-3014
23
93047432-3015
14
26
25
24
23
22
12
21
20
7 2X
19
18
11 2X
17
6
16
15
10
14
13
2
12
11
10
9
8
7
6
5 3X
5
4
3
3 3X
2
1
ITEM
UNSPECIFED TOLERANCES:
u
X.X= 0.1 X.XX=
FRACTIONS=
DIMENSIONS IN INCHES
DIMENSIONS IN [ ] IN MM
CONFORMS TO ASME Y14.5M
DO NOT SCALE PRINT
4
THIRD ANGLE PROJECTION
2
REV DATE RECORD
A 12/23/13 ECN # 140120012
2 UP LED BOARD
DESCRIPTION
3000K
4100K
5100K
80115 16 INCHES RED 18 AWG WIRE
80104 16 INCHES BLACK 18 AWG WIRE
A84048 2 NUT 1/4-20 HEX SS
93049759 1 BRACKET FGL/FGS LED MOUNTING
A86002-2 1 SCR-1/4-20x10 LG. SS THRD.STUD
A86002 1 SCR-1/4-20x7 LG. SS THRD.STUD
88552 1 FEMALE 4-PIN QUICK DISCONNECT
88548 1 FEMALE 2-PIN QUICK DISCONNECT
88110 6 Socket, Quick Disconnect
A74011 1 TERMINAL-FEMALE
A74010 1 TERMINAL-MALE
93023746 4 93023746 SCR. 6-32 x 1/4" PHH PHMS SS
93049774 2 PLATE LED UPLIGHT
93045602 2 93045602 Pico Emmiter, Acrylic
SEE SHART 2 ASSY-PCB 2LED BOARD 1X2
93049762 1 BRACKET LED UPLIGHT FGL-FGS
A84032 2 SCR-8-32X1/2 PHH PHMS SS
93049763 1 BRACKET LIFESHIELD Y-LED
A74106 2 WIRE TERMINAL
A74026 AR CABLE TIE GT50S2 BIN ITEM
93017851 2 SCR-4-40x3/16 PHH PH MS SS
93042082-080051 1 SWITCH THERMAL N. O.
A84041 3 SETSCR-1/4-20x1 SS
A84051 5 SCR-1/4-20x1/2 BTN HD CAP SS
A56332-18 3 STANDOFF 3/8"DIA. X 8"
93041672 1 32-LED OPTICAL ASSEMBLY
93046560 1 FGL/FGS LED MOUNTING PLATE
PART # QTY DESCRIPTION
PARTS LIST
INCHES
u u
0.03 X.XXX= 0.010
u u v
1/32 ANGULAR TOLERANCE= 1
DRAWN:
rcarrillo 12/23/13
RETROFIT KIT Y-LED FGL SLG-PA3-PA5
CHECKED BY:
--- --/--/--
MATERIAL:
ENGINEERING:
KC 12/23/13
SCALE SIZE DRAWING NO.
CATALOG NO.
B
FGL Y-LED
2
1
DESN CHCK
RC KC
B
PA3 / PA5 LENS
SLG LENS
NOT SHOWN
A
NOTES
This document contains confidential and proprietary information of Architectural
Area Lighting, a division of Hubbell Lighting, Inc. (HLI). Receipt or possession of
this document does not convey any rights to reproduce or disclose its contents,
or to make, use , or sell anything it may disclose. Reproduction, disclosure, or
use of the document or its contents, without the specific written authorization of
HLI, may violate the intellectual property rights of HLI.
LENS
