  • Page 1 SG4 EXTENDED Instruction Manual...
  • Page 2 All brand and product names mentioned herein are for identification purposes only and may be trademarks or registered trademarks of their respective owners. Datalogic shall not be liable for technical or editorial errors or omissions contained herein, nor for incidental or consequential damages resulting from the use of this material.

  • Page 4: Table Of Contents

    CONTENTS GENERAL VIEW ....................... viii  LED DESCRIPTION ....................viii  1  GENERAL INFORMATION ....................1  1.1  General Description ....................1  1.1.1  General Description of the safety light curtains ..........1  1.1.2  Package Contents ..................3  1.2  New features compared to SG4 BASE............... 3  1.3 ...
  • Page 5 7.8  Override ........................48  7.8.1  Override mode ....................49  7.8.2  Override timeout ................... 50  7.8.3  Override restart ..................... 51  7.9  Blanking ........................54  7.9.1  Fixed Blanking ....................55  7.9.2  Fixed Blanking with increased tolerance............56  7.9.3  Floating Blanking with total surveillance ............56  7.9.4 ...
  • Page 6 FIGURES INDEX Fig. 1 – Resolution ...................... 4   Fig. 2 – Controlled height.................... 5   Fig. 3 – Minimum installation distance (vertical) ............6   Fig. 4 – Minimum installation distance (horizontal) ............. 7   Fig. 5 – Incorrect device positioning ................. 11  ...
  • Page 7 Fig. 50 – Override timings (edge trigger) ..............49   Fig. 51 – Override timeout timings ................50   Fig. 52 – Override restart connection ............... 51   Fig. 53 – Override restart timings (auto) ..............52   Fig. 54 – Override restart timings (normal) ............... 53  ...

  • Page 8: General View

    GENERAL VIEW SG4 EXTENDED LED DESCRIPTION The microprocessor guarantees the check and the management of the beams that are sent and received through the units: the microprocessor – through some LEDs – informs the operator about the general conditions of the safety light curtain, both for settings and for diagnostics (see chapter 6 and 8).

  • Page 9: General Information

    GENERAL INFORMATION 1 GENERAL INFORMATION 1.1 GENERAL DESCRIPTION 1.1.1 General Description of the safety light curtains The safety light curtains of the SG4 series are optoelectronic multibeam devices that are used to protect working areas that, in presence of machines, robots, and automatic systems in general, can become dangerous for operators that can get in touch, even accidentally, with moving parts.
  • Page 10 As the required knowledge may not be completely included in this manual, we suggest the customer to contact Datalogic Technical Service for any necessary information relative to the functioning of the SG light curtains and the safety rules that regulate the correct installation...

  • Page 11: Package Contents

    GENERAL INFORMATION 1.1.2 Package Contents Package contains the following objects:  Receiver (RX)  Emitter (TX)  Installation Quick Guide of SG4 EXTENDED curtain  Biannual checklist and periodical maintenance schedule  CD with instruction manual and other documents  4 angled fixing brackets and specific fasteners ...

  • Page 12: How To Choose The Device

    SG4 EXTENDED INSTRUCTION MANUAL HOW TO CHOOSE THE DEVICE There are at least three different main characteristics that should be considered when choosing a safety light curtain, after having evaluated the risk assessment. 1.3.1 Resolution The resolution of the device is the minimum dimension that an opaque object must have in order to obscure at least one of the beams that constitute the sensitive area.

  • Page 13: Controlled Height

    GENERAL INFORMATION 1.3.2 Controlled height The controlled height is the height protected by the safety light curtain Fig. 2 – Controlled height The height controlled by the SG4 EXTENDED is the whole height of the light curtain. Referring to the figure above the protected height is reported in the table here below. Model Protected height (mm) SG4-xx-030-OO-P...

  • Page 14: Minimum Installation Distance

    SG4 EXTENDED INSTRUCTION MANUAL 1.3.3 Minimum installation distance The safety device must be positioned at a specific safety distance (Fig. 3). This distance must ensure that the dangerous area cannot be reached before the dangerous motion of the machine has been stopped by the ESPE. The safety distance depends on 4 factors, according to the EN ISO 13855 Standard (which replaces EN999): ...

  • Page 15: Fig. 4 – Minimum Installation Distance (Horizontal)

    GENERAL INFORMATION where: S = Minimum safety distance in mm. t1 = Response time of the ESPE in seconds (see chapter 11) t2 = Machine stopping time in seconds. H = Beam height from ground; this height must always be less than 1,000 mm. Fig.

  • Page 16: Typical Applications

    SG4 EXTENDED INSTRUCTION MANUAL TYPICAL APPLICATIONS Example 1: operating point protection on drilling machines The operator positions the part and takes it back after machining. The operator must be protected against possible abrasions while working. Solution: SG4 EXTENDED 14 mm safety light curtain is especially suitable for this kind of application, which requires the installation of the device directly on the machine.

  • Page 17: Safety Informations

    GENERAL INFORMATION Example 4: Milling machines A milling machine is a machine tool used for the shaping of metals and other solid materials. Operator hands and body must be protected from being dragged, entangled or cut by the tool / spindle. Solution: SG4 EXTENDED series safety light curtain is the best solution considering the required safety levels and application...

  • Page 18: Installation

     The presence of intense electromagnetic disturbances could affect device’s correct operation. This condition shall be carefully assessed by seeking the advice of Datalogic Technical Service  The operating distance of the device can be reduced in presence of smog, fog or airborne dust ...

  • Page 19: General Information On Device Positioning

    INSTALLATION 2.2 GENERAL INFORMATION ON DEVICE POSITIONING The safety light curtain should be carefully positioned, in order to reach a very high protection standard; access to the dangerous area must only be possible by passing through the protecting safety light beams. Fig.

  • Page 20: Minimum Distance From Reflecting Surfaces

    SG4 EXTENDED INSTRUCTION MANUAL Fig. 7 Fig. 8 2.2.1 Minimum distance from reflecting surfaces Reflecting surfaces placed near the light beams of the safety device (over, under or laterally) can cause passive reflections. These reflections can affect the recognition of an object inside the controlled area.

  • Page 21: Distance Between Homologous Devices

    INSTALLATION The minimum distance depends on:  operating distance between emitter (TX) and receiver (RX);  real aperture angle of ESPE (EAA); especially: for ESPE type 4 EAA = 5° ( = ± 2,5°) Diagram of Fig. 10 shows the minimum distance from the reflecting surface (Dsr), based on the operating distance: ESPE Type 4...
  • Page 22 SG4 EXTENDED INSTRUCTION MANUAL The following graphic shows the distance from the interfering devices (D ) according to the operating distance (D ) of the couple ( TXA – RXA ). Fig. 12 The following table shows, for convenience, the values of the minimum installation distances relative to some operating distances: Operating distance Minimum installation distance...

  • Page 23: Fig. 13 – Interference Between Adjacent Light Curtains

    INSTALLATION Fig. 13 provides an example of possible interference between different devices and two possible solutions. Fig. 13 – Interference between adjacent light curtains If two light curtains have to be mounted near each other as reported in the first example of Fig.

  • Page 24: Emitter And Receiver Orientation

     The alignment of the emitter and the receiver can be a very critical operation when deviating mirrors are used. Even very small displacements of the mirror is enough to lose alignment. The use of Datalogic laser pointer accessory is recommended under these conditions ...

  • Page 25: Checks After First Installation

    INSTALLATION The following table shows the operating distances relating to the number of mirrors used. number of mirrors operating distance operating distance (30 mm) (14 mm) 20 m 16,5 m 5,1 m 13,7 m 4,3 m 11,6 m 3,7 m ...
  • Page 26 SG4 EXTENDED INSTRUCTION MANUAL  ESPE has to be correctly aligned, press slightly on the product side in both directions the red LED must not turn on  The activation of the TEST function (on TX side) causes the opening of the OSSD outputs (red LED, OSSD on RX side, ON and controlled machine stop) ...

  • Page 27: Mechanical Mounting

    MECHANICAL MOUNTING 3 MECHANICAL MOUNTING The emitting (TX) and receiving (RX) units must be installed with the relevant sensitive surfaces facing each other. The connectors must be positioned on the same side and the distance must be included within the operating range of the model used (see chapter 11). The two units must be positioned the most aligned and parallel possible.

  • Page 28: Fig. 19 – Light Curtain Dimensions

    SG4 EXTENDED INSTRUCTION MANUAL Fig. 19 – Light curtain dimensions MODELS L (mm) A (mm) B (mm) C (mm) 306.3 86.3 SG4-xx-030-OO-P SG4-xx-045-OO-P 456.3 236.3 SG4-xx-060-OO-P 606.2 306.2 SG4-xx-075-OO-P 756.2 406.2 906.1 506.1 SG4-xx-090-OO-P 1056.1 606.1 SG4-xx-105-OO-P 1206 SG4-xx-120-OO-P SG4-xx-135-OO-P 1356 1066 SG4-xx-150-OO-P...

  • Page 29: Electrical Connections

    ELECTRICAL CONNECTIONS 4 ELECTRICAL CONNECTIONS All electrical connections to the emitting and receiving units are made through some particular cables; these cables are composed of a rectangular 18 pin connector on light curtain side and M12 male connector(s) on the other side. The Muting cable allows to have on the receiving unit one M12 12-pole connector and one M12 5-pole connector.
  • Page 30 SG4 EXTENDED INSTRUCTION MANUAL PIG-TAIL CABLE BLANKING CONFIGURATION FOR RECEIVER (CS-G1-70-B-002) M12 12 pin: 24V (brown) 0V (blue) RESET/RESTART/ALIGN (white) TEACH IN (green) OSSD2 (pink) EDM (yellow) N.C. (black) OSSD1 (grey) TOLERANCE (red) LAMP (violet) N.C. (grey-pink) EARTH (red-blue) PIG-TAIL CABLE FOR EMITTER (CS-G1-50-B-002) M12 5 pin: 24V (brown)
  • Page 31 ELECTRICAL CONNECTIONS MUTING CONFIGURATION RECEIVER LAYOUT LINE BEHAVIOUR CONNECTION OSSDs high level = free path OSSD1 / OSSD 2 low level = object detection OSSDs high level = override function active low level = override function not active OVERRIDE STATUS NB: at startup there are fluctuations on this line not concerning the override activation 24Vdc...

  • Page 32: Notes On Connections

    SG4 EXTENDED INSTRUCTION MANUAL NOTES ON CONNECTIONS For the correct functioning of the SG4 safety light curtains, the following precautions regarding the electrical connections have to be respected:  Do not place connection cables in contact with or near high-voltage cables and/or cable undergoing high current variations (e.g.

  • Page 33: Fig. 21 – Correct Connection Of The Load

    ELECTRICAL CONNECTIONS  Connect both OSSDs to the device to control. Failure to connect an OSSD to the activating device jeopardises the system safety degree that the light curtain has to control. Fig. 21 – Correct connection of the load Fig.

  • Page 34: Alignment Procedure

    SG4 EXTENDED INSTRUCTION MANUAL 5 ALIGNMENT PROCEDURE The alignment between the emitting and the receiving units is necessary to obtain the correct functioning of the light curtain. A good alignment prevents output’s instability caused by dust or vibrations. The alignment is perfect if the optical axes of the first and the last emitting unit's beams coincide with the optical axes of the corresponding elements of the receiving unit.
  • Page 35 ALIGNMENT PROCEDURE In Alignment Mode ESPE is always in Safe State and the OSSDs are kept OFF. The state of alignment is estimated from RX unit by reading the received signal level of each beam compared on 4 factory established thresholds. First and last beams received level get some more weight.

  • Page 36: Function Setting

    SG4 EXTENDED INSTRUCTION MANUAL 6 FUNCTION SETTING ESPE operation functions and parameters configuration can be performed in two different ways: - Basic Configuration Mode (BCM): Let the user select among basic functions / basic parameters with the help of push buttons and led user interface (available on both RX and TX unit) - Advanced Configuration Mode (ACM): Let the user select among advanced functions / advanced parameters with the help of a PC...

  • Page 37: Fig. 28 – Acm Configuration Cycle

    FUNCTION SETTING ADVANCED CONFIGURATION MODE SG Extended UI software (Graphic User Interface, GUI) for PC allows the user to set ESPE advanced configuration. Many parameters are available to customize ESPE behaviour for specific applications. Since ESPE parameters can be safety critical and PC software cannot be guaranteed as a safety component, a safe configuration procedure has to be followed.

  • Page 38: Reset To Factory Configuration

    SG4 EXTENDED INSTRUCTION MANUAL Generic configuration information: user, date, time ... Identifies a phisycal ESPE system with a unique configuration (checksum of ESPE serial numbers, ESPE hardware, configuration parameters) Global ESPE system parameters Device identification (Serial Number) Device s.n: 123456789 Configuration ID (checksum of configuration parameters) Parameters of each cascade unit...

  • Page 39: Function List

    FUNCTION SETTING FUNCTION LIST SG4 EXTENDED has two main operating modes: Blanking and Muting. Choosing between Blanking and Muting changes the function setting associated to Leds 5 to 8. N.B.: the default configuration is indicated in bold characters N.B.: since the last 3 leds don’t change status by passing from a muting configuration to a blanking configuration (and viceversa) and since these 3 leds have 3 different meanings depending on the configuration, the user has to pay attention to the configuration setting when decides to change configuration...
  • Page 40 SG4 EXTENDED INSTRUCTION MANUAL Function list in Blanking operation Mode (Led 3 OFF) Led Status Function Led # Setting Coding Code 1 Code 2 No Code Muting/Blanking Muting Selection Blanking Enabled Disabled Restart mode Auto Manual Floating Blanking Floating Blanking Disabled Selection Floating Blanking 1 beam Floating Blanking 2 beams...

  • Page 41: Functions

    FUNCTIONS 7 FUNCTIONS This chapter deals with all the functions of the light curtain. RESTART MODE An opaque object detected by the beams causes the switching of the OSSD outputs (i.e. the opening of the safety contacts - SAFE condition). The restart mode allows the user to define how the light curtain returns in a Normal Operation condition.

  • Page 42: Fig. 32 – Restart Timings (Manual)

    SG4 EXTENDED INSTRUCTION MANUAL Manual Restart: after the ESPE has detected an opaque object in the controlled area, the light curtain begins its normal functioning only by pressing the Restart button (normal open push button) and after the object has been removed from the controlled area. The RESTART push-button must be kept pressed for at least 500 msec.

  • Page 43: Test

    FUNCTIONS BCM Configuration: Restart Mode Auto Led 5 ON Red Manual Led 5 OFF ACM Configuration: Restart Mode TEST The TEST function can be activated by pressing the 24VDC normally-open push-button connected to TX unit TEST input (pin 2 of M12-5 poles) for at least 0.5 seconds. The TEST disables the emission stage, so the RX side sees interrupted all beams and the OSSD goes low within response time.

  • Page 44: Reset

    SG4 EXTENDED INSTRUCTION MANUAL RESET When ESPE locks into failure state user can go back to Normal Operation with a power cycle or using the activation of RESET function (non critical failures only). activate RESET function 24VDC normally-open button connected RESET/RESTART/ALIGN input (pin 3 of M12-12 poles –...

  • Page 45: Fig. 36 – Edm Timings

    FUNCTIONS The function controls the 24VDC normally-closed contact switching according to the changes of the OSSDs’ status. CONFIGURATION Fig. 36 – EDM timings The EDM status is antivalent with OSSDs’: the timing diagram explains the relationship between the cause (OSSDs) and the effect (EDM) with the maximum permissible delay. Tc ...

  • Page 46: Edm Selection

    SG4 EXTENDED INSTRUCTION MANUAL EDM SELECTION This function lets the user to select or exclude the monitoring of the external switching devices. BCM Configuration: EDM Selection Enabled Led 4 ON Yellow Disabled Led 4 OFF ACM Configuration: EDM Selection To increase safety level, when EDM is set OFF, at start-up ESPE checks if EDM input is floating.
  • Page 47 FUNCTIONS BCM Configuration (TX side): Reduction Range Long Led 3 ON Yellow Short Led 3 OFF ACM Configuration (RX side) : Reduction Range In particular, if long range is selected TX and RX can be mounted at the maximum allowed operating distance;...

  • Page 48: Muting

    SG4 EXTENDED INSTRUCTION MANUAL MUTING Muting function allows automatic deactivation of the safety function on the whole or part of protected height in order to carry out definite cyclical operations without blocking machine work. As the pertaining safety requirements demand, ESPE is equipped with two muting activation inputs, MUTING1 and MUTING2.

  • Page 49: Muting Function Disable

    FUNCTIONS 7.7.1 Muting function disable During SG4 EXTENDED operations muting function can be dynamically disabled or enabled: when disabled no valid muting request will be accepted at the MUTINGX inputs and safety function will always be on. The user can disable the muting function at runtime by setting a high level on the signal MUTING DISABLE (pin 7 of the M12-12 poles connector).

  • Page 50: Fig. 41 – T Muting Timings

    SG4 EXTENDED INSTRUCTION MANUAL T muting In T type operations the device enters muting function if the input MUTING2 goes high within a fixed T12max after the rise of MUTING1 (or viceversa). The muting function ends as soon as the signal on MUTING1 or MUTING2 goes low. A further custom delay (Tdelay) may be set by the user in a 0-1000 ms range.

  • Page 51: Fig. 42 – T Muting Connection

    FUNCTIONS Fig. 42 – T muting connection L muting In L type operation the device enters muting function if the inputs go high in a particular order: MUTING1 has to activate first, then MUTING2 can activate; if MUTING2 activates before MUTING1, the device doesn’t enter the muting function. “T12”...

  • Page 52: Fig. 44 – L Muting Connection

    SG4 EXTENDED INSTRUCTION MANUAL The sensor named A is the farthest from the light curtain, so its beam is intercepted first. Making reference to the next figure, since the pack goes from right to left only, B sensor can’t be intercepted first; if this happens the device doesn’t enter muting function. “V”...

  • Page 53: Muting Timeout

    FUNCTIONS 7.7.5 Muting timeout Muting timeout is a time that defines the maximum duration of muting function; after the timeout the muting ends. This time can be set from the user in both BCM and ACM mode. In BCM mode the user can select a timeout of 10 minutes or infinite; “infinite” means that muting timeout could never end: if the conditions of muting persist, the muting function still continues to exist.

  • Page 54: Muting Filter

    SG4 EXTENDED INSTRUCTION MANUAL 7.7.6 Muting Filter This function avoids undesired activations of the muting. The muting filter is a filter on muting inputs; low-high or high-low transitions of MUTING signals are considered valid only if maintained for a time (Tf) greater than 100ms. If this function is disabled the logical level of the muting sensors corresponds to the wire level.

  • Page 55: Partial Muting

    FUNCTIONS 7.7.7 Partial muting It’s possible to configure the type of muting: total or partial. Partial muting can be useful in those applications in which the user wants to limit the muting function effects to selected zones only. In ACM Configuration the user can select a maximum of 5 muting zones, each defined with the following parameters: - Position: first beam of muting zone (starting from user display cap) - Dimension: number of beams of muting zone...

  • Page 56: Override

    SG4 EXTENDED INSTRUCTION MANUAL OVERRIDE Override function allows the user to force safety function deactivation whenever it’s necessary to restart the machine despite one or more ESPE beams are intercepted. The aim is clearing protected area of any working materials blocked ahead of ESPE because of (i.e.) a cycle anomaly.

  • Page 57: Override Mode

    FUNCTIONS 7.8.1 Override mode It’s possible to configure the trigger of override inputs: Level or Edge. As explained in diagrams below two types of override trigger sequence are accepted on external inputs: - Level Trigger: override engaged until both contacts are closed AND at least one muting sensor is intercepted.

  • Page 58: Override Timeout

    SG4 EXTENDED INSTRUCTION MANUAL BCM Configuration: Override Mode Level Led 8 ON Green Edge Led 8 OFF ACM Configuration: Override Mode 7.8.2 Override timeout BCM mode In both modes Override status timeout is 120s: if Override conditions remain active and both Override contacts remain closed (this condition only in Level Trigger Mode) more than 120s, the Override goes low in any case after a maximum of 120s.

  • Page 59: Override Restart

    FUNCTIONS ACM Configuration: Override Timeout 7.8.3 Override restart This kind of selection can be achieved only if the light curtain is in Manual Restart; the user can select the type of Override Restart: Normal or Auto. The user has to connect the RESET/RESTART/ALIGN input (pin 3 of M12-12 poles – RX side) to a 24VDC normally-open contact.

  • Page 60: Fig. 53 – Override Restart Timings (Auto)

    SG4 EXTENDED INSTRUCTION MANUAL AUTO OVERRIDE RESTART The OSSDs go in normal operation state after the RESTART signal goes low, and not after 500msec. A timeout of 5s on the high RESTART brings the ESPE in failure lockout. The outputs go high after a time that is the maximum value between the recovery time and the time of restart high (greater or equal to 500msec), so this time can be any value between 500ms and 5s.

  • Page 61: Fig. 54 – Override Restart Timings (Normal)

    FUNCTIONS NORMAL OVERRIDE RESTART The OSSDs go in normal operation state after the RESTART signal goes low, and not after 500msec. A timeout of 5s on the high RESTART brings the ESPE in failure lockout. The outputs go high after a time that is the maximum value between the recovery time and the time of restart high (greater or equal to 500msec), so this time can be any value between 500ms and 5s.

  • Page 62: Blanking

    SG4 EXTENDED INSTRUCTION MANUAL BLANKING Blanking is an auxiliary function of safety light curtains for which the introduction of an opaque object inside parts of the light curtain’s controlled area is allowed without stopping the normal functioning of the machine. Blanking is only possible in the presence of determined safety conditions and in accordance with a configurable operating logic.

  • Page 63: Fixed Blanking

    FUNCTIONS 7.9.1 Fixed Blanking Fixed Blanking allows a fixed portion of the controlled area (i.e. a fixed set of beams) to be occupied, while all the other beams operate normally. The blanking zone can be obtained through a Teach-in operation: the user has to keep pressed the 24VDC normally-open contact of Teach-in (pin 4 of M12-12 poles - RX) for at least 3 seconds while an object intercepts the area to be blanked.

  • Page 64: Fixed Blanking With Increased Tolerance

    SG4 EXTENDED INSTRUCTION MANUAL 7.9.2 Fixed Blanking with increased tolerance This is a fixed blanking with the tolerance only on one side of the blanking zone, so the user has to choose a “tolerance top” or a “tolerance bottom”. This function is useful for conveyors (that use fixed blanking) with goods moving on them (with a dimension within the tolerance).

  • Page 65: Reduced Resolution

    FUNCTIONS 7.9.5 Reduced Resolution Reduced Resolution is a particular kind of floating blanking in which more than one object can intercept each a defined number of beams with the ESPE remaining in normal operation. The number that follows indicates how many adjacent beams can be intercepted by the object to allow the light curtain to remain in Normal Operation.
  • Page 66 SG4 EXTENDED INSTRUCTION MANUAL The presence of the tolerance is indicated with the blinking of some leds in the user interface as shown below. Tolerance indication Tolerance active Led 3 blinking YELLOW Tolerance affects the ESPE resolution. Take care to the new resolution in order to calculate a new mechanical mounting OSITION OLERANCE...
  • Page 67 FUNCTIONS BLANKING IN BASIC CONFIGURATION MODE In basic configuration mode only a reduced set of possible blanking configuration is possible. BCM Configuration: Fixed Blanking Led 8 ON Green 1 Fixed Blanking Zone 2 Fixed Blanking Zones Led 8 OFF 1 Fixed Blanking zone: only 1 zone can be configured as blanking zone 2 Fixed Blanking zones: 2 zones can be configured as blanking zone BCM Configuration: Floating Blanking Floating Blanking Disabled...
  • Page 68 SG4 EXTENDED INSTRUCTION MANUAL BLANKING IN ADVANCED CONFIGURATION MODE In ACM a maximum of 5 blanking zones (fixed + floating) can be configured (at least 1 beam of separation between zones is necessary). In ACM the number of beams can be chosen by the user. REDUCED RESOLUTION ACM Configuration GUI calculates the maximum object size (in mm) that can intercept ESPE without causing...
  • Page 69 FUNCTIONS FIXED BLANKING The panel on the right shows the settings of the active blanking zone (in the example here below the active blanking zone has a dimension of 3 beams and is 7 beams from the bottom of the light curtain; no tolerance is set). FIXED BLANKING WITH INCREASED TOLERANCE (TOP or BOTTOM The example below shows a setting with fixed blanking with increased tolerance top: over...
  • Page 70 SG4 EXTENDED INSTRUCTION MANUAL FLOATING BLANKING WITH PARTIAL SURVEILLANCE Floating objects can move up or down intercepting different beams while moving; they can even get out of the protected area or intercept a number of beams minor than the configured one.

  • Page 71: Cascade

    FUNCTIONS 7.10 CASCADE A dedicated Bus provides the connection between master and slave units. The same bus is used to connect SG-Dongle which links the light curtain to Ethernet. A proprietary transmission protocol for bus is used to communicate to slaves safety related informations and status.

  • Page 72: Fig. 58 – Npn Timings

    SG4 EXTENDED INSTRUCTION MANUAL NPN CONFIGURATION THIS CONFIGURATION LOAD CONNECTED 24VDC OSSD BETWEEN OUTPUT OSSD N NORMAL OPERATION S OUTPUT VOLTAGE IS HEN AN OPAQUE OBJECT INTERCEPTS THE BEAMS THE OSSD STATUS OF S CHANGES FROM LOW TO HIGH . 57 – NPN CONNECTION Fig.

  • Page 73: Coding

    FUNCTIONS 7.12 CODING The coding function allows the ESPE to remain in normal operation also when an interference condition with an other ESPE occurs, and in particular when the TX of the first light curtain radiates in the direction of the RX of the second light curtain. Obviously, both light curtains must be configured with two different codes (see also par.
  • Page 74 SG4 EXTENDED INSTRUCTION MANUAL When one of the three option (no code, code 1 and code 2) is selected and the beams are intercepted, the indication on the user interface is the following. Normal Operation (RX side): Intercepted beams No Code Led 5 and 6 OFF Code 1 Led 5 ON Red, Led 6 OFF...

  • Page 75: Diagnostic

    DIAGNOSTIC 8 DIAGNOSTIC USER INTERFACE In the left side of user control panel (on both units of light curtains) an 8 leds user interface helps customer to control and check the state of the light curtain, for alignment mode, normal operation and for troubleshooting activity.
  • Page 76 SG4 EXTENDED INSTRUCTION MANUAL ESPE LED CONFIGURATION WORKING INDICATION SUGGESTED ACTION Blink Indifferent MODE VALID BLANKING (OSSDS ON) blanking zones not NORMAL INVALID BLANKING respected OPERATION (OSSDS OFF) reconfigure blanking (teach- BLANKING in if BCM) ONLY check effective ESPE BCM TOLERANCE resolution and intentional ACTIVE activation of tolerance...
  • Page 77 POWER SUPPLY Connection. If error persists FAILURE contact Technical Support A critical failure can’t be re-established with a Reset procedure but it’s necessary to switch- off and switch-on the light curtain; if the failure persists, please contact the Datalogic Technical Support.
  • Page 78 Turn ON/OFF ESPE. If error CRITICAL FAILURE persists contact Datalogic Automation Technical Support A critical failure can’t be re-established with a Reset procedure but it’s necessary to switch- off and switch-on the light curtain; if the failure persists, please contact the Datalogic Technical Support.

  • Page 79: Periodical Checks

    The safety devices fulfil their safety function only if they are correctly installed, in accordance with the Standards in force. If you are not certain to have the expertise necessary to install the device in the correct way, Datalogic Automation Technical Support is at your disposal to carry out the installation.

  • Page 80: Warranty

    36 (thirty-six) months from the date of manufacturing. DATALOGIC AUTOMATION will not be liable for any damages to persons and things caused by wrong installation modes or device use.

  • Page 81: 10  Device Maintenance

     paper or other abrasive materials 10.1 PRODUCT DISPOSAL Under current Italian and European laws, DATALOGIC S.p.A. is not obliged to take care of product disposal at the end of its life. DATALOGIC S.p.A. recommends to dispose of the product in compliance with local laws or...

  • Page 82: 11  Technical Data

    SG4 EXTENDED INSTRUCTION MANUAL 11 TECHNICAL DATA ELECTRICAL DATA Power supply (Vdd): 24 Vdc ± 20% Unit current draw (TX): 3 W max Unit current draw (RX): 5 W max (without load) Outputs: 2 PNP or 2 NPN Short-circuit protection: 1.4 A max Output current: 0.5 A max / each output...

  • Page 83: 12  List Of Available Models

    LIST OF AVAILABLE MODELS 12 LIST OF AVAILABLE MODELS Controlled Response time Response time Resolution Model height AIC OFF AIC ON Beams (mm) (mm) (msec) (msec) SG4-14-030-OO-P SG4-14-045-OO-P SG4-14-060-OO-P SG4-14-075-OO-P SG4-14-090-OO-P SG4-14-105-OO-P 1050 SG4-14-120-OO-P 1200 SG4-14-135-OO-P 1350 SG4-14-150-OO-P 1500 SG4-14-165-OO-P 1650...
  • Page 84 Master response Slave response time AIC OFF time AIC OFF time AIC ON time AIC ON (msec) (msec) (msec) (msec) Tmaster Tslave Tmaster AIC Tslave AIC SG4-14-030-OO-P 13,7 13,7 19,1 19,1 SG4-14-045-OO-P 15,4 15,4 23,6 23,6 SG4-14-060-OO-P 17,2 17,2 28,1...

  • Page 85: 13  Overall Dimensions

    OVERALL DIMENSIONS 13 OVERALL DIMENSIONS MODEL (mm) L (mm) SG4-xx-030-OO-P 306,3 SG4-xx-045-OO-P 456,3 SG4-xx-060-OO-P 606,3 SG4-xx-075-OO-P 756,3 SG4-xx-090-OO-P 906,3 SG4-xx-105-OO-P 1056,3 SG4-xx-120-OO-P 1050 1206,3 SG4-xx-135-OO-P 1200 1356,3 SG4-xx-150-OO-P 1350 1506,3 SG4-xx-165-OO-P 1500 1656,3 SG4-xx-180-OO-P 1650 1806,3 xx = Resolution (14mm - 30mm)

  • Page 86: 14  Outfit

    SG4 EXTENDED INSTRUCTION MANUAL 14 OUTFIT Angled fixing bracket (with threaded pins metallic insert)
  • Page 87 OUTFIT Terminator cap (CVL-5196) Tool for BCM configuration The tool for BCM configuration, when not used, can be inserted in the profile groove by making it enter from the top of the light curtain...

  • Page 88: 15  Accessories

    SG4 EXTENDED INSTRUCTION MANUAL 15 ACCESSORIES 15.1 BRACKETS FIXING Metal angled fixing bracket Angled fixing bracket Angled fixing bracket + Orientable support Angled fixing bracket + Antivibration support Angled fixing bracket + Orientable support + Antivibration support MODEL DESCRIPTION CODE ST-KSTD Fixing brackets (4 pcs kit) 95ACC1670...
  • Page 89 ACCESSORIES Plastic angled fixing bracket 56.2 65.7 14.5 20.5 53.5 59.5   78.4 66.2 72.2  Fixing bracket 56.2 56.9 71.2 71.9   74.7 83.9 84.7  Fixing bracket + Orientable support 56.2 65.7 21.1 52.8 78.4 52.5 Fixing bracket + Antivibration support 71.2 71.9...
  • Page 90 SG4 EXTENDED INSTRUCTION MANUAL Cascade bracket MODEL DESCRIPTION CODE ST-KCASCADE-SG EXTENDED Bracket 95ASE2110...

  • Page 91: Muting Lamp

    ACCESSORIES 15.2 MUTING LAMP Ø4 Ø4.5 LAMPADA LMS-2 Ø4 LAMPADA LMS-3 Ø54 Ø5 Ø4.5 SU-LMS-1A LMS-1 MODULO SU-LMS-1A + LMS-1 SUPPORTO SU-LMS-1B + LMS-1 MODEL DESCRIPTION CODE Muting lamp 95ASE1830 LMS-1 Modular Muting lamp 95ACC1990 Muting lamp - horizontal mounting LMS-2 95ACC2000 Muting lamp - vertical mounting...

  • Page 92: Deviating Mirrors

    SG4 EXTENDED INSTRUCTION MANUAL 15.3 DEVIATING MIRRORS MODEL DESCRIPTION CODE SG-DM 150 Deviating mirror version 150 mm 95ASE1670 MODEL DESCRIPTION CODE (mm) (mm) (mm) Deviating mirror version 600 mm SG-DM 600 95ASE1680 Deviating mirror version 900 mm SG-DM 900 95ASE1690 Deviating mirror version 1200 mm SG-DM 1200 1145...
  • Page 93 ACCESSORIES Fixing kit MODEL DESCRIPTION CODE ST-DM Kit “STAND ALONE” 95ASE1940...

  • Page 94: Columns And Floor Stands

    SG4 EXTENDED INSTRUCTION MANUAL 15.4 COLUMNS AND FLOOR STANDS MODEL DESCRIPTION L (mm) X (mm) CODE SE-S 800 Column and floor stand H = 800 mm 30x30 95ACC1730 SE-S 1000 Column and floor stand H = 1000 mm 1000 30x30 95ACC1740 SE-S 1200 Column and floor stand H = 1200 mm...

  • Page 95: Lens Shield (Pmma)

    ACCESSORIES 15.5 LENS SHIELD (PMMA) MODEL DESCRIPTION CODE SG-LS 150 Lens Shield H=150mm (5pcs) 95ASE1450 SG-LS 300 Lens Shield H=300mm (5pcs) 95ASE1460 SG-LS 450 Lens Shield H=450mm (5pcs) 95ASE1470 SG-LS 600 Lens Shield H=600mm (5pcs) 95ASE1480 SG-LS 750 Lens Shield H=750mm (5pcs) 95ASE1490 SG-LS 900 Lens Shield H=900mm (5pcs)

  • Page 96: Protective Stands

    SG4 EXTENDED INSTRUCTION MANUAL 15.6 PROTECTIVE STANDS MODEL DESCRIPTION L (mm) CODE SG-PSB 600 Protective stand H=600mm 95ASE2240 SG-PSB 1000 Protective stand H=1000mm 1000 95ASE2250 SG-PSB 1200 Protective stand H=1200mm 1200 95ASE2260 SG-PSB 1650 Protective stand H=1650mm 1650 95ASE2270 SG-PSB 1900 Protective stand H=1900mm 1900 95ASE2280...

  • Page 97: Plate For Protective Stands

    ACCESSORIES 15.7 PLATE FOR PROTECTIVE STANDS MODEL DESCRIPTION CODE Plate kit for SG-PSG SG-P 95ASE2290 15.8 TEST PIECE MODEL DESCRIPTION CODE TP-14 Test piece Ø 14mm L = 300mm 95ACC1630 TP-30 Test piece Ø 30mm L = 300mm 95ACC1650...

  • Page 98: Sg4-Dongle Ethernet Adaptor

    SG4 EXTENDED INSTRUCTION MANUAL 15.9 SG4-DONGLE ETHERNET ADAPTOR MODEL DESCRIPTION CODE SG4-DONGLE ETHERNET ADAPTOR 95ASE2080...

  • Page 99: Safety Relay

    ACCESSORIES 15.10 SAFETY RELAY The drawings show the connection between the safety light curtain and the type 4 safety relay of the SE-SR2 series operating in the automatic Restart mode(on the left) and manual Restart mode with monitoring (on the right). MODEL DESCRIPTION CODE...

  • Page 100: Connection Cables

    SG4 EXTENDED INSTRUCTION MANUAL 15.11 CONNECTION CABLES MODEL DESCRIPTION CODE CS-A1-03-U-03 5-pole M12 cable (axial) UL2464 95ASE1170 CS-A1-03-U-05 5-pole M12 cable (axial) UL2464 95ASE1180 CS-A1-03-U-10 5-pole M12 cable (axial) 10 m UL2464 95ASE1190 CS-A1-03-U-15 5-pole M12 cable (axial) 15 m UL2464 95ASE1200 CS-A1-03-U-25 5-pole M12 cable (axial)
  • Page 101 ACCESSORIES RX BLANKING - PIG-TAIL CABLE This is the Pig-Tail cable that must be used for RX UNIT of SG4 EXTENDED when you configure it in BLANKING MODE and DON’T USE SG4 DONGLE. It has a 18 poles socket in one side and a M12 12 poles in the other RX MUTING - PIG-TAIL CABLE This is the Pig-Tail cable that must be always used for RX UNIT SG4 EXTENDED when you configure...
  • Page 102 SG4 EXTENDED INSTRUCTION MANUAL Cascade cables MODEL DESCRIPTION CODE CS-F1-80-B-01 SG EXTENDED CASCADE 1m 95A252840 CS-F1-80-B-005 SG EXTENDED CASCADE 0,5m 95A252850 MODEL DESCRIPTION CODE CS-F1-80-B-0005 SG EXTENDED CASCADE 0,05m 95A252860...

  • Page 103: Muting Arms

    ACCESSORIES 15.12 MUTING ARMS The SG4 EXTENDED series light curtains can be equipped with retro-reflective muting arms to obtain the “T” or “L” configuration. The following figures show, respectively, the dimensions of single active arms, of single passive arms, and the corresponding fixing bracket stand alone. MODEL DESCRIPTION CODE...
  • Page 104 SG4 EXTENDED INSTRUCTION MANUAL The following figures show, respectively, the dimensions of single active arms with fixing bracket mounted, of single passive arms with fixing bracket mounted, of double active arms with fixing bracket mounted, of double passive arms with fixing bracket mounted. ACTIVE/PASSIVE ARMS L ACTIVE/PASSIVE ARMS T MODEL...
  • Page 105 ACCESSORIES SG4 EXTENDED + BRACCI ATTIVO/PASSIVO L SG4 EXTENDED + BRACCI ATTIVO/PASSIVO T...

  • Page 106: Glossary

    GLOSSARY ELECTROSENSITIVE PROTECTIVE EQUIPMENT (ESPE): assembly of devices and/or components working together to activate the protective disabling function or to detect the presence of something and including at least: a sensor, command/control devices and output signal switching devices. PROTECTED AREA: area where a specified test object is detected by the ESPE. SAFETY LIGHT CURTAIN: it is an active optoelectronic protective device (AOPD) including an integrated system consisting of one or several emitting elements and one or several receiving elements forming a detection area with a detecting capacity specified by the...
  • Page 107 EMITTER: unit emitting infrared beams, consisting of a set of optically-synchronised LEDs. The emitting unit, combined with the receiving unit (installed in the opposite position), generates an optical “curtain”, i.e. the detecting area. START INTERLOCKING DEVICE (= START): device preventing machine automatic start if the ESPE is live or the voltage is disabled and enabled once again.
  • Page 108 www.datalogic.com...
