INCLUDED ACCESSORIES
Remote control and two AAA batteries
+ +
Align the stand column with the stand
A
base, then secure the column to the base
with the four provided (ST4 × 16 mm)
Stand column
screws (the long screws).
Stand base
ST4 screws (16 mm length) (4 pcs.)
M5 screws (12 mm length) (4 pcs.)
FEATURES
Power cord
WALL MOUNT ACCESSORIES
M6 screws (45 mm length)(4 pcs.)
Spacers(4 pcs.)
FIND YOUR USER GUIDE ONLINE!
Go to www.insigniaproducts.com, then click
Support & Service. Enter NS-55D420NA16
in the box under Manual, Firmware, Drivers &
►
Product Information, then click
.
USB
Roku Ready®
Your TV is certified to work with the Roku
Streaming Stick™. Instantly stream 1000+
entertainment channels, including Netflix,
Hulu Plus, Pandora, and more. Connect the
Streaming Stick (not included) to the purple
MHL jack on your TV and enjoy.
STOP
Do not plug your power cord in until all other
devices have been connected.
START HERE
1
How do I attach the stand to my TV? (not for wall mounting)
You'll need: Soft surface and Phillips screwdriver
B
Carefully place your TV face-down on a
cushioned, clean surface.
C
Align the screw holes on the stand column
with the screw holes on the back of your TV.
B
A
ST4 x 16 mm screws
C
Remote control sensor
Power indicator
AV IN
L
- AUDIO -
R
P
P
COMPONENT IN
HDMI1/ARC
Before using your new product, please read these
instructions to prevent any damage.
D
Secure the stand column to your TV with
the four provided M5 × 12 mm screws
(the short screws).
D
M5 x 12 mm screws
Front
MAKING CONNECTIONS
2
How do I watch TV (cable, satellite, or antenna) or connect a device such as a DVD or Blu-ray disc player, game
console, Roku Streaming Stick™, MHL-enabled device, or tablet?
WHICH CABLES
DO YOU HAVE?
HDMI
(BEST)
Best video quality
HDMI1/ARC
COMPONENT
Note: The component and AV jacks are shared. This means you can connect
(BETTER)
only one component or AV device at a time. We suggest upgrading to HDMI
(BEST)
if your device supports it.
OR
P
AV
(GOOD)
COMPONENT IN
Note: Connect the yellow
video cable to the
green VIDEO/Y jack.
COAXIAL
AV IN
(GOOD)
DIGITAL
L
AUDIO
R
-
-
VIDEO / Y
P
P
B
R
OUTPUT
COMPONENT IN
(OPTICAL)
Quick Setup Guide
WALL MOUNT
How do I prepare my TV for wall mounting? (not for use with a TV stand)
You'll need: Soft surface and Phillips screwdriver
A
Carefully place your TV face-down on a cushioned, clean surface.
B
Insert four spacers (provided) into the mount screw holes on the back of your TV, then attach the
OR
wall-mount bracket to your TV using either the four M6 × 45 mm screws (provided) or the screws
that came with the wall-mount bracket. See instructions that came with the wall-mount bracket
for information about which screws to use and how to correctly hang your TV.
Warning: This apparatus is intended to be supported by a UL Listed wall-mount bracket.
See the instructions that came with your wall mount for more information about how to correctly
C
mount your TV.
B
A
C
Your TV has four VESA mounting holes on the back. If you attach
a wall-mount bracket to the back of your TV, the bracket must
be securely attached, using all four holes. If you do not use
all four mounting holes, your TV may fall and cause property
damage or personal injury. See the documentation that
came with your wall mount for complete mounting instructions.
Multi-purpose jacks: You can plug any device that uses HDMI into any HDMI jack. However,
certain devices must be connected to the ARC or MHL jacks. See the instructions that came
with your Roku® Streaming Stick™ or ARC or MHL-enabled device for more information.
AUDIO/VIDEO OUT
AV IN
L
R
- AUDIO -
P
ANT/CABLE
IN
|
NS-55D420NA16
55" 1080P • 60Hz LED TV
AUDIO/VIDEO OUT
CABLE
