- Page 1 USER GUIDE 48" 1080p 60Hz LED TV 55" 1080p 60Hz LED TV NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 Before using your new product, please read these instructions to prevent any damage.
-
Page 2: Table Of Contents
Contents CHILD SAFETY ............. . . 1 Important Safety Instructions . - Page 3 Contents Connecting a home theater system with multiple devices ....25 Connecting power ............26 Using the remote control .
- Page 4 One-year limited warranty - Insignia Televisions—US and Canada ... . 65 One-year limited warranty - Insignia Televisions—Mexico ....66...
-
Page 5: Child Safety
CHILD SAFETY PROPER TELEVISION PLACEMENT MATTERS THE CONSUMER ELECTRONICS INDUSTRY CARES Manufacturers, retailers and the rest of the consumer electronics industry are committed to making home entertainment safe and enjoyable. As you enjoy your television, please note that all televisions - new and old- must be supported on proper stands or installed according to the manufacturer's recommendations. -
Page 6: Important Safety Instructions
NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 Important Safety Instructions 14 Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or CAUTION objects have fallen into the apparatus, the... -
Page 7: Caution
Replacement parts 1 Antenna lead-in wire When replacement parts are required, make sure that the service technician uses replacement parts 2 Grounding clamp specified by the manufacturer that have the same Antenna discharge characteristics as the original part. Unauthorized unit substitutions may result in fire, electric shock, personal injury, or other hazards. -
Page 8: Introduction
NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV 48"/55" 1080p 60Hz LED TV Introduction INlink Enjoy the benefit of having HDMI CEC compatible products plug and play! No setup is needed! CEC Congratulations on your purchase of a high-quality technology lets different devices discover and Insignia product. - Page 9 48"/55" 1080p 60Hz LED TV 2 Make sure that the arrows on the bottoms of the stands point toward the front of the TV. Align the screw holes on the TV stands with the holes on the bottom of your TV, then secure each stand with two of the provided screws. Screw type Screw length # of screws...
-
Page 10: Installing A Wall-Mount Bracket
NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV Installing a wall-mount bracket Warnings • Your TV has four VESA mounting holes on the back. If you attach a wall-mount bracket to the back of your TV, the bracket must be securely attached, using all four holes. If you do not use all four mounting holes, your TV may fall and cause property damage or personal injury. - Page 11 48"/55" 1080p 60Hz LED TV 3 Insert the four provided spacers into the mount screw holes on the back of your TV. 48" 55" 4 Attach the wall-mount bracket to your TV using either the four provided M6 × 30 mm screws or the screws that came with the wall-mount bracket.
-
Page 12: Tv Components
NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV TV components Front Your TV has several sets of jacks for connecting devices to your TV. This section contains information about: • Package contents • Side jacks • Remote control Package contents • 48" or 55" LED TV •... -
Page 13: Side Jacks
48"/55" 1080p 60Hz LED TV Side jacks Item Description Connect an HDMI device to this jack. For more information, see HDMI (best) on pages 12, 16, or Connecting a computer 6 HDMI1/ARC page 20. Connect an ARC-enabled home theater receiver to this jack. Connect a USB flash drive to this jack to view compatible JPEG picture files. -
Page 14: Remote Control
NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV Remote control Button Press to... GAME Change the picture mode to Game mode. Select the picture mode. You can select Vivid, Standard, Energy Savings, Movie, Game, or Custom. See the PICTURE Picture Mode option in Adjusting the TV picture page 38. -
Page 15: What Connection Should I Use
48"/55" 1080p 60Hz LED TV What connection should I Connection type and Cable connector use? jack Your TV has several connection types for connecting Optical digital devices to your TV. audio output For the best video quality, you should connect a device to the best available connection. -
Page 16: Connecting A Cable Or Satellite Box
NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV Connecting a cable or satellite box Many cable or satellite TV boxes have more than one connection type. To get the best video, you should use the best connection type available. For more information, see What connection should I use? on page 11. -
Page 17: Av (Good)
48"/55" 1080p 60Hz LED TV AV (good) Note Cables are often color-coded to match color-coded jacks. Side of TV On your TV Cable wall jack AV cable Audio cable connector connectors Cable or satellite box AV cable AV jack Analog audio jacks 1 Make sure that your TV’s power cord is unplugged and all connected devices are turned off. -
Page 18: Coaxial (Good)
NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV Coaxial (good) Side of TV On your TV Coaxial cable Cable or satellite box Coaxial cable connector ANT/CABLE IN jack Cable wall jack 1 Make sure that your TV’s power cord is unplugged and all connected devices are turned off. -
Page 19: Connecting An Antenna Or Cable Tv (No Box)
48"/55" 1080p 60Hz LED TV Connecting an antenna or cable TV (no box) Side of TV Antenna or cable TV (no box) On your TV Coaxial cable connector Coaxial cable ANT/CABLE IN jack 1 Make sure that your TV’s power cord is unplugged and all connected devices are turned off. 2 Connect a coaxial cable (not provided) to the ANT/CABLE IN jack on your TV and to the antenna or cable TV wall jack. -
Page 20: Connecting A Dvd Or Blu-Ray Player
NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV Connecting a DVD or Blu-ray player Many DVD or Blu-ray players have more than one connection type. To get the best video, you should use the best connection type available. For more information, see What connection should I use? on page 11. -
Page 21: Av (Good)
48"/55" 1080p 60Hz LED TV AV (good) Notes Cables are often color-coded to match color-coded jacks. Side of TV On your TV DVD or Blu-ray player AV cable Audio cable connector connectors AV jack Analog audio jacks AV cable 1 Make sure that your TV’s power cord is unplugged and the DVD or Blu-ray player is turned off. 2 Connect an AV cable (not provided) to the VIDEO jack and L and R AUDIO jacks on your TV and to the AV OUT jacks on the DVD or Blu-ray player. -
Page 22: Connecting A Game Console
NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV Connecting a game console You can connect a game console using: • HDMI (best) • AV (good) HDMI (best) Side of TV Game console On your TV HDMI cable connector HDMI cable HDMI jack 1 Make sure that your TV’s power cord is unplugged and the game console is turned off. -
Page 23: Av (Good)
48"/55" 1080p 60Hz LED TV AV (good) Notes Cables are often color-coded to match color-coded jacks. Side of TV On your TV Game console AV cable Audio cable connector connectors AV jack Analog audio jacks Console-specific AV cable 1 Make sure that your TV’s power cord is unplugged and the game console is turned off. 2 Connect the video and audio connectors on the game console’s AV cable (not provided) to the VIDEO jack and L and R AUDIO jacks on your TV and to the composite jack(s) on the game console. -
Page 24: Connecting A Computer
NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV Connecting a computer Side of TV On your TV Computer HDMI cable connector HDMI jack HDMI cable 1 Make sure that your TV’s power cord is unplugged and the computer is turned off. 2 Connect an HDMI cable (not provided) to an HDMI jack on your TV and to the HDMI OUT jack on the computer. -
Page 25: Connecting A Usb Flash Drive
48"/55" 1080p 60Hz LED TV Connecting a USB flash drive Side of TV USB flash drive 1 Plug a USB flash drive into the USB port on your TV. Caution Do not remove the USB flash drive or turn off the TV while using the USB flash drive. -
Page 26: Connecting Headphones
NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV Connecting headphones When you connect headphones, the TV speakers are muted. Warning Loud noise can damage your hearing. When using headphones, use the lowest volume setting on your headphones that still lets you hear the sound. -
Page 27: Connecting External Speakers Or A Soundbar
48"/55" 1080p 60Hz LED TV Connecting external speakers or a soundbar You can connect external speakers using: • Digital audio • Analog audio Digital audio Digital speaker system Side of TV On your TV Soundbar Digital optical audio cable connector Digital optical audio jack Digital optical... -
Page 28: Analog Audio
NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV Analog audio Note When you connect an analog system or soundbar to the /AUDIO OUT jack, the TV speakers are muted. Side of TV On your TV Audio cable Audio cable connector Analog speaker... -
Page 29: Connecting A Home Theater System With Multiple Devices
48"/55" 1080p 60Hz LED TV Connecting a home theater system with multiple devices DVD or Blu-ray player Cable or satellite box AV receiver Antenna or cable TV connected directly to the wall jack The connections you make depend on the video and audio jacks available on your devices. Refer to the documentation that came with your devices for connection information. -
Page 30: Connecting Power
NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV Connecting power 1 Connect one end of the power cord to the power connector on the back of your TV. 2 Connect the other end of the cord to a power outlet. Caution • Your TV should only be operated from the power source indicated on the label. -
Page 31: Using The Remote Control
48"/55" 1080p 60Hz LED TV Using the remote control Cautions • Batteries should not be exposed to excessive heat, such as sunshine, heat This section covers: registers, or fire. • Installing remote control batteries • Battery chemicals can cause a rash. If the •... -
Page 32: Programming Universal Remote Controls
NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV Programming universal remote controls Viewing universal remote control codes You can operate your Insignia TV with a new or You can view a list of universal remote control codes existing universal remote control. in the on-screen menu. -
Page 33: Turning On Your Tv For The First Time
48"/55" 1080p 60Hz LED TV Turning on your TV for the 4 Press to highlight Home Use Mode or Store Display Mode, then press ENTER. first time If you selected Store Display Mode, a message asks if you are sure you want this mode. Select OK to continue using Store Display Mode, or select The first time you turn on your TV, the Easy Setup Cancel to automatically change to Home Use... - Page 34 NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV 7 Press to select On (if your viewing area 12 If you select a preset label, press to highlight observes Daylight Saving Time) or Off (if your Next, then press ENTER. viewing area does not observe Daylight Saving Time), then press ENTER.
-
Page 35: Understanding The Basics
48"/55" 1080p 60Hz LED TV • If you select Cable from the wall or Antenna, Turning your TV on or off your TV starts scanning for channels and 1 Make sure that the power cord is connected to a displays a progress screen. power outlet. -
Page 36: On-Screen Menu Overview
NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV On-screen menu overview Settings menu (TV mode) Notes • Depending on the signal source selected, you may see different options on your screen. • Menu items that are not selectable are grayed out. Picture menu (TV mode) -
Page 37: Navigating The Menus
48"/55" 1080p 60Hz LED TV Navigating the menus Selecting a channel • Press CH+ or CH– to go to the next or previous Press MENU to open the on-screen menu. channel on the memorized channel list. • Press the number buttons to enter the channel number you want, then wait for the channel to change or press ENTER to immediately change the channel. -
Page 38: Using Inlink
NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV Using INlink 3 Press to highlight INlink, then press ENTER or . INlink lets you control HDMI CEC-compatible devices connected to the HDMI jacks on your TV using the remote control that came with your TV. -
Page 39: Turning Tv Auto Power On On Or Off
48"/55" 1080p 60Hz LED TV 4 Press to highlight Device Auto Power Off, Turning Audio Receiver on or off then press ENTER or . When INlink is turned on and you have connected an 5 Press to highlight On (turns off the HDMI CEC-compatible audio receiver to your TV, connected devices when you turn off your TV) or turning on Audio Receiver lets you use your TV’s... -
Page 40: Displaying A List Of Inlink-Compatible Devices
NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV Displaying a list of INlink-compatible devices Selecting an INlink-compatible device You can display a list of HDMI CEC devices that are When you have more than one INlink-compatible connected to your TV. device connected, you can select the device you want to use. -
Page 41: Using A Usb Flash Drive
48"/55" 1080p 60Hz LED TV Using a USB flash drive 2 Press to highlight Browse Photos, then press ENTER or . The screen displays folder names and photo files stored on the USB flash You can connect a USB flash drive to your TV to view drive in a thumbnail index with the first folder or compatible JPEG pictures. -
Page 42: Viewing Photos In A Slideshow
NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV Viewing photos in a slideshow 2 Press or ENTER to access the menu. 3 Press to highlight an option, then press You can view your photos in a slideshow. ENTER or to access the option. You can select: 1 Switch to USB mode. - Page 43 48"/55" 1080p 60Hz LED TV • Aspect Ratio—Adjusts how the picture fills • Overscan—Extends text and images past the screen. You can select: the screen edges to hide edge artifacts. You can select On or Off. Aspect ratio • Dynamic Backlight (DCR)—Enhances the Example options contrast ratio between light and dark areas of...
-
Page 44: Automatically Adjusting The Aspect Ratio
NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV Adjusting the sound Automatically adjusting the aspect ratio Auto Aspect Ratio automatically changes how the picture looks on the screen (aspect ratio) based on the This section covers: TV program you are viewing. • Adjusting sound settings 1 Press MENU. -
Page 45: Selecting The Audio Out Mode
48"/55" 1080p 60Hz LED TV • TV Speakers—Selects where to play TV audio. • Headphones / Audio Out—You can use the When you connect headphones to your TV, /AUDIO OUT jack on your TV to connect audio plays through both the headphones and headphones, a home theater system, soundbar, the TV speakers. -
Page 46: Playing Tv Audio Only
NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV Playing TV audio only 1 Press MENU. 2 Press to highlight CHANNELS, then press You can turn off the picture on your TV and listen to or ENTER. the program audio only. 1 Press MENU. -
Page 47: Hiding Channels
48"/55" 1080p 60Hz LED TV B If you select Cable from the wall your TV scans Hiding channels for available channels. The scan may take You can hide channels in the channel list. When you several minutes. press CH+ or CH–, your TV skips the hidden channels. You can still tune to a hidden channel by pressing the number buttons for the channel. -
Page 48: Setting Up A Favorite Channel List
NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV Setting up a favorite channel list Viewing a favorite channel You can create a favorite channel list so you can 1 Press MENU. quickly browse through your favorite channels, then 2 Press to highlight CHANNELS, then press selecting a channel from the favorite channel list. -
Page 49: Checking The Digital Signal Strength
48"/55" 1080p 60Hz LED TV Setting parental controls 4 Press to select the channel you want to label, then press to move to the channel label field. Parental controls let you prevent your children from watching inappropriate material on TV. When set, parental controls read the rating of the program (with some exceptions, such as news and sports) and deny access to programs that exceed the ratings level you... -
Page 50: Blocking Unrated Tv
NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV 4 Press the number buttons to enter the four-digit Blocking unrated TV password. The default password is 0000. You Some TV programs, such as news and sports shows should change the password to a number you can are not rated. -
Page 51: Setting Parental Control Levels
48"/55" 1080p 60Hz LED TV Setting parental control levels Canadian French ratings You can set parental controls for the U.S. and Canada. Exempt programming U.S. rating levels General audiences 8 ans+ Suitable for children 8 and older U.S. TV ratings 13 ans+ Suitable for children 13 and older NONE... -
Page 52: Downloading Rating Information
NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV 5 Press to highlight USA Parental Locks, Downloading rating information then press ENTER. (To set Canadian ratings, select If the program you are viewing has downloadable Canadian Parental Locks.) rating information, you can download the USA Parental Locks information to use when setting parental controls. -
Page 53: Locking The Power Button On Your Tv
48"/55" 1080p 60Hz LED TV 6 Press to select the program and 3 Press to highlight Button Lock, then press content types you want to block, then press ENTER or . ENTER. 4 Press to select On (locks the /INPUT button) or Off (unlocks the /INPUT button). -
Page 54: Selecting The Analog Closed Captioning Mode
NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV 6 Press ENTER, MENU, or to return to the previous Selecting the digital closed captioning mode menu, or press EXIT to close the menu. Digital channels usually have one or more closed captioning modes. The CC1 mode usually displays a... -
Page 55: Customizing Digital Closed Captioning Settings
48"/55" 1080p 60Hz LED TV Customizing digital closed captioning settings 6 Press to highlight an option, then press ENTER or . You can select: 1 Press MENU. • Size—Selects the font size. 2 Press to highlight SETTINGS, then press • Font—Selects the font style. or ENTER. -
Page 56: Setting The Sleep Timer
NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV 4 Press to highlight Date / Time, then press Setting the sleep timer ENTER. You can specify the amount of time before your TV automatically turns off. 1 Press MENU. 2 Press to highlight SETTINGS, then press or ENTER. -
Page 57: Adjusting Menu Settings
48"/55" 1080p 60Hz LED TV Adjusting menu settings 3 Press to highlight Auto Input Sensing, then press ENTER or . 4 Press to select On (turns on the input You can adjust how the TV menus look by: sensor) or Off (turns off the input sensor). •... -
Page 58: Maintaining
NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV 5 Press to select a preset label or select Viewing system information Custom to create your own label. You may need to view system information during 6 If you select Custom, press ENTER, then troubleshooting. -
Page 59: Updating The Tv Firmware
. 3 Follow the instructions in the Firmware Installation Guide on the Insignia website to download the firmware update and copy it to a USB flash drive. 4 Plug the USB flash drive into the USB port on your 5 Press MENU. -
Page 60: Testing The Tv Speakers
NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV Testing the TV speakers Restoring settings to the defaults You can test your TV’s speakers to make sure they are When you restore default settings, all the settings you working correctly. have customized (except parental controls) are reset. -
Page 61: Video And Audio
48"/55" 1080p 60Hz LED TV Video and audio Problem Solution Dark, poor, or no Problem Solution • Try another channel. The station picture (screen is may be experiencing problems. Picture does not lit), but sound is • Change the aspect ratio. See •... - Page 62 NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV Problem Solution Problem Solution Only snow (noise) Dotted lines or • Try another channel. The station • Make sure that the antenna or appears on the stripes appear on may be experiencing problems. cable TV is connected correctly screen.
- Page 63 48"/55" 1080p 60Hz LED TV Problem Solution Problem Solution Good picture, but Poor picture. • Increase the volume. • Make sure that the room is not no sound. • Make sure that the sound is not too bright. Light reflecting off muted.
-
Page 64: Remote Control
NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV Remote control Problem Solution After Auto Problem Solution • Reception can vary by channel Channel depending on the broadcast power Remote Search, there • Make sure that the power cord is level of a given station. Contact your... -
Page 65: Inlink (Cec-Compatible) Device
48"/55" 1080p 60Hz LED TV Problem Solution Problem Solution /INPUT My TV is not • Make sure that the Button Lock • Make sure that the HDMI cable is button does playing the option is set to Off. See Locking the connected securely to your TV and not work. - Page 66 NS-48D510NA17/NS-55D510NA17/NS-55D510MX17 48"/55" 1080p 60Hz LED TV Problem Solution Problem Solution My TV’s My TV does • Make sure that there are no • Make sure that the INlink feature is remote not turn on obstructions between the remote turned on. See...
-
Page 67: Specifications
1 (side) Digital audio 1 (optical) (side) Dimensions and weight WiFi NS-55D510NA17 Ethernet NS-48D510NA17 NS-55D510MX17 Audio 42.6 × 24.8 × 3.3 in. 48.8 × 28.2 × 3.3 in. (108.2 × 62.9 × 8.3 cm) (123.9 × 71.7 × 8.3 cm) -
Page 68: Legal Notices
See the License for the specific language operate the equipment. governing permissions and limitations under the License. If you require additional information please call the Insignia Cables support line at 1-877-467-4289. Connections to this device must be made with shielded cables with metallic RF/EMI connector hoods to maintain compliance with FCC Rules and Regulations. -
Page 69: One-Year Limited Warranty - Insignia Televisions-Us And Canada
Insignia repair center or store personnel, LOST PROFITS. INSIGNIA PRODUCTS MAKES NO OTHER EXPRESS Insignia will (at its sole option): (1) repair the Product with new or WARRANTIES WITH RESPECT TO THE PRODUCT, ALL EXPRESS AND rebuilt parts;... -
Page 70: One-Year Limited Warranty - Insignia Televisions-Mexico
ADAPTADORES LAPTOPS 1 AÑO/3 AÑOS Distrito Federal, teléfono (01) (52) (55) 88-50-20-00 para productos de la marca INSIGNIA, DYNEX, ROCKETFISH, PLATINUM y MODAL (el BOCINAS 90 DÍAS / 1 AÑO “Producto” o los “Productos”) establece las normas y condiciones de BOCINAS DE COMPUTO 1 AÑO... - Page 71 Producto sea compatible con cualquier otro Producto o combinación de productos diferentes a los Productos de la marca INSIGNIA, DYNEX, ROCKETFISH, PLATINUM y MODAL a los que el Cliente decida conectar el Producto.
- Page 72 U.S. and Canada: 877-467-4289 INSIGNIA is a trademark of Best Buy and its affiliated companies. Registered in some countries. Distributed by Best Buy Purchasing, LLC Mexico: 01800-926-3000 INSIGNIA is a trademark of Best Buy and its affiliated companies.
