Insignia Roku TV NS-43DR620NA18 Quick Setup Manual

INCLUDED ACCESSORIES
1
Remote control and two AAA batteries
+ +
A
43" 50" 55"
43"
M4 screws
(20 mm length)
(4 pcs.)
TV stands
50"
55" M6 screws
(25 mm length)
(4 pcs.)
TV stands
FEATURES
Power cord
43" 50" 55"
WHAT YOU NEED
(not included)
Phillips screw driver
FIND YOUR USER GUIDE ONLINE!
On a computer, go to www.insigniaproducts.com,
enter your model in the search box, then press
ENTER. Next to Features, click Support &
Downloads, then next to User Manual, click
the language you want.
STOP
Do not plug your power cord in until all other
devices have been connected.
Before using your new product, please read these
instructions to prevent any damage.
START HERE
How do I attach the stand to my TV? (not for wall mounting)
You'll need: Soft surface and Phillips screwdriver
Place your TV face-down on a cushioned, B Align the screw holes on the TV stands with the holes on the bottom of your TV, then secure each stand to your
clean surface. TV with the provided screws.
B
A
43"
(55" model shown)
Remote control sensor
Power indicator
AV IN
AUDIO OUT
R
L
M4 × 20 mm screws
R
50"
L
55"
MAKING CONNECTIONS
2
How do I watch TV (cable, satellite, or antenna) or connect a device, such as a DVD or Blu-ray disc player, game console, or tablet?
WHICH CABLES
DO YOU HAVE?
HDMI
(BEST)
Best video quality
RESET
AV
(GOOD)
COAXIAL
(GOOD)
Quick Setup Guide |
NS-43DR620NA18/NS-50DR620NA18/NS-55DR620NA18
43" / 50" / 55" UHD (4K) • LED TV
WALL MOUNT
How do I prepare my TV for wall mounting?
(not for use with a TV stand)
You'll need: Soft surface and Phillips screwdriver
OR A Carefully place your TV face-down on a cushioned, clean surface.
B See the instructions that came with your wall mount for
more information about how to correctly mount your TV.
C Your TV has wall-mount screws installed in the VESA mounting
holes on the back of your TV. Remove the screws, place the
wall-mount bracket (not included) over the screws holes, then
replace the screws to secure the bracket to your TV.
A
B
M6 × 25 mm screws
Multi-purpose jacks: You can plug any device that uses HDMI into either HDMI jack.
However, certain devices must be connected to the ARC jack. See the instructions
that came with your ARC device for more information.
AV IN
AV IN
C
Your TV has four VESA mounting holes on the back. If you attach a wall-mount
bracket to the back of your TV, the bracket must be securely attached, using
all four holes. If you do not use all four mounting holes, your TV may fall and
cause property damage or personal injury. See the documentation that came
with your wall-mount for complete mounting instructions.
AUDIO/VIDEO OUT
CABLE
