OPERATING INSTRUCTIONS
Automatic welding machine LARON Version 2.1
Please read the operating instructions carefully before use and keep for further reference!
Before start-up these operating instructions must be examined carefully because we will not
assume any liability for any failures resulting from improper use.
APPLICATION
The Laron is an automatic welding machine for overlap welding of roofing membranes made
of PE, PVC, TPO, ECB, EPDM, CSPE and bitumen. The machine can also be used in areas
close to edges and on uneven surfaces.
TECHNICAL DATA
Voltage
Frequency
Power consumption
Power regular operation
Drive
Welding temperature
Air flow
Size LxWxH
Weight
VAC
Hz
W
W
m/min.
°C
%
mm
kg
BAK Thermoplastic Welding Technology AG
230
50/60
4100
2500
0.5-7 stepless
30-620 stepless
60-100
610x410x320
39
400
50/60
6000
4200
0.5-7 stepless
30-620 stepless
60-100
610x410x320
39
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for BAK LARON
Summary of Contents for BAK LARON
- Page 1 APPLICATION The Laron is an automatic welding machine for overlap welding of roofing membranes made of PE, PVC, TPO, ECB, EPDM, CSPE and bitumen. The machine can also be used in areas close to edges and on uneven surfaces.
-
Page 2: Security Warning
Only use the automatic welding machine if in technically perfect condition and for the purposes for which they are intended while observing the operating instructions. The tool can be used for the applications mentioned in the present operating instructions only! BAK Thermoplastic Welding Technology AG... -
Page 3: Extension Cords
Push the guide roller downward and fix it with the hexagon nut on the threaded bar. Outside edge of the overlap, outside edge of pressure roll and outside edge of guide roller must form a line. (see following sketch). BAK Thermoplastic Welding Technology AG... -
Page 4: Controller Adjustment
“OFF” und unplug the mains plug. GUARANTEE AND LIABIITY For BAK guarantee and liability see the general and sales condition on the back of the invoice paper. For the neglect or for damages resulting from it, the manufacturer / supplier will not accept any liability. -
Page 5: Service And Repairs
Do not use the automatic welding machine if the connecting line or the plug is damaged, repairs have to be done by the manufacturer or authorised service personnel. For after-sales service and orders please contact: BAK Thermoplastic Welding Technology AG Industriestrasse 6 CH-6064 Kerns / Switzerland... - Page 6 DV 159 DV 089 DV 084 DV 088 DV 209 D - 2286 DV 111 DV 112 DV 098 DV 103 DV 218.1 DV 142 DV 212.1 DV 220 DV 219 DV 211.1 DV 215 BAK Thermoplastic Welding Technology AG...
- Page 7 DV 146 DV 012 DV 114 DV 136 DV 153 DV 156 DV 136 DV 059 DV 069 DV 068 DV 137 DV 042 DV 013 DV 029 DV 063 DV 146 DV 023 DV 045 BAK Thermoplastic Welding Technology AG...
- Page 8 Art. no. Description Art. no. Description 6600062 Eron 230V Laron complete 6601161 Sprocket wheel clamp (DV114) 6600063 Eron 400V Laron complete 6601254 Countersunk screw, M6x16 DIN7991 (DV123) 6601246 O-ring 19x3.5 DIN3771 (D-1079) 6601162 Cheese head screw, M6x20, DIN912(DV124) 6601111 Pressure spring (DV001)
- Page 9 ERON 230V/400V BAK Thermoplastic Welding Technology AG...
- Page 10 Spare parts list Eron 230V/400V Art. No. Description Qty. 5101270 Gasket 70x48x4 5101274 Mica tube 47.6x134 5107612 Heating element Laron 230V 5107613 Heating element Laron 400V 5108222 Overlap welding nozzle 40mm 5112693 Thermocouple 6100284 Countersunk screw M4x12 TX 6100287 Hexagon nut M5...
- Page 11 BAK Thermoplastic Welding Technology AG...
