Summary of Contents for Planet NVR-3685
-
Page 2: Front Panel
1. Packet Contents VERIFY THE CONTENTS INSIDE THE PACKAGE BOX The package should contain the following items plus the NVR-3685. If any item is missing or damaged, please contact the seller immediately. Quick Installation Guide x 1 Screw Packet x 1... - Page 3 3. Hardware Installation Accessories Check Screw Pack Accessories Pack 6-32UNC Silver Screws M4 x 8 Flat Head Screws SATA CABLE x 8 pcs (32 pcs) (6 pcs) HDD Installation Remove all the screws from the cover Lift the cover up to remove it. of the NVR.
- Page 4 Install the hard drives on the fixed First place back the bottom fixed plates plates with screws. of hard drives. Latch the fixed plates of hard drives Place back the top fixed plates of hard and case with screws. drives on the other.
- Page 5 Connect the SATA cable to the hard Put the cover back. drives. Latch the rack mounting ears on the Assemble all the screws to the case. case with screws. The HDDs have been completely assembled. - 4 -...
- Page 6 Installing “Planet IP Wizard II” search utility from PLANET Website: http://www.planet.com.tw/en/support/download.php?type1=8&model=48864&type=8184#list 1. Please go to Start Programs PLANET IP Wizard II PLANET IP Wizard II to run the search tool. Then you will see the utility start searching the network.
- Page 7 5. Customer Support You can browse our online FAQ resource and User’s Manual on PLANET Web site first to check if it could solve your issue. If you need more support information, please contact PLANET surveillance support team. PLANET online FAQ: http://www.planet.com.tw/en/support/faq.php?type=1...
