Instruction Manual
Form 1111
September 2015
1301 Series High-Pressure Regulators
WARNING
!
Failure to follow these instructions or
to properly install and maintain this
equipment could result in an explosion,
fire and/or chemical contamination
causing property damage and personal
injury or death.
Fisher
regulators must be installed,
®
operated and maintained in accordance
with federal, state and local codes, rules
and regulations and Fisher instructions.
If the regulator vents gas or a leak
develops in the system, service to the unit
may be required. Failure to correct trouble
could result in a hazardous condition.
Installation, operation and maintenance
procedures performed by unqualified
personnel may result in improper
adjustment and unsafe operation. Either
condition may result in equipment
damage or personal injury. Use qualified
personnel when installing, operating
and maintaining the 1301 Series high-
pressure regulator.
Introduction
Scope of the Manual
This Instruction Manual provides instructions for the
installation, adjustment, maintenance and parts ordering
of the Types 1301F and 1301G high-pressure regulators.
Product Description
Types 1301F and 1301G regulators are direct-operated,
high-pressure regulators, which can be used where
high-pressure gas must be reduced for use as pilot
supply pressure in pilot-operated regulators or as
loading pressure in pressure-loaded regulators.
Types 1301F and 1301G
P1025
Figure 1. Type 1301F High-Pressure Regulator
Types 1301F and 1301G regulators can also be used
in many other applications due to their rugged design
as high-pressure reducing regulators for various fluids
such as air, gas, water and other liquids.
The Type 1301F can handle outlet pressures from 10 to
225 psig / 0.69 to 15.5 bar in three ranges and the
Type 1301G can handle outlet pressures from 200 to
500 psig / 13.8 to 34.5 bar in one range.
www.fisherregulators.com

Advertisement

loading

  Related Manuals for Emerson 1301G

  Summary of Contents for Emerson 1301G

  • Page 1 This Instruction Manual provides instructions for the installation, adjustment, maintenance and parts ordering of the Types 1301F and 1301G high-pressure regulators. Types 1301F and 1301G regulators can also be used in many other applications due to their rugged design Product Description as high-pressure reducing regulators for various fluids such as air, gas, water and other liquids.
  • Page 2: Specifications

    Types 1301F and 1301G Specifications Specifications section lists the specifications for Types 1301F and 1301G high-pressure regulators. The maximum outlet pressure for a given regulator as it comes from the factory is stamped on the regulator nameplate. Available Configurations IEC Sizing Coefficients Type 1301F: Direct-operated, high-pressure reducing : 0.938...
  • Page 3: Principle Of Operation

    Types 1301F and 1301G Type 1301F CONTROL SPRING DIAPHRAGM DISK HOLDER VALVE DISK SPARE DISK INLET PRESSURE OUTLET PRESSURE ATMOSPHERIC PRESSURE VALVE SPRING BOTTOM CAP M1015 INLET PRESSURE OUTLET PRESSURE ATMOSPHERIC PRESSURE Figure 2. Type 1301F Operational Schematic Table 1. Outlet Pressure Ranges...
  • Page 4: Installation

    Type 1301F regulator has one 1/4 NPT internal according to the Maintenance section. connection. The Type 1301G regulator spring case has one 1/8 NPT internal connection with a screen. To Shutdown remotely vent the spring case, remove the screen, if...
  • Page 5: Maintenance

    To avoid personal injury or equipment are shown in Figure 3 for the Type 1301F regulator damage from sudden release of pressure and in Figure 4 for the Type 1301G regulator unless or explosion of accumulated gas, do not otherwise indicated.
  • Page 6 Types 1301F and 1301G NOTE: OPTIONAL THIRD OUTLET CD3923_F Figure 3. Type 1301F High-Pressure Regulator Assembly BP6341-A CN7095_C Figure 4. Type 1301G High-Pressure Regulator Assembly Figure 5. Exploded View of The Diaphragm Head Assembly and Yoke...
  • Page 7: Parts Ordering

    1E8220X0012 Type 1301F Stainless steel 1E8220X0212 Brass Stainless steel Standard or with T-Handle 1D383113012 (For Type 1301G Cold Temperature) 1E8220X0022 Stainless steel With 1/4 NPT vent connection 22B0753X012 *Recommended spare part. Monel and Inconel are trademarks of Special Metals Corporation.
  • Page 8 For further information visit www.fisherregulators.com The Emerson logo is a trademark and service mark of Emerson Electric Co. All other marks are the property of their prospective owners. Fisher is a mark owned by Fisher Controls International LLC, a business of Emerson Process Management.
