1.3

Standards compliance

CSMIO/IP-M controllers were designed and made in accordance with the national and international
standards for industrial control systems based on electronic components:
Detailed requirements for programmable controllers: working characteristics, shock resistance,
•
safety etc. EN61131-2 (IEC1131-2), CSA 22.2, UL508
Compliance with European Guidelines (low voltage, the level of electromagnetic interference
•
Electromagnetic Compability), the CE marking.
• Electrical and non-combustible properties of insulation materials: UL 746C, UL 94, etc.
The Product made in lead-free technology, RoHS compliant.
•
1.4

Specification

Digital inputs
Digital outputs
Relay outputs
Analog inputs
Analog outputs
Supply voltage
Power consumption
Maximum I/O Voltage
Maximum output line load
Analog Input Voltage
Analog Output - Maximum Load
Axis Drives control type
Maximum frequency of the STEP signal
STEP Signal Duty Cycle
PC communications
Ambient temperature range
Relative Humidity (Non-Condensing)
The STEP outputs signal frequency is in no way limited by the „Kernel speed" settings in Mach3 program.
While using the CSMIO/IP-M controller this Mach3's configuration parameter is unused and can be set at
any value.
C S - L a b s . c . – C N C C S M I O / I P - M c o n t r o l l e r
Parameter Value
12
4
2
2
2
24VDC +/-10%
5W
30VDC
250mA
0-10VDC
5mA
(STEP/DIR)
125kHz
50%
Ethernet 10/100Mb
o o
0 C to +60 C
10% to 95%
(without condensation)
