Page 1
PB270Q Wired Adjustable Base Owner Manual CONTENTS Advisory Setup and Installation Wired Hand Control 1-2-20 year Warranty Manufactured by I nnova S leep Systems 1- 1 4...
Page 2
WARNING Attention: Read the following information before using this product . Failure to use a surge protection device could compromise safety or cause product malfunction and could void the electrical portion of your warranty. Electrical surges are by far the biggest cause of problems with electrical circuits.
Page 3
PRODUCT RATINGS: The bed lift motors are not designed for continuous use of more than 2 minutes in an 18 minutes period, or approximately 10% duty cycle. Any attempt to circumvent or exceed this rating will shorten the life expectancy of the product and may void the warranty. WEIGHT UNITS: The limitation for this adjustable bed is 750 lbs.
Page 4
SETUP and INSTALLATION Important: We strongly recommend two able-bodied adults to setup and assemble this product. Step 1: Check and verify all parts are included before discarding any packing materials. Step 2: With the help of your able-bodied assistant, place carton on floor with arrows pointing downwards .
Page 5
Step 4: Unplug the Power Cord. ④ Install the six legs firmly into the base of the frame. The legs screw into the threaded holes in each corner of the adjustable base frame. (See Page 13). -Do not over tighten Step 5: With the help of your able-bodied assistant, carefully lift the adjustable bed frame and set it in place upright on its legs.
Page 6
Please Note : Put the bed base on the side before assembling it . ① Wired Remote B O X A #PB270Q Adjustable Bed ② Head Up Head Down ③ 6-1 4 11-14...
Page 7
INNOVA SLEEP PRODUCT Assembly Instruction 1, 2 & 20 YEAR LIMITED WARRANTY Innova Sleep Systems, Inc. (“Innova”) warrants this adjustable bed This product includes two boxes with box A and to the consumer who is the original purchaser (the “purchaser”), box B.
Page 8
20 YEAR LIMITED WARRANTY of this warranty. This limited warranty does not include Upon written notice during the third year through the 20th year reimbursement for inconvenience, removal, installation, setup time, from the warranty commencement date, INNOVA will replace, upon loss of use, shipping, or any other costs of expenses, Innova and/or term and conditions set forth in this paragraph, any mechanical its service technicians shall not be responsible for moving furniture...
