955781.book : t95578.fm Seite 1 Donnerstag, September 21, 2000 2:07 PM Avensys Exposed Single Thermostat Mixing Valve 34 033 34 034 Installation Instructions and Operating Guide Please leave this document with the user after finishing installation! 95.578.131/ÄM 30 222/09.00...
955781.book : i95578gb.fm Seite 6 Donnerstag, September 21, 2000 2:07 PM Technical Data Functioning Principle Specification This Avensys mixing valve is a thermostatic • Exposed thermostatic shower mixing mixer with wax cartridge. Turning the handle valve, concealed or exposed supplies in a counter-clockwise direction opens the •...
955781.book : i95578gb.fm Seite 7 Donnerstag, September 21, 2000 2:07 PM Installation Exposed Installation In case of exposed installation with supply pipes from above or below rotate inlet The thermostatic shower mixing valve can elbows 90° and connect to 15mm supply be installed in two different ways.
Page 7
955781.book : i95578gb.fm Seite 8 Donnerstag, September 21, 2000 2:07 PM Installation 6.Mark the holes in the backplate for wall- 9. Slide the escutcheons (H) over the plugs, see Fig. [4]. supply pipes and install filters (J), see Fig. [7]. 7.Drill the holes (6mm) for the wallplugs (F) and fit them into the wall, see Fig.
Page 8
955781.book : i95578gb.fm Seite 9 Donnerstag, September 21, 2000 2:07 PM Installation Shower Hose Connection Pipe Connection 1.Close free outlet with plug (K), see 1.Close free outlet with plug (K), see Fig. [9]. Fig. [10]. ° 2.Thread the outlet nipple (L) with the O-ring seal into the valve body outlet.
955781.book : i95578gb.fm Seite 10 Donnerstag, September 21, 2000 2:07 PM Installation Adjustment 6.Check the temperature of the outflowing water with a thermometer, see Fig. [12]. The temperature of the outflowing water is factory set to 43 °C. A temperature adjust- ment is necessary if: •...
955781.book : i95578gb.fm Seite 11 Donnerstag, September 21, 2000 2:07 PM Maintenance I. Control Unit 12. Screw out screw nut (P) if replacing control unit (U). 1. Shut off hot and cold water supply! 13. Take out wax element (V), slider (W) and 2.
Page 11
3.Remove threaded ring with flow limiter (9.1) if installed. 4.Take out and replace non-return valve (9.2). Reassemble in reverse order. Only genuine GROHE replacement parts must be used. 8. Tighten set screw (D1) and compression nuts. 9. Reinstall screw (P) in control unit.
Care We want to ensure that you get long-lasting your fitting dull and scratched. As the for- satisfaction and pleasure from your GROHE mulations of commercially available cleaning fitting. Therefore, please read the following agents frequently change, we cannot gua-...
