  • Page 1 G410/G411 IMAGE SCANNER OPERATOR’S MANUAL...

  • Page 2: Safety During Operation

    Safety Information When using your machine, the following safety precautions should be always be followed Safety During Operation In this manual, the following important symbols are used: WARNING: Ignoring this warning could cause serious injury or even death. CAUTION: Ignoring this caution could cause injury or damage to property. Examples of Indications Symbol R means a situation that requires you take care.
  • Page 3 Safety Information Warnings Only connect the machine to the power source described on the inside front cover of this manual. Avoid multi-wiring. Do not damage, break or make any modifications to the power cord. Do not place heavy objects on it, pull it hard or bend it more than necessary.
  • Page 4 Safety Information CAUTION Keep the machine away from humidity and dust. A fire or an electric shock might occur. Do not place the machine on an unstable or tilted surface. If it topples over, it could cause injury. When you move the machine, unplug the power cord from the wall outlet to avoid fire or electric shock.

  • Page 5: Important Information

    Important Information Important Information 1. Read all of these instructions and keep them for later reference. 2. Follow all warnings and instructions marked on the machine. 3. Unplug this machine from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.
  • Page 6 13. Unplug this machine from the wall outlet and refer servicing to qualified service personal under the following conditions; A. When the power cord or plug is damaged or frayed. B. If liquid has been spilled into the machine. C. If the machine has been exposed to rain or water. D.

  • Page 7: How To Read This Manual

    How to Read This Manual How to Read This Manual In this manual, the following symbols are used: Warning This symbol indicates a potentially hazardous situation that might result in death or serious injury when you misuse the machine without following the instructions under this symbol. Be sure to read the instructions, all of which are described in the Safety Information section.

  • Page 8: Table Of Contents

    Ultra-fast scanning ---------------------------------------------------------------- 1 Simultaneous scanning of both sides of a document --------------------------- (Duplex Model only) ----------------------------------------------------------- 1 Direct operation using the buttons on the scanner ------------------------------ (Manual Scanning function) ------------------------------------------------------ 1 Large 150-sheet paper capacity -------------------------------------------------- 1 Printing on scanned documents (optional) -------------------------------------- 1...
  • Page 9 Table of Contents 3. Setting Originals Originals ---------------------------------------------------------------------------------- 17 Recommended Sizes and Weights of Originals -------------------------- 17 Difficult to Detect Sizes ----------------------------------------------------------- 18 Original Sizes and Scanning Area -------------------------------------------- 19 Setting Originals ----------------------------------------------------------------------- 20 Setting the Original on the Contact Glass ----------------------------------- 20 Setting the Original in the Auto Document Feeder (ADF) -------------- 21 4.
  • Page 10 Cleaning the Feed Roller and Drum ------------------------------------------- 34 Cleaning the White Roller (Duplex Model Only) ---------------------------- 36 Moving the Scanner -------------------------------------------------------------- 38 Carrying the Scanner a Short Distance ---------------------------------------- 39 Shipping the Scanner ------------------------------------------------------------ 39 Disposing of the Scanner ------------------------------------------------------- 39...

  • Page 12: Introduction

    If using a driver that supports the Manual Scanning function, scanning can be initiated by pressing the {Start} button on the scanner. This function is useful when scanning a document that needs to be set in place for each scan.

  • Page 13: Space-Saving Design

    This scanner is designed in a “wingless” style, in which there are no protruding elements, such as a document tray. This design allows the scanner to be set up next to a wall, and permits office space to be used more effectively.

  • Page 14: Guide To The Scanner

    Auto Docu- ment Feeder (ADF). 7. Power Switch This switch is used to turn the scanner power on and off. 8. { { { { { Clear Modes} } } } } Button This button is used to stop manual scan- ning.
  • Page 15 These switches are used to set the operat- ing mode. 9. Reset Switch This switch resets the scanner as if the power had been turned off and then back on again. This switch is used to make new DIP switch and rotary switch set- tings valid.

  • Page 16: Understanding The Indicators

    3: Document in Place 4: Error When the scanner is in a normal operating state, the indicators will light in one of the combina- tions shown below. If the indicators light in any other pattern, an error has occurred. Refer to p.
  • Page 17 1. Introduction...

  • Page 18: Setting Up The Scanner

    2. Setting up the Scanner This chapter explains the preparations that are necessary in order to use the scanner. Preparing for Installation Checking the Scanner Location Set up the scanner in a location that satisfies the following conditions: Setup location...
  • Page 19 2. Setting up the Scanner Installation space Set up the scanner in a location where there is enough space to provide the clearance shown in the figure below. Installation environment Important Do not set up the scanner in any of the types of locations listed below. Doing so could cause the scanner to malfunction.
  • Page 20 Set up the scanner in a location where the temperature and humidity will fall within the ranges shown below. Usable range 50 F 80% F 15% Usable range Important Save the box and cushioning material in which the scanner was packed so that they can be used if it is necessary to transport the scanner in the future.

  • Page 21: Connecting To The Host Computer

    Connecting to the Host Computer This scanner connects to a host personal computer through a SCSI interface. This section provides an overview of SCSI, and explains how to connect the scanner to a host computer. What is SCSI? “SCSI” (Small Computer System Interface)

  • Page 22: Setting The Scsi Id

    Use SCSI cables to connect the per- sonal computer and the peripheral de- vices in daisy chain fashion, with this scanner at the end of the daisy chain. (Use either of the two SCSI connec- tors on the scanner.) C C C C C Set DIP switch 3 to off.

  • Page 23: Connecting The Scsi Cable (Connection To Other Port)

    B B B B B Use SCSI cables to connect the per- sonal computer and the peripheral de- vices in daisy chain fashion, with this scanner in the middle of the daisy chain. C C C C C Set DIP switch 3 to on.

  • Page 24: Connecting The Power Cable

    Connecting the Power Cable This section explains how to connect the power cable to the scanner. Warning Only connect the machine to the power source described on the inside front cover of this manual. Avoid multi-wiring. Do not damage, break or make any modifications to the power cord.
  • Page 25 2. Setting up the Scanner B B B B B Push the power cable plug all of the way into the power connector on the scanner. Note Use the power cable that was provided with this scanner. C C C C C...

  • Page 26: Turning On/Off The Scanner Power

    Turning On/Off the Scanner Power Turning On the Scanner Power When turning on the power, turn on each device in the daisy chain one by one, starting from the device that is at the opposite end of the daisy chain away from the host computer and working towards the host computer.

  • Page 27: Initializing The Scanner

    Using an object with a thin tip, such as a ballpoint pen, press the reset switch located on the back of the scanner. Doing so puts the scanner into the same state as if the power had been turned off and then back on again.

  • Page 28: Setting Originals

    This section explains how to set originals that are to be scanned in the scanner. Originals can be set either on the contact glass or in the Auto Document Feeder (ADF). The Auto Document Feeder (ADF) is useful when you want to scan multiple originals consecutively.

  • Page 29: Difficult To Detect Sizes

    When the optional Image Processing Unit Type A is installed, the scanner can automatically detect the size of an original. However, the sizes of the following types of originals are difficult to detect properly, even if using a scanner driver that supports automatic detection of the size of the original:...

  • Page 30: Original Sizes And Scanning Area

    Original sizes that can be detected automatically Original size Paper sizes used in Japan A 3 B 4 A 4 A 4 B 5 B 5 A 5 A 5 B 6 B 6 A 6 K K K L K L K L K L K Where original is placed Contact glass...

  • Page 31: Setting Originals

    3. Setting Originals Setting Originals Setting the Original on the Contact Glass Caution Be careful not to pinch your fingers when closing the Auto Document Feeder (ADF). A A A A A Open the Auto Document Feeder (ADF). B B B B B With the side to be scanned facing down, place the original on the contact glass, and align it with the home position and scale.

  • Page 32: Setting The Original In The Auto Document Feeder (Adf)

    ) " Limitation When the original has a dark background, the scanner may not be able to recognize that a document has been placed in the ADF. If this happens, place the document on the contact glass instead.
  • Page 33 3. Setting Originals Note When scanning an original that is A5K(HLTK) size or smaller, pull the stopper out of the output table, turn it around, slide it back into the table, and adjust the position. (Refer to the diagram below.) Important When the stopper is extended, do not grasp the stopper when opening or closing the Auto Document Feeder (ADF).
  • Page 34 C C C C C Fan the sheets, and then line up their edges. D D D D D With the first page facing up on top, place the originals in the Auto Document Feeder (ADF), and adjust the positions of the guides so that they touch the edges of the original.
  • Page 35 3. Setting Originals...

  • Page 36: Scanning Originals

    4. Scanning Originals General Scanning Method Scanning of an original is initiated by software that is TWAIN or ISIS compatible. The method of operation depends on the software. For details, refer to the manual that was supplied with your software. Limitation When using double-sided scanning, if the leading edge of the reverse side of the document is dark, the scanned image may appear whitish.

  • Page 37: Manual Scanning

    4. Scanning Originals Manual Scanning By setting up a scanner driver that supports the manual scanning function, scanning can be initiated by pressing the {Start} button. If the manual scanning function is used, then communications between the scanner and the personal computer are no longer needed in cases where it is necessary to set the original in the scanner one sheet at a time, for example.

  • Page 38: Troubleshooting

    Turn on the power. If there are any other SCSI devices connected, the host computer may not be able to recognize the scanner if it has the same SCSI ID as another device. Refer to P.11, “Setting the SCSI ID,” and set a unique SCSI ID for the scanner.

  • Page 39: Error Indicators And Solutions

    5. Troubleshooting Error Indicators and Solutions When the indicators are on or flashing in any of the following combinations, an error has occurred. After confirming the nature of the error, take the appropriate action. : On : Flashing : Off Description of error The Auto Document Feeder (ADF) or the ADF cover is...

  • Page 40: Procedures To Correct Errors In The Adf

    Procedures to Correct Errors in the ADF When an Original is Jammed in the Auto Document Feeder (ADF) A A A A A Open the ADF cover. B B B B B Turn the drum knob in the direction indicated by the arrow. 1: Knob 2: Feed roller C C C C C...

  • Page 41: When Characters Printed By The Endorser Are Too Light Or The Original Gets Dirty

    Replace the ink ribbon if the Endorser’s printing becomes too light. A A A A A Turn off scanner power, and unplug the power cable from the power outlet. B B B B B Flip open the Endorser cover (located towards the rear of the output table), and pull the cover out.
  • Page 42 , and then pull it out G G G G G Push a new ink ribbon cartridge into the Endorser. H H H H H Align the endorser with the hooks on the scanner as shown in the diagram.

  • Page 43: Cleaning The Endorser

    5. Troubleshooting I I I I I Push the Endorser in until it clicks, and tuck the Endorser’s power cord into the appropriate hook. J J J J J Slide the protrusion on the bottom of the cover into the output table, and then push the cover closed.

  • Page 44: Appendices

    Do not use volatile chemicals such as benzene or paint thinner to clean the scanner, and do not spray insect sprays, etc., on the scanner. Such chemicals could deform, discolor, or crack scanner components. If there is any dust or dirt inside the scanner, wipe it away with a dry, clean cloth. 6. Appendices...

  • Page 45: Cleaning The Contact Glass, Slit Glass, White Sheet, And Platen

    Be careful not to pinch your fingers when closing the Auto Document Feeder (ADF). A A A A A Turn off scanner power, and unplug the power cable from the power outlet. B B B B B Wipe these components with a soft, dry cloth.
  • Page 46 Maintenance Note Always clean the feed roller after scanning an original that was written in pencil or with some other material that is not solidly fixed on the paper. If you do not clean the feed roller, it may dirty the next original that is scanned.

  • Page 47: Cleaning The White Roller (Duplex Model Only)

    A A A A A Turn off scanner power, and unplug the power cable from the power outlet. B B B B B Open the Auto Document Feeder (ADF), and pull off the white sheet (which is held in place by cellophane tape).
  • Page 48 E E E E E Align the arrow on the reverse side of the white sheet with the document home position. Note Make sure that the white sheet does not lie on the scales. 1: Home position 2: Scales F F F F F Gently close the Auto Document Feeder (ADF), and press it down on it firmly.

  • Page 49: Moving The Scanner

    Accordingly, after this period has elapsed, it may not be possible to accept a unit for repairs. If you contact a service center, they will prepare the scanner for safe shipment for you. However, you will be responsible for the actual packing and shipping of the scanner.

  • Page 50: Carrying The Scanner A Short Distance

    When shipping the scanner, pack it in its original shipping carton. Important Disconnect all cables. Because the scanner is a precision instrument, pack it carefully so that it will not be damaged while in transit. Disposing of the Scanner When you wish to dispose of your scanner, contact your dealer or a service center.

  • Page 51: Options

    6. Appendices Options This section describes options that are sold separately. Image Processing Unit Type A Note The Image Processing Unit Type A is an option. If this option is used, the following image processing features become possible: Dynamic Threshold This function automatically determines a suitable threshold value on the basis of the brightness of the original, and converts the scanned image to binary data.

  • Page 52: Endorser Unit Type A(Printing Function)

    Auto Document Feeder (ADF). The Endorser Unit Type A (printing function) settings are made through the scanner driver. For details on how to set the Endorser Unit Type A, refer to the manual and help provided for the scanner driver that you will be using. Options...

  • Page 53: Specifications

    6. Appendices Specifications Scanner Electrical and Hardware Specifications Type Scanning methods Scanning area Resolution Gray scale Scanning time Scanning speed Warm-up time Interface Power consumption Size Weight Desktop flatbed scanner Fixed original scanning and moving original scanning Main-direction: 298mm (11.7”) max.

  • Page 54: Dip Switches

    In this case, set DIP switch 2 to “ON” (SCSI synchronous transfer disabled). If this scanner is connected in the middle of a daisy chain, set DIP switch 3 to “ON” (internal SCSI terminator off). DIP Switches Leave these set to “OFF;”...

  • Page 55: Functions

    Note The scanner operates according to the scanner driver settings, but some scanner driv- ers do not support all of the scanner functions. In such a case, the unsupported func- tions are not available for use. In addition, the names used in this manual for certain functions may differ from the names used by the scanner driver.

  • Page 56: Scan

    Scan This function scans an original once the scanning area, scanning composition, resolution, and other values have been set. When setting these values, consideration should be given to the original that is to be scanned and to the output device (display, printer, etc.). For example, it is meaningless to scan an original at high resolution if the resolution of the output device is lower than the scanning resolution, especially because high-resolution scanning uses a great deal of memory and requires more processing time.

  • Page 57: Binary Scanning/Threshold

    6. Appendices Binary Scanning/Threshold The binary scanning function converts the original into black and white image data. If the original contains any intermediate colors, they are compared with the threshold value and determined to be either black or white accordingly. The threshold value can be set to any of 255 gradations; any intermediate colors that are brighter than the threshold value are scanned as “white,”...

  • Page 58: Halftone Scanning

    Halftone Scanning Halftone scanning converts the original into an image consisting of pseudo-halftones produced by dot shading (in which shading is achieved through combinations of black and white dots, as in newspaper photographs). This function is used to output an original that has intermediate tones, such as a photo, on an output device that can only produce monochrome output, such as a laser printer.

  • Page 59: Gray Scale Scanning

    6. Appendices 70 LPI 95 LPI 180 LPI Gray Scale Scanning Glay Scale scanning converts an original into image data consisting of 4-bit or 8-bit gradations. Four bits can express 16 gradations, and eight bits can express 256 gradations. This function is used to output an original that contains intermediate tones on an output device that can express intermediate tones for a single pixel, such as a display or a Dye Sublimation printer.

  • Page 60: Area Extraction

    Functions Area Extraction This function extracts and scans a specified rectangular area within a scanning area. For example, to scan just the photograph portion of the original shown below, specify the area where the photograph is located. The rectangular area is specified by specifying the coordinates of the upper left corner of the rectangle, and the vertical and horizontal lengths.

  • Page 61: Section Area (Multi-Area Settings)

    6. Appendices Section Area (Multi-area Settings) This function permits the specification of up to four rectangular areas of any size within the scanning area, each of which can be set as the scanning area. When overlapping areas are set, the area that was set last takes priority.

  • Page 62: Auto Photo/Letter

    Auto Photo/Letter This function automatically determines whether the image being scanned is text (binary image) or photo (intermediate tone image), and scans the text areas in binary scanning mode and the photos in halftone scanning mode. This function is used in order to automatically scan text in binary scanning mode and photos in halftone scanning mode.

  • Page 63: Resolution

    6. Appendices Resolution This function permits setting separate resolutions for the main-scanning and the sub-scanning, over a range of 100dpi to 800dpi (in 1dpi increments) for each. A high resolution setting requires more free space in memory and requires more processing time. Basically, when outputting a scanned image that is the same size as the original image, set the same resolution as that of the output device.

  • Page 64: Brightness

    Brightness The brightness can be adjusted to 255 levels. If a high value is set for the brightness, the image will become brighter overall. If a low value is set, the image will become darker overall. When scanning a dark original, set a high value for the brightness; when scanning a bright original, set a low value for the brightness.

  • Page 65: Gamma Correction

    6. Appendices Gamma Correction The following types of gamma correction are possible. However, different models of output devices have different characteristics. Select a suitable gamma curve for the original that is to be scanned and the output device. Normal Emphasizes the contrast slightly, resulting in a somewhat sharp scanned image. Sharp Emphasizes the contrast, resulting in a sharp scanned image.

  • Page 66: Binary Filters

    This function is valid only when the optional Image Processing Unit Type A is installed. Parameter Download This function allows a user to download user-created gamma curves and halftone patterns to the scanner. The details of how to download the data depends on the software being used. When filter is used...

  • Page 67: Document Size Detection

    6. Appendices Document Size Detection This function automatically detects the width of the original, and sends the information to the personal computer. Document Size Detection on the Contact Glass Document Size Detection in the Auto Document Feeder (ADF) Note If there is any coloring on the leading edge (5mm, 0.2”) of the original, the size of the original might not be detected properly.

  • Page 68: Erase Background

    Erase Background This function permits selection of the white side dynamic range for scanning. When Erase Background is disabled The dynamic range is set so that a white original (D value: 0.07) reaches maximum output. When Erase Background is enabled During scanning, the portion of the original that is closest to white is deemed to be white, and the dynamic range is set so that the portion in question reaches maximum output.

  • Page 69: Index

    Halftone Scanning ------------------- 45, 47 Home Position ------------------------ 20, 37 Image Processing ------------------------- 40 Indicators --------------------------- 5, 27, 28 Initializing the Scanner ------------------ 16 ink ribbon ----------------------------------- 30 Interface for Reverse Side Scanning ------- 4 ISIS -------------------------------------- 2, 25 Knob ------------------------------ 29, 34, 36...
  • Page 70 Reset Switch ---------------------------- 4, 16 Resolution ---------------------------------- 52 Rotary Switch --------------------------- 4, 11 Scale ----------------------------------------- 20 SCAM --------------------------------- 10, 43 Scanner Indicators --------------------------- 3 Scanning Composition -------------------- 45 SCSI ----------------------------------------- 10 SCSI Board --------------------------------- 10 SCSI Cables ---------------- 10, 11, 27, 39...
  • Page 71 6. Appendices...
