Description of Parts
5.6 Power Supply
The EPC C2D Nautic is available with 230 V AC or 24 V DC power system.
230 V AC Power Supply Connection with Integrated Fuse
24 V DC Power Supply Connection
The power supply for 24 V DC is carried out via a double-pole connector
(Phoenix MST BT 2,5/2).
The EPC C2D Nautic is certified for the connection to protective grounded
power supply according to EN60950. The EPC Box C2D Nautic can also be
operated with extra low voltage in accordance with EN60950. The controlling
transformer has to comply with EN60742.
Note:
Check the power supply system with the relevant data on the type plate.
16
Fuse 1 A
Earth screw
Fuse 6.3 A
Earth screw
Beijer Electronics, MAEN979B
