Summary of Contents for Beijer Electronics EPC T170/170 C2D Nautic
- Page 1 EPC C2D Nautic Installation Manual English MAEN979B, 2010-08...
- Page 2 Please read the entire installation manual prior to installing and using this equipment. Only qualified personnel may install, operate or repair this equipment. Beijer Electronics AB, including all its group companies, is not responsible for modified, altered or renovated equipment. Because the equipment has a wide range of applications, users must acquire the appropriate knowledge to use the equipment properly in their specific applications.
-
Page 3: Table Of Contents
Compact Flash Memory Card............18 6 Operation ..................... 19 Operating System................19 Default BIOS Settings............... 20 Important Items Regarding Software Installation ......23 Graphic Board Installation ..............24 Touch Screen Installation..............25 Installation of LAN-/Network Card ..........29 Beijer Electronics, MAEN979B... - Page 4 EPC T150/150 C2D Nautic Front View .........39 EPC T150/150 C2D Nautic Cut Out Drawing........40 EPC T150/150 C2D Nautic Outline Drawings ........41 EPC T170/170 C2D Nautic Front View .........42 EPC T170/170 C2D Nautic Cut Out Drawing........43 EPC T170/170 C2D Nautic Outline Drawings ........44 EPC T190/190 C2D Nautic Front View .........45...
-
Page 5: Safety Precautions
Please visit our web site for the latest information. Model DNV ABS 60945 EPC T150/150 C2D Nautic EPC T170/170 C2D Nautic EPC T190/190 C2D Nautic EPC Box C2D Nautic * Also for bridge applications Approval/Certificate Abbreviation Conformité... -
Page 6: General
– The supplier neither guarantees that the EPC is suitable for your particular application, nor assumes responsibility for your product design, installation or operation. Beijer Electronics, MAEN979B... -
Page 7: During Installation
1.4 During Use – Keep the EPC clean. – Emergency stop and other safety functions may not be controlled from the EPC. – Do not use too much force or sharp objects when touching the keys, touch screen etc. Beijer Electronics, MAEN979B... -
Page 8: Service And Maintenance
1.6 Dismantling and Scrapping – The EPC or parts thereof shall be recycled according to local regulations. – The following components contain substances that might be hazardous to health and the environment: lithium battery, electrolytic capacitor and dis- play. Beijer Electronics, MAEN979B... -
Page 9: Product Naming
Optional touch Screen Processor Main Type of series screen size type usage power supply There is a variant without display; EPC C2D Box Nautic AC: Nautic Computer Processor type No display Main Type of series usage power supply Beijer Electronics, MAEN979B... -
Page 10: Supplied Equipment
24 V DC units are delivered without cable. A variety of cables are available separately. Installation manual This manual describes specific information about Beijer Electronics products only – not about third party components. Note: Separate documentation of third party components is included on the enclosed driver software CD + as printed documentation. -
Page 11: Compass Safety Distance
Electrical devices, such as the EPC C2D Nautic, must be kept in a safe distance to a compass in operation according to the following table: Compass type Minimum distance to the EPC C2D Nautic Steering compass 1 meter in all directions Emergency compass Standard compass 1.45 meter in all directions Beijer Electronics, MAEN979B... -
Page 12: Description Of Parts
The EPC C2D Nautic consists of a Front unit and a PC unit. These are installed in the same way independent of the display size. Front unit PC unit The EPC Box C2D Nautic consists of the PC unit only. Beijer Electronics, MAEN979B... -
Page 13: Display
(single step or auto- matic repeating after one second) Press + and - simultaneously for Turns on full brightness quickly more than one second (default - may be configured according to RBC software manual MAEN986) Beijer Electronics, MAEN979B... -
Page 14: Communication Ports
ATX remote LAN 2 COM2 LAN 1 ATX switch Power supply PCI slot 1 PCI slot 2 Earth Mic in PS/2 mouse COM1 DVI-1 USB 1-2 USB 3-4 Compact Flash slot Line in PS/2 keyboard Line out Beijer Electronics, MAEN979B... -
Page 15: Motherboard
The quality of the memory module may influence the system stability. When updating the memory module, or adding a second one, please only use memory modules ap- proved by Beijer Electronics. Memory modules are electrostatic sensitive compo- nents. Relevant protective measures (earth) have to be considered during assembly/ disassembly. -
Page 16: Power Supply
EN60950. The EPC Box C2D Nautic can also be operated with extra low voltage in accordance with EN60950. The controlling transformer has to comply with EN60742. Note: Check the power supply system with the relevant data on the type plate. Beijer Electronics, MAEN979B... -
Page 17: Earthing System
A manual actuation of the ATX power switch, i.e. to start the BIOS menu au- tomatically to check and confirm correct settings, can be necessary if the system registers an error during shut-down or booting. This is not a malfunction but a safety feature. Beijer Electronics, MAEN979B... -
Page 18: Atx Remote Connector
Note: Only Compact Flash cards distributed by Beijer Electronics may be used. Third par- ty products may cause system malfunction or performance loss. If a Compact Flash memory card is mounted in/removed from a running EPC, the EPC must be restarted in order to detect the system change. -
Page 19: Operation
The operating system and other programs are installed on drive “C:”. Drive “D:” contains all data required for a new installation (drivers and opera- tion system) and may also be used for user data (beneficial for example for data backup). Beijer Electronics, MAEN979B... -
Page 20: Default Bios Settings
Second Boot Device Harddisk Third Boot Device Disabled Boot Other Device Disabled Boot Up NumLock Status Gate A20 Option Fast Security Option Setup MPS Version Control For OS 1.4 Report No FDD For Win95 Small Logo (EPA) Show Disabled Beijer Electronics, MAEN979B... - Page 21 Enabled USB Mass Storage Device Auto mode Boot setting Power Management Setup PCI Express PME Disabled ACPI Suspend Type Soft-Off by PWR-BTTN Instant-Off Wake-Up by PCI Card Disabled Power On by Ring Disabled Resume by Alarm Disabled Beijer Electronics, MAEN979B...
- Page 22 INT Pin 4 Assignment Auto INT Pin 5 Assignment Auto INT Pin 6 Assignment Auto INT Pin 7 Assignment Auto INT Pin 8 Assignment Auto Frequency Voltage Control Auto Detect PCI / clk Enabled Spread Spectrum Disabled Beijer Electronics, MAEN979B...
-
Page 23: Important Items Regarding Software Installation
After operating the system for the first time we recommend that you make start discs (emergency discs). These might be required to restore an operational system. Additionally, we recommend making backup copies of your own data and applica- tions. Beijer Electronics, MAEN979B... -
Page 24: Graphic Board Installation
CD instead. Note: The graphic driver will be installed twice. 5. After finishing the installation and re-starting the EPC, the following entries are available under the Display icon in the Control Panel, or in the display properties. Beijer Electronics, MAEN979B... -
Page 25: Touch Screen Installation
6.5 Touch Screen Installation Note: Make sure to use a touch driver of version 6.31.a or higher. 1. Start the touch screen installation from the driver CD, follow the instruc- tions on the screen and press Next: Beijer Electronics, MAEN979B... - Page 26 Operation 2. Accept the license agreement. Beijer Electronics, MAEN979B...
- Page 27 Operation 3. Select Autodetect or manually select the technical connection data. Beijer Electronics, MAEN979B...
- Page 28 4. Press Finish and follow the instructions for a re-start. 5. After a re-start of the operating system you will find Hampshire Control Panel among the programs. 6. Calibrate the touch screen with your finger or with a rounded pointed touch pen. Beijer Electronics, MAEN979B...
-
Page 29: Installation Of Lan-/Network Card
5. Via the MS-DOS window, under Start/All Programs/Accessories/ Command prompt, you can set a “connection PING” to test your connec- tions to the server and other PC’s. (for example: C:\ping 192.168.5.100). Beijer Electronics, MAEN979B... - Page 30 Operation Beijer Electronics, MAEN979B...
-
Page 31: Service
Service Service 7.1 Introduction Only spare parts recommended by Beijer Electronics may be used. 7.1.1 Tools You can carry out the disassembly and assembly with an 2.5 mm Allen key and a Phillips head screwdriver, size 3. 7.1.2 Preparation Disconnect the EPC from the power supply. -
Page 32: Changing The Fan Filter
To install a PCI-board the right hand side part of the rear enclosure has to be removed. 1. To open the enclosure remove the marked seven screws with an Allen key. After removing the screws the enclosure can be easily removed. Beijer Electronics, MAEN979B... - Page 33 The picture of the opened EPC below shows the board holder (1) and the 2 PCI- slots (2). 2. Remove the cover of the desired slot to insert your PCI-board, by removing the screw and pulling out the cover. Beijer Electronics, MAEN979B...
- Page 34 4. Insert the PCI-board, if necessary bend the slot bracket a little bit. Please ensure a correct fit at the rear edge (3) of the slot and make sure the metal bracket goes into the groove (4). Beijer Electronics, MAEN979B...
- Page 35 Service 5. Mount your PCI-board and make sure to properly tighten the screw. 6. Re-assemble the board holder and tighten the two screws properly. Beijer Electronics, MAEN979B...
-
Page 36: Cable Fixing Points
If two wide boards are used, the short support (5) can be removed. 7.4 Cable Fixing Points When connecting interface cables such as RS232, USB, LAN or VGA, the ca- bles must be fixed at the cable fixing points, to avoid that the cables loosen be- cause of vibrations. Beijer Electronics, MAEN979B... -
Page 37: Technical Data
Compact Flash ports 1 x internal (optional) bootable 1 x external not bootable Keyboard/mouse 2 x PS/2 For external monitor, supports QXGA 2048 x 1536 For external monitor, supports DVI 1.0 Audio ports Line in/out, microphone in Beijer Electronics, MAEN979B... - Page 38 10% to 90% non-condensed humidity Basic RBC software V0003 May 28, 2009 version Please contact Beijer Electronics/Elektronik-Systeme Lauer for information about current version. * Only applies to EPC T150 C2D Nautic/ EPC T170 C2D Nautic/ EPC T190 C2D Nautic Beijer Electronics, MAEN979B...
-
Page 39: Drawings
Drawings Drawings 9.1 EPC T150/150 C2D Nautic Front View 6 x hole Ø 6.5 mm Beijer Electronics, MAEN979B... -
Page 40: Epc T150/150 C2D Nautic Cut Out Drawing
6 x bore holes Ø 6.5 mm Front plate 412.0 x 351.0 mm, tolerance: ±0.2 mm. Mounting method: 6 x M6x25 steel screws DIN 6912. Screws and o-ring seals are included. Max. 8 mm thick mounting frame. Beijer Electronics, MAEN979B... -
Page 41: Epc T150/150 C2D Nautic Outline Drawings
Drawings 9.3 EPC T150/150 C2D Nautic Outline Drawings Bottom view 387.5 375.5 205.7 80.3 36.5 24.5 Rear view Side view Beijer Electronics, MAEN979B... -
Page 42: Epc T170/170 C2D Nautic Front View
Drawings 9.4 EPC T170/170 C2D Nautic Front View 8 x bore holes Ø 6.5 mm Beijer Electronics, MAEN979B... -
Page 43: Epc T170/170 C2D Nautic Cut Out Drawing
Drawings 9.5 EPC T170/170 C2D Nautic Cut Out Drawing Cut out dimensions: 396.0 x 364.0 mm, tolerance +1 mm. Space for mounting screws on all sides: 15 mm = needed space 426.0 x 394.0 mm. 8 x bore holes Ø 6.5 mm Front plate 430.0 x 390.0 mm, tolerance: ±0.2 mm. -
Page 44: Epc T170/170 C2D Nautic Outline Drawings
Drawings 9.6 EPC T170/170 C2D Nautic Outline Drawings Bottom view 384.5 214.7 89.3 45.5 Rear view Side view Beijer Electronics, MAEN979B... -
Page 45: Epc T190/190 C2D Nautic Front View
Drawings 9.7 EPC T190/190 C2D Nautic Front View 126.6 8 x bore holes Ø 6.5 mm 126.6 126.6 483.2 Beijer Electronics, MAEN979B... -
Page 46: Epc T190/190 C2D Nautic Cut Out Drawing
8 x bore holes Ø 6.5 mm 465.2 Front plate 483.2 x 444.0 mm, tolerance: ±0.2 mm. Mounting method: 8 x M6x25 screws DIN 6912. Screws and o-ring seals are included. Max. 8 mm thick mounting frame. Beijer Electronics, MAEN979B... -
Page 47: Epc T190/190 C2D Nautic Outline Drawings
Drawings 9.9 EPC T190/190 C2D Nautic Outline Drawings Bottom view 458.1 411.1 241.3 115.9 72.1 25.1 Rear view Side view Beijer Electronics, MAEN979B... -
Page 48: Epc Box C2D Nautic Outline Drawings
9.10 EPC Box C2D Nautic Outline Drawings Bottom view 169.2 43.8 Rear view Side view 255.5 220.5 Ø7 Ø4.6 Ø8.5 55.5 20.5 Mounting method: 6 x M4x12 steel screws DIN 912 or 4 x M6x12 steel screws DIN 912. Screws are included. Beijer Electronics, MAEN979B... - Page 49 Head Office Subsidiaries Sweden Germany China Beijer Electronics Products AB Elektronik-Systeme Lauer GmbH & Co. KG Beijer Electronics Co. Ltd Box 426 Kelterstraße 59 Room 201, Buildning B, No. 1618, 201 24 Malmö, SWEDEN 72669 Unterensingen, GERMANY Yishan Road, Shanghai 201103, CHINA Tel: +46 40 35 86 00 Tel.: +49 70 22/96 60 0...
