Xerox ® Color C60/C70 Printer
Simple Image Quality Adjustment (SIQA)
Quick Use Guide
Simple Image Quality Adjustment (SIQA) is a set of maintenance tools that adjust the quality of the printed images generated by the printer. SIQA performs
three types of adjustments, which must be performed in the order given. For details on the procedures outlined below, refer to the Xerox
Printer System Administrator Guide.

Image Transfer

Alignment

Density Uniformity
These are the three sets of steps that are performed when calibrating the printer with the SIQA tools:
1. Print the SIQA targets.
2. Scan the targets using either the Document Feeder or the Platen Glass.
3. Save the adjustment data to a file on the printer providing the file with a unique name.
Accessing the SIQA Tools
1. At the printer UI, select the Login/Logout button.
2. Log-in as a System Administrator.
3. Press the Machine Status button on the control panel.
4. Touch the Tools tab.
5. In the Features column, scroll down and touch Maintenance.
6. Touch the down arrow to access the SIQA tools on the next screen.
Xerox ® Color C60/C70 Printer
Simple Image Quality Adjustment (SIQA) Quick Use Guide
SIQA Tools
Color C60/C70
®
