STATUS INDICATOR LED

Combinations of the three front LEDs (LD1, LD2, LD3)
indicate the transmitter's operating status by different flash-
ing patterns.
Examples are shown below.
NORMAL OPERATION (RUN) MODE
LD1
PC Configuration RUN Mode (Option A)
G
The transmitter is configured via PC and
LD2
is in normal operating conditions.
LD3
ERROR MODE
LD1
System Error
A
Indicates the CPU's communication error.
LD2
A
LD3
A
LD1
Output Saturated in PC Configuration Mode
G
(Option A)
LD2
The output is saturated.
(approximately below -15% or above +115%)
LD3
A
M-SYSTEM WARRANTY
M-System warrants such new M-System product which it manufactures to be free from defects in materials and workmanship during the 36-month period following the date that such
product was originally purchased if such product has been used under normal operating conditions and properly maintained, M-System's sole liability, and purchaser's exclusive remedies,
under this warranty are, at M-System's option, the repair, replacement or refund of the purchase price of any M-System product which is defective under the terms of this warranty. To
submit a claim under this warranty, the purchaser must return, at its expense, the defective M-System product to the below address together with a copy of its original sales invoice.
THIS IS THE ONLY WARRANTY APPLICABLE TO M-SYSTEM PRODUCT AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. M-SYSTEM SHALL HAVE NO LIABILITY FOR CONSEQUENTIAL, INCIDENTAL OR
SPECIAL DAMAGES OF ANY KIND WHATSOEVER.
M-System Co., Ltd., 5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN, Phone: (06) 6659-8201, Fax: (06) 6659-8510, E-mail: info@m-system.co.jp
LD1
DIP SW Configuration RUN Mode
G
The transmitter is configured via DIP SW and
LD2
is in normal operating conditions.
LD3
LD1
DIP SW Error
R
DIP SW configuration is inappropriate.
LD2
Check the DIP SW setting referring to Tables 2 – 11.
R
LD3
R
LD1
Output Saturated in DIP SW Configuration Mode
G
The output is saturated.
LD2
(approximately below -15% or above +115%)
LD3
A
M3LDY
A Amber LED OFF
G Green LED ON
R Red LED Blink
P. 6 / 6 EM-2664 Rev.2
