OPN2002

Quickstart Guide for HID

STEP ONE

Scan the code at right to choose Bluetooth-HID (Keyboard) mode.

STEP TWO

Hold the Clear/Function key (see diagram above) on the OPN2002 for five
seconds, until it beeps and the LED begins flashing blue.

STEP THREE

you, or allow you to choose one for yourself (please
use numbers only).
Once chosen, the OPN2002's laser will light up and
you will hear a steady beep. Use the number bar-
codes provided on the right to scan your PIN code,
one number at a time. When you are done, scan
'END' to complete the pairing.

STEP FOUR

Your OPN2002 is now paired. The LED blinks blue slowly to indicate a con-
nection is active and working. Any barcode data you scan will now appear
on the screen as if you had typed it. Please have a program open that
allows typing for your data to appear.
Note, if for any reason your OPN2002 becomes unpaired with your other
device (e.g. Host device goes to sleep, battery loss, etc.), you can simply
hold the scan key for five seconds to reestablish the connection.
Use the Bluetooth
software on your host
device to discover and
choose the OPN2002
scanner. Your device
will either choose and
display a PIN code for
USB Connector
Clear/Function Key
Scan Key
LED Indicator
Laser Engine
