MIF AND MIF II RELAYS
Feature
MIF order code options
Application
MIF-P-A11E100F00C
P: 3 Phase and Ground
N: Single Phase
Curves
MIFP-A-11E100F00C
A: ANSI Curves
I: IEC Curves
U: IAC Curves
C: EPTAR-C Curves (single phase
only)
Phase CT Range MIFPA-1-1100F00C
0: N models (single phase)
1: Phase CT = 1 A (0.1 - 2.4 A)
5: Phase CT = 5 A (0.5 - 12 A)
Ground CT
MIFPA1-1-E100F00C
Range
1: Ground CT In = 1 A (0.1 - 2.4 A)
5: Ground CT In = 5 A (0.5 - 12 A)
N: Sensitive Ground (0.005 - 0.12 A)
Language
All MIF relays come with English
standard.
Options
MIFPA11E-1-00F00C
0: Basic Model ()
1: Option 1 (Configurable I/O, Event
Recording, and Oscillography)
2: Option 2 (Option 1 and Cold Load
Pickup, Breaker Failure Protection,
Breaker Health, and Configurable
Logic)
Recloser
n/a
Power Supply
MIFPA11E100-F-00C
H:
110 - 250 VDC (Range: 88~300 VDC)
110 - 230 VAC (Range: 88~264 VAC)
F: 24 - 48 VDC (Range: 19~58 VDC)
Protocol
All MIF relays come with Modbus
RTU standard.
Environmental
n/a
Option
1. Some features are implemented or configured somewhat differently in the 350 relay. See the 350 Instruction Manual for details.
2. For details of 350 communications implementation, see the 3 Series Communications Guide.
4
MIF II order code options
MIFII-P-A11E00HI00
P: 3 Phase and Ground
N: Single Phase
MIFIIP-A-11E00HI00
A: ANSI Curves
I: IEC Curves
U: IAC Curves
C: EPTAR-C Curves (single phase
only)
MIFIIPA-1-1E00HI00
0: Phase CT = 1/5 A
1: Phase CT = 1 A
5: Phase CT = 5 A
MIFIIPA1-1-E00HI00
1: Ground CT In = 1 A (0.1 - 2.4 A)
5: Ground CT In = 5 A (0.5 - 12 A)
L: Extremely Sensitive Ground In
= 1 A (0.002 - 0.048 A)
N: Sensitive Ground (0.005 - 0.12 A)
MIFIIPA11-E-00HI00
E: English
F: French
T: Turkish
MIFIIPA11E-0-0HI00
0: Basic Model ()
1: Option 1 (Event Recording,
Oscillography, Configurable I/O and
LEDs)
2: Option 2 (Option 1 and Cold Load
Pickup, Breaker Failure Protection,
Breaker Health, Configurable Logic,
and Circuit Breaker Control)
MIFIIPA11E0-0-HI00
0: without Recloser
R: with Recloser
MIFIIPA11E00-HI-00
HI:
110 - 250 VDC (Range: 88~300 VDC)
110 - 230 VAC (Range: 88~264 VAC)
LO: 28 - 48 VDC (Range: 19~58 VDC)
MIFIIPA11E00HI-0-0
0: Standard model (Modbus RTU)
C: IEC60870-5-103 with 2 Comms
ports
MIFIIPA11E00HI0-0
0: None
H: Conformal Coating
CHAPTER 1: OVERVIEW
350 order code options
All 350 relays come with 3 phase
and ground standard.
All 350 relays come with ANSI, IEC,
and IAC curves standard.
350E-P0-G0HEENNSNNN
P0: user selectable 1/5 A three-
phase current inputs (0.02 - 20 × CT)
350EP0-G0-HEENNSNNN
G0: user selectable 1/5 A Ground
current input (0.02 - 20 × CT)
S0: user selectable 1/5 A Sensitive
Ground current input (0.002 - 3 × CT)
All 350 relays come with English
standard.
350EP0G0HEE-N-NSNNN
N: CLP, Lockout (86)
C: CLP, 50BF, Autoreclose (79)
All 350 relays come with Event
Recording, Oscillography,
Configurable I/O and LEDs,
Configurable Logic (up to 16),
Breaker Health, and Circuit Breaker
1
Control standard.
350EP0G0HEE-N-NSNNN
N: CLP, Lockout (86)
C: CLP, 50BF, Autoreclose (79)
350EP0G0-H-EENNSNNN
H: 110 - 250 VDC
110 - 230 VAC
L: 28 - 48 VDC
350EP0G0HEENN-SN-NN
SN: Standard: Front USB, Rear
RS485: Modbus RTU, DNP3.0,
2
IEC60870-5-103
350EP0G0HEENNSNN-N
N: None
H: Harsh Environment Conformal
Coating
3 SERIES RETROFIT – INSTRUCTION MANUAL
