Maintenance
COOKTOP BURNER GRATES DUAL PURPOSE
The cooktop is designedwith two con- SEALED BURNERS
toured wells which containspills until The four sealed burners are secured to
they can be wiped up. Unlike the stan- the coektopand areNOT designedto be
dard gas appliance, THiS COOKTOP removed by the consumer.
DOES NOT LIFT-UP NOR IS IT RE-
MOVABLE. To prevent damage to the Since the four burners are sealed into
gas tubing or top, do not attempt to lift the eooktop, boiloverswon't seep under-
cooktop, neath to the burner box area. Thus
When reinstalling square grates, place there are no hidden spills in the burner
_J indentedsidestogether sostraightsides b°x area to clean'are at front and rear.
IGNITORS
__ When cleaning around the surface burn-
er, use care to prevent damage to the
spark ignitor which is located at the
back-side of each burner. If a cleaning
cloth should catch the ignitor, it could
damage or break it, If the ignitor is dam-
aged or broken, the surface burner will
not light.
Burner grates are durable but may lose Ignitor
their shine due to usage and high tom- REARVIEW OF SEALEDBURNER
peratures.
(continued next page)
VALVE ADJUSTMENT
The LOW settingshouldproducea sta-
bleflamewhen turningthe knobfrom HI
to LO. The flame shouldbe 1/8 inchor
lowerand must be stableonallportson
LOW setting.
To adjust: Operate burner on HI for NOTE: All gas adjustmentsshould be
about5 minutesto preheat burnercap. done by a qualifiedserviceronly,
Turn knob back to LO; remove knob,
and insert a small screwdriverintothe
centerof the valve stem. Adjustflame
size by turning adjustment screw in
either direction.
