- Page 1 Style that revolves around you. • C • EILING WNER'S ANUAL • Indy • 10/17 WARNING: Read and follow these instructions carefully and be mindful of all warnings shown throughout.
- Page 2 & O ENERAL NSTALLATION PERATION NSTRUCTIONS MPORTANT AFEGUARDS: 1. To ensure the success of the installation, be sure to read the instructions and review the diagrams thoroughly To ensure the success of the installation, be sure to read the instructions and review the diagrams thoroughly before beginning.
-
Page 3: Important Safety Precautions
MPORTANT AFETY RECAUTIONS Thank you for choosing a Regency Ceiling Fan. You have chosen the best! Your new ceiling fan has been designed to provide many years of service and enjoyment. Warnings: Warnings: • Disconnect power by removing fuse or turning off circuit breaker before installing the fan and/or optional lighting. -
Page 4: Unpacking Your Fan
NPACKING 1. Unpack your fan and check the contents. Do not discard the carton. If warranty replacement or repair is ever necessary, the fan should be returned in original packing. Remove all parts and hardware. Do not lay motor housing on its side, or the decorative housing may shift, be bent or damaged. 2. -
Page 5: Hanging Bracket
REPARATION Parts identification on assembled fan Canopy Canopy Screw Downrod Cover Plate Collar Cover Blade Motor Housing Blade Arm Decorative switch housing cap PREPARATION: Verify you have all parts before beginning the installation. Check foam insert closely for missing parts. Remove motor from packing. - Page 6 NSTALLING THE 1. Carefully support fan body (motor) in its styrofoam packing with the mounting collar (where the wires come out) facing upward. 2. Loosen the two set screws and remove the downrod pin and cotter pin from the top coupling of the motor assembly. 3.
- Page 7 NSTALLING THE ANG THE FAN TO HANG BRACKET ASSEMBLY 1. Lift ball/downrod/fan into hanger bracket opening. NOTE: NOTE: The tab opposite hanger bracket opening should fit in slot on ball. 2. Make wire connections, (refer to section titled "Electrical Connections"). Hanger Bracket Tab Ball Slot...
- Page 8 LECTRICAL ONNECTIONS LECTRICAL ONNECTIONS: Be sure electricity is turned off at the main power box before wiring. OUTLET BOX SWITCH Step 1. Disconnect the power and remove the existing wall WALL PLATE plate and switch from the wall junction box. (Fig. 1) SCREWS SCREWS Step 2.
- Page 9 LECTRICAL ONNECTIONS Be sure electricity is turned off at the main power box before wiring. SUPPLY CIRCUIT b. Connecting the wires from the wall switch to the b. Connecting the wires from the wall switch to the wires from the wall outlet box. wires from the wall outlet box.
-
Page 10: Installation
INISHING THE NSTALLATION 1. Tuck connections neatly into ceiling outlet box. 2. Slide the canopy up to mounting bracket and place the Ceiling Fan key hole on the canopy over the screw on the mounting Outlet Box bracket, turn canopy until it locks in place at the narrow Hanger section of the key holes. -
Page 11: Operation
NOTE: Be sure the power is off before installing. 1. Attach the decorative bottom cover to the mounting hub by turn the cover clockwise until tight. 2. Turn the power on. Your Regency Ceiling Fan is now ready to enjoy! Mounting Hub... -
Page 12: Troubleshooting
Make sure these are tight and the ball is completely seated in the bracket. HANK YOU FOR PURCHASING A EGENCY EILING Write to us at: Regency Ceiling Fans P.O. Box 730 Fenton, MO 63026 Visit us on the Web at: www.regencyfan.com 10/17 Regency Ceiling Fans...
