- Page 1 Bose ® ControlSpace™ CC-4 Room Controller Installation Guide...
-
Page 2: Important Safety Instructions
Do not attempt to service this product yourself. Opening or removing covers may expose you to hazards. Please call Bose to be referred to an authorized service center near you. -
Page 3: Required For Installation
Required for installation Provided in carton Not provided Double-gang junction box Cable* *Shielded, data-grade cable (22-24 AWG or 0.34-0.25mm ) is recommended. Limit runs to 500 ft for shielded cable, 100 ft for unshielded. Note: Use only cables which are acceptable by the local or national code. -
Page 4: Installation
Installation Assembly Wiring You must program the ESP-88 GPIO inputs using the ControlSpace™ Designer™ to enable ControlSpace CC-4 Room Controller functionality. CC-4 connector ESP-88 GPIO Input Connector COM — Connect to ESP-88 GPI Ground CAUTION: Be sure to terminate cable at both ends. - Page 5 ® Two sets of screws are provided. Use the The Bose ControlSpace™ CC-4 Room screws that are appropriate for your junc- Controller is designed to fit a North Ameri- tion box: Use #6 for North American...
- Page 6 Dimensions...
-
Page 7: Limited Warranty
How you can obtain Limited Warranty service: This Limited Warranty is fully transferable provided that the current 1. You can ship the system to either a Bose Service Agency or to owner furnishes the original proof of purchase from an authorized Bose directly with a proof of purchase from an authorized dealer. - Page 8 ©2007 Bose Corporation, The Mountain Framingham, MA 01701-9168 USA AM306693 Rev.01...
