TECHNICAL INFORMATION:
• Voltage: 230VAC 50Hz.
• Fuse rating: Type 50F, 6.3A/250VAC, 5 x 20mm.
• Wattage: Max.1000W for incandescent load.
• Wattage: Max. 300W for fluorescent load.
• Wattage: Max. 200W LED (no more than 8 lights).
• Detection angle: approx. 110°.
• Detection distance: Max. 12 metres.
• Duration time: from (10±5) seconds up to (4±1)
minutes adjustable.
• Lux control level: from daylight to night adjustable.
• IP44 rating.
Email: sales@eterna-lighting.co.uk / technical@eterna-lighting.co.uk
www.eterna-lighting.co.uk
Visit our website:
Issue 1117
CLEANING:
Clean this fitting only with a soft dry cloth.
Do not use any chemical or abrasive cleaners.
IF YOU EXPERIENCE PROBLEMS:
If you believe your product is defective, please return
it to the place where you bought it. Our Technical
Team will gladly advise on any Eterna Lighting
product, but may not be able to give specific
instructions regarding individual installations.
EVENTUALLY, YOU MAY WANT TO
REPLACE THIS PRODUCT:
Regulations require the recycling of Waste from
Electrical and Electronic Equipment (European
"WEEE Directive" effective August 2005—UK
WEEE Regulations effective 2nd January 2007).
Environment Agency Registered Producer: WEE/
GA0248QZ.
WHEN YOUR PRODUCT COMES TO THE END OF
ITS LIFE OR YOU CHOOSE TO REPLACE IT, PLEASE
RECYCLE IT WHERE FACILITIES EXIST - DO NOT
DISPOSE WITH HOUSEHOLD WASTE.
Made in China
INSTALLATION INSTRUCTIONS
A guide for qualified electricians
Model:
PIR110BK / PIR110WH
External 110° PIR Detector
These instructions are provided as a guideline to assist you.
PLEASE READ THESE INSTRUCTIONS BEFORE INSTALLATION
AND RETAIN FOR FUTURE REFERENCE
Pack contents:
1 x Fitting
1 x Screw pack
