EVENTUALLY, YOU MAY WANT TO
REPLACE THIS PRODUCT:
Regulations require the recycling of Waste from
Electrical and Electronic Equipment (European
"WEEE Directive" effective August 2005—UK
WEEE Regulations effective 2nd January 2007).
Environment Agency Registered Producer: WEE/
GA0248QZ.
WHEN YOUR PRODUCT COMES TO THE END OF
ITS LIFE OR YOU CHOOSE TO REPLACE IT, PLEASE
RECYCLE IT WHERE FACILITIES EXIST - DO NOT
DISPOSE WITH HOUSEHOLD WASTE.
Email: sales@eterna-lighting.co.uk / technical@eterna-lighting.co.uk
www.eterna-lighting.co.uk
Visit our website:
Issue 1016
CLEANING:
To avoid dust build-up and ensure proper
functioning of the PIR sensor, please wipe the sensor
lens lightly with a dry cloth every 3 months.
Do not use any chemical or abrasive cleaners.
IF YOU EXPERIENCE PROBLEMS:
If you believe your product is defective, please return
it to the place where you bought it. Our Technical
Team will gladly advise on any Eterna Lighting
product, but may not be able to give specific
instructions regarding individual installations.
Made in China
INSTALLATION INSTRUCTIONS
A guide for qualified electricians
Pack contents:
1 x Stand-alone PIR sensor
1 x Corner mounting bracket
1 x Fixing pack
Model:
EX360PIRWH
360° PIR Movement Detector
These instructions are provided as a guideline to assist you.
PLEASE READ THESE INSTRUCTIONS BEFORE INSTALLATION
AND RETAIN FOR FUTURE REFERENCE
Advertisement
Related Manuals for Eterna EX360PIRWH
Summary of Contents for Eterna EX360PIRWH
- Page 1 ITS LIFE OR YOU CHOOSE TO REPLACE IT, PLEASE it to the place where you bought it. Our Technical RECYCLE IT WHERE FACILITIES EXIST - DO NOT Team will gladly advise on any Eterna Lighting EX360PIRWH DISPOSE WITH HOUSEHOLD WASTE.
- Page 2 The installer must ensure that this fitting is suitable To avoid damage to the unit do not aim the sensor screw. for the purpose intended. Eterna Lighting Ltd cannot eyeball towards the sun. accept any liability for loss, damage or premature 10) Restore mains power.
- Page 3 UNDERSTANDING THE CONTROLS: TROUBLESHOOTING AND USER HINTS: Referring to Fig. 5 below. Note: all passive infra red detectors are more sensitive in cold and dry weather than warm and wet weather. Mounting ADJUSTING THE DURATION TIME: Screws x 2 The length of time that the load-light remains switched on after activation, can be adjusted from 10(±5) Power PROBLEM POSSIBLE CAUSE...
