SETTING THE KEYPAD ADDRESS

The keypad can either be set for an address of 00-30, or to
the non-addressable mode (31). The keypad's default
address is 31.
To change the keypad's address, do the following:
1. Enter address mode: Power up the keypad. Within 60
seconds of power-up, press and hold down the [1] and [3]
keys at the same time for 3 seconds. (If unable to enter
address mode, power up and try again.)
The current keypad address will be displayed, and the
cursor will be under the "tens" digit. If 10 seconds have
passed with no key entry, the keypad automatically
exits address mode. You must power down, power up
and start address mode again.
NOTE: The keypad will not enter address mode if the
panel to which it is connected is in programming mode.
2. Set the current address to "00": Press [0] to clear the
current "tens" digit. The cursor will move to the "ones"
digit position. Press [0] to clear the current "ones" digit.
The cursor will move back to the "tens" digit position.
3. Enter the keypad's address: Enter the proper "tens" digit
of the keypad's address. The cursor will move to the
"ones" digit position. Enter the proper "ones" digit of the
keypad's address. Note that address "31" sets the
keypad to non-addressable mode.
4. Exit address mode:
Press [✱] to save the displayed address and exit address
mode.

VIEWING THE KEYPAD ADDRESS

Press and hold down the [1] and [3] keys at the same time
for about 3 seconds. The current address is displayed. No
key entry is allowed. Press any key to exit or wait 10
seconds to automatically exit viewing mode.

FUNCTION KEY LABELS

A set of adhesive-backed labels with some typical function
symbols (i.e., fire, police, personal emergency, etc.) is
provided. These labels can be placed on or next to the keys
to identify each key's function for the end user (as
determined by the control
programming; see the control's instructions).
REFER TO INSTALLATION INSTRUCTIONS FOR THE CONTROL PANEL WITH WHICH THIS DEVICE IS USED
FOR WARRANTY INFORMATION AND LIMITATIONS OF THE ENTIRE ALARM SYSTEM.
ÊK14030V1sŠ
K14030V1 9/10 Rev. A
panel's capability and
2 CORPORATE CENTER DRIVE, MELVILLE, NY 11747
www.firstalertprofessional.com
Copyright © 2009 Honeywell International Inc.

SPECIFICATIONS

Physical:
FA220KP: 6-1/8"W x 4-1/4"H x 1-1/8"D
(155.6mm x 108.0mm x 28.6mm)
FA270KP: 6-5/8"W x 4-7/8"H x 1-1/8"D
(168.3mm x 123.9mm x 28.6mm)
FA570KP: 7-3/4"W x 5-3/8"H x 1-5/16"D
(197mm x 136.5mm x 28.6mm)

WIRING TABLE

Keypad
▲ G
Data Out
- GND
+ +12VDC
▼ Y
Data In
Displays:
FA220KP, Fixed-Word LCD
FA270KP: Fixed-Word LCD (backlit).
FA570KP: 2 x 16 alpha-numeric supertwist LCD, backlit.
Sounder:
FA220KP: Piezo-electric (fire alarm is loud, pulsing single
tone; (all Keypads) burglary alarm is loud,
continuous, dual tone).
FA270KP, Speaker
FA570KP: Speaker
Voltage: 12VDC
Current:
FA220KP: 55mA sounder on, 30mA standby, alarm
sounder off.
FA270KP: 100mA (ARMED LED lit, LCD backlight and
sounder on), reduces to 40mA when panel is
operating in standby mode (backlight off).
FA570KP: 150mA (ARMED LED lit, LCD backlight and
sounder on), reduces to 40mA when panel is
operating in standby mode (backlight off).
Control Panel Color
Data In Green
- Aux Power Black
+ Aux Power Red
Data Out Yellow
