User Actions
Garden Lighting
0Hr 00Min 00Sec
Mode: Timed On
Cancel OK=Start
or
or
Set Mode
Controlling the User Action.
When the desired User Action is selected (i.e.
Highlighted in the list), press:
- <ON> to turn it On.
- <OFF> to turn it Off.
- <OK> to toggle the state.
- <Back> FUNCTION key or <END> to return
to the default display.
- <Timed> FUNCTION key to enter a User
Action "On time".
If "Timed" is selected, use the <LEFT> and/or
<RIGHT> ARROW keys to position the cursor
on the time digit you wish to edit, then use the
SCROLL WHEEL or the ALPHA-NUMERIC
keys to enter the required value.
A period of up to 4 Hours may be entered.
Periods are accurate to +/- 1 second.
The <Set Mode> FUNCTION key can be used to
choose the timer mode. Options will vary
depending on the type of entity being controlled.
When the timer period is entered, and mode
selected, press <OK> to start the timed action, or
<Cancel>.
The display will then return to the User Action
list. The icon and text will be updated to indicate
the new Entity state.
