Summary of Contents for Minox BL10x44HD
- Page 1 Instruction manual BL 8x33 HD BL 8 x 44 HD · BL 10x44 HD BL 8 x 52 HD · BL 10x52 HD BL 8x 56 HD...
-
Page 2: Operating Parts
Introduction Operating parts With these binoculars from MINOX you have chosen a pro- 1. Eyepieces with adjustable eyecups duct of highest optical quality and mechanical precision. 2. Diopter compensation The MINOX BL-HD binoculars were developed, engineered 3. Central drive and assembled in Germany, giving them the "Made in 4. - Page 3 Adjustments Ideal for people wearing glasses To ensure that people wearing glasses also have an optimal field of view MINOX binoculars are fitted with rotating eyecups. For use without wearing glasses Those who do not wear glasses must turn the eyecups at both eyepieces in counterclockwise direction until they engage in the extended position.
- Page 4 (c) Your MINOX binoculars are now set to the individual vision of both eyes. (d) For the observation of different objects at varying distances you will always have to adjust the focusing.
- Page 5 We therefore recommend always removing fingerprints, dust and other forms of soiling on the surfaces of the lens and eyepieces using a soft hair brush or the special MINOX Lens-Cleaner (Order number. 99605). On the left eyepiece you will find the factory number. It is important that you make a note of this number for the event of loss.
-
Page 6: Technical Data
Technical data BL 8x33 HD BL 8x44 HD BL 10x44 HD Magnification 10 x Front lens diameter 1.30 in. / 33 mm 1.73 in. / 44 mm 1.73 in. / 44 mm Exit pupil 0.16 in. / 4.1 mm 0.22 in. / 5.5 mm 0.17 in. - Page 7 BL 8x52 HD BL 10x52 HD BL 8x56 HD 10 x 2.04 in. / 52 mm 2.04 in. / 52 mm 2.2 in. / 56 mm 0.26 in. / 6.5 mm 0.20 in. / 5.2 mm 0.28 in. / 7 mm 342 ft at 1,000 yds / 6.5°...
