Summary of Contents for HIMS SenseView LIGHT
-
Page 2: Table Of Contents
Table of Contents 1. What is the SenseView LIGHT? ....4 2. Safety precaution ........... 5 3. Package ............6 4. Configuration ..........7 5. After purchasing ..........9 (1) Charging ..........9 (2) Remove screen protection film ....9 6. - Page 3 (6) Changing the brightness of the illumination . 16 (7) Additional features ........16 ① Power saving mode ......16 ② Checking the battery status ....17 ③ Sound on/off ........18 7. Troubleshooting ........... 19 8. Technical Specifications ....... 22 9.
-
Page 4: What Is The Senseview Light
User manual – SenseView LIGHT 1. What is the SenseView LIGHT? The SenseView LIGHT is compact size so you can carry in your pocket and use whenever you want. To read books or newspapers for a long time, unfold legs at the bottom. If you unfold one leg, it is inclined so you can read in comfortable position without bending your neck. -
Page 5: Safety Precaution
Do not touch power plug with wet hands to prevent electronic shock. Only the supplied adapter by HIMS should be used. Other power adapter may damage the unit. Do not use this unit in moisture environment like a bathroom or shower room to prevent any damage. -
Page 6: Package
User manual – SenseView LIGHT 3. Package (1) SenseView LIGHT (2) AC adapter (3) Carrying case (4) Strap (5) User manual... -
Page 7: Configuration
User manual – SenseView LIGHT 4. Configuration (4) (5) (6) (1) Power switch (2) AC Jack (connect to a power adapter) (3) Battery charging indicator (4) Zoom button (5) Screen brightness button (6) Color mode button (7) Screen (8) Strap hole... - Page 8 User manual – SenseView LIGHT (10) (11) (12) (13) (9) Illumination brightness button (10) Still image button (11) Camera (12) Legs (13) Illumination...
-
Page 9: After Purchasing
User manual – SenseView LIGHT 5. After purchasing (1) Charging Battery must be fully charged approximately for 3 hours prior to initial use. To charge the battery, plug the supplied AC adapter into the AC adapter jack on the bottom of the device. -
Page 10: How To Use
User manual – SenseView LIGHT 6. How to use (1) Starting the SenseView LIGHT ① Power on/off The power switch is located at the center of the bottom panel. To turn on, slide the power switch to the right. -
Page 11: ② Location Of The Camera
User manual – SenseView LIGHT ② Location of the camera The camera is in the center of the back side of the unit. Place the camera on the center of the object you want to magnify. (2) Zoom ① Changing the magnification rate... - Page 12 User manual – SenseView LIGHT ※ Without unfolding the legs, you can’t get an accurate image. ※ When you fold up one leg, you can use the unit without difficulty but text will be titled slightly.
-
Page 13: ③ Semi-Distance
User manual – SenseView LIGHT ③ Semi-distance You can use the SenseView LIGHT as a regular optical magnifier by lifting 20mm~45mm from the object. The image on the screen gets larger as the distance from object shortens. magnification rate is from 1.5X to 10.5X. -
Page 14: Changing Color
User manual – SenseView LIGHT ※ Magnification rate There are 4 magnification levels. The rates are different, depending on the distance from the object. Distance from object Zoom level 4.5cm Level 1 3.5X 1.5X Level 2 5.25X 2.25X Level 3 Level 4 10.5X... -
Page 15: Changing Brightness On The Screen
The Still image button is at the center of the rare panel. Briefly press the button and the image the SenseView LIGHT is showing at that instant will remain on the screen. Press the button again to return to the normal... -
Page 16: Changing The Brightness Of The Illumination
User manual – SenseView LIGHT (6) Changing the brightness of the illumination You can adjust the brightness of the illumination. Change the brightness, depending on the circumstance and for your convenience. The Illumination brightness button is at the right side. -
Page 17: ② Checking The Battery Status
User manual – SenseView LIGHT In the Power saving mode, the display screen turns off and the battery charging indicator flickers. To exit "Power saving mode", simply touch any button or move the unit. If the unit is left a further 3 minutes after entering the power saving mode, power is automatically switched off. -
Page 18: ③ Sound On/Off
User manual – SenseView LIGHT the indicator will appear accompanied by an audio beep. The battery status is displayed with 5 levels: Full, High, medium, Low and Very low. The icon, Empty battery status, will flicker when the battery status is needs to be charged. -
Page 19: Troubleshooting
User manual – SenseView LIGHT 7. Troubleshooting (1) It does not turn on. Connect the adapter to AC jack over 3 hours before using. (2) The power is on, but I can’t get an accurate image. In the Capturing an image mode, it may seem to be defective. - Page 20 User manual – SenseView LIGHT (5) I want to turn on/off the sound. When you press each button, you can hear a sound to confirm your button stroke. To turn on/off the sound, press the Illumination brightness button and the Color mode button simultaneously.
- Page 21 User manual – SenseView LIGHT When the battery runs out, the power will be turned off. Connect the adapter into AC jack over 3 hours before using (9) The battery has been charged for a long time, but it doesn’t last long.
-
Page 22: Technical Specifications
User manual – SenseView LIGHT 8. Technical Specifications (1) Screen: 3.4 inch wide type AMOLED (2) Magnification rate: 1.5X~10.5X (3) Semi-distance: 2cm~4.5cm (4) Screen brightness: 4 levels (5) Color modes: 5 color modes (6) Battery : Rechargeable lithium polymer (2000mAh, 3.7V) ①... - Page 23 User manual – SenseView LIGHT NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-vide reasonable protection against harmful interference in a residential installation.
