HIMS SenseView User Manual

Hide thumbs Also See for SenseView:

Advertisement

Quick Links

Download this manual See also: User Manual
SenseView
User Manual
HIMS Co., Ltd.
TEL: +82-42-864-4460
FAX: +82-42-864-4462
E-mail: hims@himsintl.com
http://www.himsintl.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the SenseView and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HIMS SenseView

Summary of Contents for HIMS SenseView

  • Page 1 SenseView User Manual HIMS Co., Ltd. TEL: +82-42-864-4460 FAX: +82-42-864-4462 E-mail: hims@himsintl.com http://www.himsintl.com...
  • Page 2 User Manual NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-vide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not in-stalled and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 3 User Manual ■ The SenseView Package (supplied accessories) AC adaptor Cable for TV Cable for PC connection User manual If your package does not include all the listed items above, please contact your retailer or HIMS Co., Ltd - 2 -...
  • Page 4 User Manual ■ Overview SenseView is the most modern and innovative video magnifying system designed specifically for people with low vision. It has been designed many exciting features such as durability, a rotary magnification dial, change the magnification size incrementally and ergonomically placed...
  • Page 5 Continuous auto focus provides instant readability and vividness. 3) 21 Color Modes SenseView designed with the low vision user in mind, it provides full color, monochrome, high contrast positive and high contrast negative. There are 21 user selectable foreground / background color mode display.
  • Page 6 User Manual ■ SenseView Overview - 5 -...
  • Page 7 User Manual ■ Quick Start Guide 1) Installing the SenseView (1) Place the SenseView on the table and facing the control panel forward. (2) Connect the AC adaptor (supplied) with DC IN (at the back side). (3) Connect the monitor (or TV) with the SenseVeiw, using VGA cable (supplied).
  • Page 8 User Manual SenseView users does not want to use the PC, just conncet with the the monitor. ① Connecting the monitor : Connect the VGA cable (the monitor has the VGA cable) between the SenseView and the Monitor. ② Connecting the PC: Connect the PC with the SenseView, using the PC connection cable (supplied).
  • Page 9 ② Connecting the SenseView with the S-VIDEO jack: Connect the TV cable (the user prepared) between the SenseView (at the rear panel of the SenseView, the black round jack) and the TV (at the rear panel of the TV, the stainless steel round jack).

  • Page 10: Zoom In/Zoom Out

    User Manual 3) ZOOM IN/ZOOM OUT Turn left and right the ZOOM DIAL, you can adjust ZOON IN/OUT. ① ZOOM IN : Turn the ZOOM DIAL Right ② ZOOM OUT: Turn the ZOOM DIAL Left 4) Selecting Color Modes Press the blue arrow buttons. 21 color modes will be displayed on the Screen.
  • Page 11 User Manual Mode 21 to 1: Press the left arrow button. If you turn off the SeseView, the last mode will be saved. The color modes are shown on the following table. Normal High Contrast Negative Back Back Back Text Text Text ground...
  • Page 12 ① FOCUS LOCK: Press the blue diamond button. ② Release FOCUS LOCK (Auto Focus Lock): Press the blue diamond button again. The SenseView power is off, the Focus Lock will be released. It turns to the Auto Focus Lock. 6) Line Marker and Window Marker Line/Window maker will guide you in reading materials.
  • Page 13 When you read books, materials and any objects, the Line/Window markers will help you to read rows or columns. The SenseView is turned off, the markers will be released. You have to set the markers up again when you turn the SenseView on.
  • Page 14 It will guide you in reading materials. Press the button again, the laser beam will disappear. 8) Setting the Beep Sound and Voice When you turn the SenseView on, it will have no sound but the SensView provides speech output feature by pressing ‘the FOCUS LOCK’ button and ‘the POINTER’ button simultaneously.
  • Page 15 If you turn off and on the power again, it will turn to no sound mode automatically. 9) Setting Date and Time When you turn the SenseView on/off, Date/Time will not be displayed. If you want to check Date/Time, you can set up as follows; - 14 -...
  • Page 16 User Manual ① Checking Date and Time Press and hold ‘FOCUS LOCK’ button, and the press ‘MARKER’ button and then release both buttons simultaneously. Date and Time will be displayed on the top of the left corner of the screen. If you press and hold ‘FOCUS LOCK’...
  • Page 17 While the Line/Window markers on; if you set TIME/DATE, the Line/Window markers will be cancelled automatically. You turn the SenseView off while the date and time is displayed, the date and time will not be displayed if you turn it on again.
  • Page 18 11) CCTV/PC Switching You can display objects that on the table of the SenseView and the PC on the monitor or TV. Please check the connecting among the SenseView, the monitor (or TV) and the PC.

  • Page 19: Specifications

    User Manual ③ You press ‘CCTV/PC’ button, PC screen will be displayed on the monitor again. ④ You press ‘CCTV/PC’ button again, the SenseView screen will be displayed again. ■ Specifications Magification 3x~70x(17" monitor) Table moving range 300mm(x-axis) * 270mm(y-axis)
  • Page 20 User Manual - 19 -...
