Deka unigy I Installation

STATIONARY BATTERY INSTALLATION
AND OPERATING INSTRUCTIONS
HIGH
VOLTAGE...
RISK OF SHOCK.
DO NOT TOUCH
UNINSULATED
TERMINALS OR
CONNECTORS.
DO NOT REMOVE VENT VALVE.
WARRANTY VOID IF VENT VALVE IS REMOVED.
SEE INSTALLATION, MAINTENANCE AND OPERATION
INSTRUCTIONS FOR IMPORTANT SAFETY PRECAUTIONS.
Batteries, battery posts, terminals and related accessories
California
contain lead and lead compounds, and other chemicals known
Proposition 65
to the state of California to cause cancer and birth defects or
Warning
other reproductive harm. Wash hands after handling.
SAFETY PRECAUTIONS
Although all valve-regulated batteries have the elec-
trolyte immobilized within the cell, the electrical hazard
associated with batteries still exists. Work performed on
these batteries should be done with the tools and the
protective equipment listed below. Valve-regulated
battery installations should be supervised by personnel
familiar with batteries and battery safety precautions.
Protective Equipment
To assure safe battery handling, installation and
maintenance, the following protection equipment
should be used:
1. Safety glasses or face shield
2. Acid-resistant gloves
3. Protective aprons and safety shoes
4. Proper lifting devices
5. Properly insulated tools
Procedures
The following safety procedures should be followed
during installation: (Always wear safety glasses or
face shield.)
1. These batteries are sealed and contain no free elec-
trolyte. Under normal operating conditions, they do not
present any acid danger. However, if the battery jar or
cover is damaged, acid could be present. Sulfuric acid
is harmful to the skin and eyes. Flush affected area
with water immediately and consult a physician if
splashed in the eyes.
2. Prohibit smoking and open flames, and avoid arcing in
the immediate vicinity of the battery.
3. Do not wear metallic objects, such as jewelry, while
working on batteries.
4. Keep the top of the battery dry and clear of all tools and
other foreign objects.
5. Provide adequate ventilation (per IEEE standard 1187 and
/or local codes) and follow recommended charging voltages.
DANGER
!
SULFURIC
NO.
SHIELD EYES
ACID
• SPARKS
EXPLOSIVE GASES
CAN CAUSE
• FLAMES
CAN CAUSE BLINDNESS BLINDNESS OR
OR INJURY. • SMOKING SEVERE BURNS.
VENTILATE WELL WHEN IN AN ENCLOSED
SPACE AND WHEN CHARGING.
REPAIR SHOULD BE PERFORMED ONLY
.BY A QUALIFIED SERVICE TECHNICIAN.
®
FLUSH EYES
IMMEDIATELY
WITH WATER.
GET
MEDICAL
HELP
FAST.
SAFETY PRECAUTIONS
Procedures
(con't)
6. Extinguishing media: Class ABC extinguisher. Note:
CO may be used but not directly on the cells due
2
to thermal shock and potential cracking of cases.
7. Never remove or tamper with pressure relief valves.
Warranty void if vent valve is removed.
8. Inspect all flooring and lifting equipment for functional
adequacy.
9. Adequately secure battery modules, racks, or cabinets
to the floor.
10. Connect support structure to ground system in accor-
dance with applicable codes.
RECEIVING AND STORAGE
Receiving Inspection
Upon receipt, and at the time of actual unloading, each
package should be visually inspected for any possible
damage or electrolyte leakage. If either is evident, a
more detailed inspection of the entire shipment should
be conducted and noted on the bill of lading. Record
receipt date, inspection data and notify carrier of any
damage.
Unpacking
1. Always wear eye protection.
2. Check all batteries for visible defects such as cracked
containers, loose terminal posts, or other unrepairable
problems. Batteries with these defects must be replaced.
3. Check the contents of the package against the packag-
ing list. Report any missing parts or shipping damage
to your East Penn agent or East Penn Mfg. Co.
immediately.
4. Never lift batteries by the terminal posts.
5. Always lift batteries by the bottom or use the lifting handles.
®
BATTERIES
AND OTHER RELATED PARTS
CONTAIN LEAD
WARNING:
Battery posts, terminals and related accessories
contain lead and lead compounds, chemicals
known to the State of California to cause
cancer and reproductive harm.
Batteries also contain other chemicals known
to the State of California to cause cancer.
WASH HANDS AFTER HANDLING!
Form No: 1314 Rev. 8/08 Must be posted in workplace near batteries.
(con't)
