Français
1. Emplacement des pieces
1. Poignée
2. Bouton d'allumage
3. Câble d'accélérateur
4. Levier d'accélération
5. Manette des gaz
6. Garde-lame
7. Lame
8. Roues
9. Pare-étincelles du silencieux
10. Poignée de démarrage
11. Réservoir de carburant
12. Pompe d'amorçage
13. Levier de starter
14. Capot du filtre à air
2. Fiche technique
■ HEZ2401S
Dimensions totales (L x L x H) ································································································· 1845 x 240 x 325 mm
Poids à sec sans acc. ······································································································································6,75 kg
Moteur Type ········································································································· 2 temps à essence refroidi par air
Modèle································································································································ Zenoah GZ23N8
Cylindrée ··········································································································································23,6 cm
Puissance maximale··················································································· 1,15 CV (0,858kW) à 8000 t/mn
Vitesse de ralenti··················································································································· 3000±200 t/mn
Carburant ····································································································· Mélange (essence 50 : huile 1)
Carburateur················································································································· Walbro à diaphragme
Bougie d'allumage ··········································································································· CHAMPION RZ7C
Contenance du réservoir de carburant ············································································································· 0,63
Transmission ················· Embrayage centrifuge, arbre de transmission rigide, engrenage conique (angle : 90 deg.)
Rapport de réduction ····························································································································· 2,538 (33,13)
Sens de rotation de la tête de coupe············································ Sens des aiguilles d'une montre (Vue de la lame)
Période de durabilité ································································································································· 300 heures
Longueur de lame ···········································································································································200 mm
Utiliser pour ··············································································································Couper les bordures de pelouse
Standard Accessories
Lunettes de sécurité ······························································································································ 1 pc.
Trousse à outils ····································································································································· 1 pc.
2. Especificaciohes
■ HEZ2401S
Tamaño global (Long x Anch x Alt) ·························································································· 1845 x 240 x 325 mm
Peso en seco sin acc. ····································································································································· 6,75 kg
Motor
Tipo ························································································· Refrigerado por aire / gasolina de 2 tiempos
Modelo ······························································································································· Zenoah GZ23N8
Desplazamiento······························································································································· 23,6 cm
Potencia máxima ························································································ 1,15 Hp (0,858kW) a 8000 rpm
Velocidad de marcha en vacío ······························································································ 3000±200 rpm
Combustible ······························································································· Mezcla (Gasolina 50: Aceite 1)
Carburador ··············································································································· Walbro tipo Diafragma
Bujía ······································································································································· NGK CMR7H
Capacidad del depósito de combustible ··········································································································· 0,63
Transmisión ······································ Embrague centrífugo, eje propulsor rígido, cambios bisel (Ángulo:90 grados)
Relación de reducción ··························································································································· 2,538 (33,13)
Dirección de rotación de cabeza cortador ··········· Sentido de las agujas del reloj (Vista mirando hacia las cuchillas)
Período de duración ···········································································································································300 h
Largo del cuchilla ············································································································································200 mm
Utilizar para ···································································································································Recorte de césped
Standard Accessories
Gafas protectoras ·································································································································· 1 pc.
Caja de herramientas ···························································································································· 1 pc.
Español
1. Situación de las piezas
1. Mango
2. Interruptor de encendido
3. Cable del acelerador
4. Palanca del acelerador
5. Botón de acelerador
6. Protector de la cuchilla
7. Cuchilla
8. Rueda
9. Parachispas
10. Arrancador
11. Tanque de combustible
12. Cebador
13. Palanca del estrangulador
14. Cubierta del filtro de aire
(Lors de l'utilisation de la véritable huile ZENOAH)
Ces spécifications peuvent être modifiées sans préavis.
(al utilizar el aceite auténtico de ZENOAH)
Especificaciones sujetas a cambios sin previo aviso.
Français
3
Español
3
