RedMax HE250F Owner's/Operator's Manual page 47

Fig.1 DRIVE UNIT HE250F (S/N 70200101 and up)
Key# Part Number
1 848-A4A-5820 PIPE COMP.
2 T3207-12200 SHAFT COMP.
3 T3207-13000 GEARCASE ASSY
4 T3207-13110 • GEARCASE
5 6129-13250 • HOLDER-B
6 6129-13240 • HOLDER-A
7 6129-13211 • SHAFT
8 T3207-13310 • PINION
9 6129-13220 • GEAR
10 06004-06201 • BEARING
11 6129-13120 • BEARING
12 04065-03212 • SNAPRING
13 06001-00609 • BEARING
14 06000-00609 • BEARING
15 04065-02412 • SNAPRING
16 T3300-13330 • SNAPRING FOR ø9 SHAFT
17 T3002-13260 • NUT
18 3199-13350 • FITTING, GREASE
19 01641-20608 • WASHER, FITTING
20 T3207-13260 • BOLT
21 01252-30510 • BOLT
22 848-J80-32H2 GRIP
23 848-8R2-0344 LEVER COMP.
24 848-8R2-0314 • LEVER (FLEX. LEVER)
25 848-8RA-0340 • • COVER, LEVER
26 T3002-12220 • CORD(A) BLACK
27 T3002-12230 • CORD(B) RED
28 T3002-12240 TUBE
29 T3002-83100 CABLE COMP.
30 848-A4A-90R0 NAME PLATE
32 T3195-14002 HANDLE ASSY
33 T3195-14102 • HANDLE COMP.
34 T4960-53030 • SCREW
35 T3207-24000 GUARD ASSY
36 848-A47-66A1 • GUARD
37 T3207-24130 • BOLT
38 T3207-24150 • PLATE
39 T3207-24210 • PLATE, PROTECTOR
40 0280-10504 • NUT
41 848-A47-66P0 • WHEEL
42 T3207-25170 • BOLT
43 01602-20825 • WASHER, SPRING
44 01642-20810 • WASHER, PLANE
45 01540-50840 • WING NUT
46 T3207-25160 • SLEEVE
Description Q'ty Key# Part Number
1 47 T3207-24310 • BRACKET
1 48 T3207-24320 • PLATE, RUBBER
1 49 T3207-24330 • RUBBER
1 50 01252-30510 • BOLT
1
1 55 6367-15110 BLADE
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
4
1
1
5
1
1
2
1
1
1
2
1
1
Description Q'ty
1
1
1
2
1
47
