FlashLogic FLRSHA6 Install Manual page 6

MODULE
A
RF PORT/WEBLINK PORT
G
F TELEMATIC PORT
B
E
C
D
A
MS2 MS2
2 1
4 3
6 5
B
2 1
4 3
6 5
8 7
MS1 MS1
10 9
12 11
14 13
16 15
18 17
20 19
C
01 BROWN/BLACK - PARKING LIGHT (-) OUTPUT
02 GRAY (NC)
03 EMPTY
2 1 04 EMPTY
4 3 05 EMPTY
6 5 06 PURPLE/GREEN (NC)
8 7 07 EMPTY
10 9 08 BLUE/GREEN (NC)
12 11 09 EMPTY
10 EMPTY
11 GRAY/GREEN - HORN (-) OUTPUT
12 DKGREEN/GREEN (NC)
D
2 1
4 3
04 GRAY/WHITE - HOOD STATUS (-) INPUT
6 5
8 7
10 9
U.S. Patent No. 8,856,780
Automotive Data Solutions Inc. © 2016
RELAY
WITHOUT OEM HOOD SWITCH:
INSTALL AND CONNECT TO
AFTERMARKET HOOD SWITCH
AFTERMARKET HOOD SWITCH (-)
TYPE 1 - WIRING DIAGRAM - 1 OF 1
VS2 VS2
VS1 VS1
VS4 VS4
VS3 VS3
OPTIONAL
FLC-HA(RS)-HA6P-[FLRSHA6]-EN
SMART PCU (SEE WIRE CHART FOR LOCATION)
28 PIN PTS CONNECTOR
28 PIN PTS HARNESS
24 PIN IGNITION CONNECTOR
24 PIN IGNITION HARNESS
PARKING LIGHT SWITCH (LEFT OF STEERING WHEEL)
PARKING LIGHT (-) - 08
HORN (-)
PAGE 6 OF 18
• 20160302
DOC.: #27448
1 2 3 4 5 6
7 8 9 10 11 12
