FlashLogic FLRSHA6 Install Manual page 4

RF KIT (accessories sold separately)
FLRF1/2/4 RF KIT
MODULE
RF PORT
TELEMATIC KIT (accessories sold separately)
FLHRNTM
MODULE
TELEMATIC PORT
TELEMATIC KIT (accessories sold separately)
FLHRNTM
MODULE
TELEMATIC PORT
U.S. Patent No. 8,856,780
Automotive Data Solutions Inc. © 2016
COMPATIBLE ACCESSORIES - 1 OF 1
(NC)
(NC)
PN 4120260
(NC)
FLC-HA(RS)-HA6P-[FLRSHA6]-EN
ANTENNA
CARLINK
CAR CONNECTION
VEHICLE
OBDII PORT
PAGE 4 OF 18
• 20160302
DOC.: #27448
OBDII CONNECTOR
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
