UL 864 9th edition requirements

NOTICE TO USERS, INSTALLERS, AUTHORITIES HAVING JURISDICTION, AND OTHER
INVOLVED PARTIES
This product incorporates field-programmable software. In order for the product to comply with
the requirements in the Standard for Control Units and Accessories for Fire Alarm Systems, UL
864, certain programming features or options must be limited to specific values or not used at all
as indicated below.
Programmable feature or
option
Enable Supervision
(telephone line is supervised
for ground faults, a single
open line, or a wire-to-wire
fault)
DACT Settings - Line 2
Installed (single line or dual
line dialer)
Trouble Resound (panel
resound)
AC Power Delay
Event message routing
Event message display
filtering: Alarm, Supervisory,
and Trouble options
Delays (programmed in rules) Y
CMS event reporting priority
(programmed in rules)
CMS activate and restore
messages (programmed in
rules)
4-state alarm IDC
EST3 Installation and Service Manual
Permitted Possible settings
in UL 864?
(Y/N)
Y No
Yes
Y No
Yes
Y Disabled (0)
1 second to ~99 hours
Y Disabled
1 minute to 45 hours
Y All Cabinets
No Cabinets
User defined routes (1
to 15)
Y Enabled
Disabled
0 to 240 seconds
Y 1 to 255
Y Send on activation
Send on restoration
N N/A
Settings permitted in
UL 864
Yes
Yes
Disabled [2]
0 to 24 hours
1 to 3 hours
All Cabinets
No Cabinets [3]
User defined routes (1 to
15) [4]
Enabled
Disabled [5]
0 to 240 seconds [6]
1 to 255 [7]
Activation and
restoration triggers must
match the message type
In Signature module
configuation, personality
code 18 is prohibited
[11]
