Table 8-20: Local trouble pseudo points
Address Label
0689 Smoke Power Current Limit
Card 2
0690 Configuration Mismatch Slot 1
Table 8-21: Local monitor pseudo points
Address Label
0615 Incoming Ring
0622 Outgoing Call in Progress
0650 All Call Active
0651 Mic Key Active
0673 Mapping In Progress Data
Card 1
0674 Mapping Disbld Data Card 1
0675 Device Maint Alert
0675 Device Maint Alert Data Card
1
0678 Reconstct Line Data Card 1
0683 Mapping In Progress Data
Card 2
0684 Mapping Disbld Data Card 2
0685 Device Maint Alert Data Card
2
EST3 Installation and Service Manual
Source Description
3-DSDC Defective module
3-SSDC1
3-SDDC1
3-DSDC N/A
3-SSDC1
3-SDDC1
Source Description
3-MODCOM An incoming call was received by the
module.
Dialer is active
3-ASU Changes to the active state when an
operator presses the All Call switch
3-ASU Changes to the active state when an
operator presses the push-to-talk
switch on the paging microphone.
3-DSDC N/A
3-SSDC1
3-SDDC1
3-DSDC Mapping manually disabled
3-SSDC1
3-SDDC1
3-AADC1 N/A
3-DSDC Dirty detector on loop 1
3-SSDC1
3-SDDC1
3-DSDC N/A
3-SSDC1
3-SDDC1
3-DSDC N/A
3-SSDC1
3-SDDC1
3-DSDC Mapping manually disabled
3-SSDC1
3-SDDC1
3-DSDC Dirty detector on loop 2
3-SSDC1
3-SDDC1
Service and troubleshooting
8.31
