jablotron DAVID GD-04 User Manual

Table 1 – A brief list of programming SMS instructions
Any programming SMS message must start with a valid access code (see 6.3).
Example: PC, ARX, heating on, DRX, heating off
Instruction
Function
Relays X and Y operation
ARX, xxx..x
SMS to switch relay ON
DRX, xxx..x
SMS to switch relay OFF
TMX, t..t
Relay switch-on period
ADX, x..x,x..x
Telephone numbers
authorised for relay control
LDX, x..x,n,
Telephone numbers
x..x,n
authorised for relay control
with a validity limit.
EDX, x..x, x..x
Erasing tel. numbers
authorised for relay control
Input A to D activation/deactivation SMS reports
ATA, xx..x
Input activation text
DTA, xx..x
Input deactivation text
TNA, x..x, x..x
Telephone numbers for input
reports
DNA, n
Input-event calls
GD-04 DAVID
Description
xxx..x = text (up to 30
Use ARY for relay Y.
characters), text erased by ARX, ,
Example: ARY,ventilator on
xxx..x = text (up to 30
Use DRY for relay Y.
characters), text erased by DRX, ,
Example: DRY,ventilator off
Use TMY for relay Y.
t..t = switch-on period in seconds, or zero
• 1 to 10h entered in seconds, minutes(m) or
hours(h) ( 3600s = 60m = 1h)
• The relay works as a time-switch, activated via
switch-on SMSes or dialling-in. Deactivation is by
time-limit expiration or via switch-off SMSes.
• 0: no time-limit applies, dialling-in is responded to
with toggle logic: on – off – on...
Use ADY for relay Y.
x..x = tel. number. Up to 50 numbers can be entered
(in a single instruction or gradually). The numbers
are added to the list of authorised numbers.
Example: ADX, 777123456, +420608503211
authorises two new numbers for relay X control.
Use LDY for relay Y.
x..x = tel. number. The numbers are added to the list
of authorised numbers, up to 50 in total.
n = limit in the number of calls (1 to 99), exceeding
the limit removes the number from the list – this is
reported to the service number by SMS.
Example: LDX, 777123457, 31 authorises a new
number for relay X control for a maximum of 31 calls.
Use EDY for relay Y. x..x = tel. number. The
numbers (up to 50) are removed from the list.
Example: EDX, 777123457 de-authorises a
single tel. number used for relay X control.
Use ATB for input B, etc.
xxx..x = text (up to 30 characters*)
Example: ATC, heating on
Instruction ATA , , erases the text = no reports
Use DTB for input B, etc.
xxx..x = text (up to 30 characters*)
Example: DTC, heating off
Instruction DTA , , erases the text = no reports
Use TNB for input B, etc.
x..x = tel. number, up to 8 for each input. All
previously stored numbers are erased. Use TNA,
to empty the list.
Example: TND, 777123456, 608123456 sets
David to report input D events to 2 numbers
, n = 1 (ON), 0 (OFF). If
Use TNB for input B, etc.
set to ON, every SMS report is followed by a call.
If you answer the call, you hear a constant tone =
activation, or an interrupted tone = deactivation.
Example: DND, 1
12 MKS51203
The GD-04 "David" GSM communicator
Factory
The GD-04 module got its name from David, a biblical king who outsmarted Goliath, a giant. In our
default
case, Goliath is meant to be the GSM network. We hope that the skills of your tiny David will help you
manage the giant.
erased

1. Basic description

erased
0
(no limit)
Tabs
empty
list
–
A1,
B1,
C1,
D1
A0,
B0,
C0,
D0
empty
list
1.1. David provides:
OFF
2 output contacts of power relays X and Y (each allows up to 5A/250V)
•
4 input terminals A to D for SMS reporting (the inputs react to a connection or disconnection
•
to or from a common GND terminal)
GD-04 DAVID
User manual

GSM antenna

SIM card

RESET jumper
Bus connector

LED indicator

Battery connection

Output fuses
1 MKS51203
