CLP SERIES BLUETOOTH TWO-WAY
RADIO QUICK REFERENCE GUIDE
PAIRING YOUR MOTOROLA CLP BLUETOOTH TWO-WAY RADIO WITH
Power/Battery
Button
Volume
Control (+/-)
Add Bluetooth Headset (Initial Pairing)
1. Turn the radio OFF.
2. Put Bluetooth headset in pairing mode. Refer to your Bluetooth headset instructions leaflet.
3. Press and hold the PTT button and power button simultaneously until radio shows the blue LED.
Reconnect to last connected Bluetooth Headset
1. Turn the radio OFF.
2. Press the power button to turn the radio ON. (Make sure the Bluetooth headset is turned ON).
Erase Bluetooth Headset history and add Bluetooth Headset
1. Turn the radio OFF.
2. Put the Bluetooth headset in pairing mode. Refer to your Bluetooth headset Instructions leaflet.
3. Press and hold the MENU button and power button simultaneously until radio shows the blue LED.
Note: (*) The CLP radio uses proximity pairing. Make sure the headset is close enough to the CLP radio.
Pairing process takes about 14 seconds.
LED Configuration
User Mode
LED Status
Bluetooth
Last connection – Fast blinking blue
Pairing Mode
Add or erase/add – Solid blue
Pairing
Blue/purple blinks for 5 seconds
Successfully
Bluetooth
Red/purple blinks until the radio
Disconnected
reconnects
Pairing Fail/
Red/purple blinks until radio
Timeout
reconnects
BLUETOOTH HEADSET
Accessory Audio
Connector
Color
M
MENU Button
Smart Status
Glow
Push-to-Talk
(PTT) Button
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and
the Stylized M logo are trademarks or registered
trademarks of Motorola Trademark Holdings, LLC and
are used under license. All other trademarks are the
property of their respective owners.
© 2010, 2011 Motorola Solutions, Inc.
All rights reserved.
Printed in Malaysia.
*68012001073*
68012001073-B
