CONTROLS

1. MAIN SWITCH
2. START SWITCH
Press the key , the indicator lamp(1)
will light, The machine starts heating
and the machine is only for sealing .in
any situation, press the key to make
lamp go out, you can stop the
machine
3. SHRINK SWITCH
If indicator lamp(2)lights,(this can
be gotten by pressing the key).the
machine can seal and shrink film. This
key has the function of maintaining
working mode under any conditions
4.
Though this key, seal temperature,
seal time, cooling time and magnet
closed time can be adjusted
○
S CHOOSING KEY
The lamp(3),or (4), or (5), or (6)will light in
orange when you press the key every
time
VALUE INCREASING KEY
VALUE DECREASING KEY
NOTE: the above two keys works
When digital readout flashes.
SETTING KEY
5. DIGITAL READOUT
It shows the value of the every time
setting.
6 HEATING INDICATOR
When the machine temperature does
not reach the setting temperature, the
lamp(3)will light in red ,The lamp will
light in green till the machine
temperature reach the setting
temperature which indicate you can
start to operate the machine
7 SEALING INDICATOR
The lamp (4)light in green while the
machine is operated
8 COOLING INDICATOR
The lamp(5)will light in green while the
film is cooled after cutting
9 SHRINKING INDICATOR
The lamp(6)will light in green while the
machine is shrinking.
