EXTENDGROUP EKH-455 Operation & Maintenance Manual page 23

PARTS LIST,FIGURE 6-4 ELECTRICAL UNIT
KEY Q'TY
11 1
15 8
16 1
17 1
20 8
21 2
101 4
102 4
103 8
104 15
105 1
106 4
107 14
109 1
111 8
112 8
113 0.71m
114 16
115 8
116 4
117 1
118 1
119 1
120 0.1m
124 1
1
2
125 4
128 1
129 1
130 1
PART NO. DESCRIPTION
7-06000-111 Electrical fixed board
7-06000-150 Connector nut
PC-FP-70SB02 Show PC board .FP-70SB02
PC-FP-70B02 Control PC board asse.FP-70B02
4-10200-130 Bush
3-14000-170 Clip
201A05 Hex nut, M5
202B05 Lock washer, M5
202A0512 Plain washer, M5*12
202A0409 Plain washer, M4*9
113H060006 Rectifier KBPC2510 6A/600V
200A05012 Socket head cap screw, M5*12
200E04008 Phillips head machine screw, M4*8
200E04016 Phillips head machine screw, M4*16
200F03016 Flat head cap screw, M3*16
200E03006 Phillips head machine screw, M3*6
153F2525 Wire track 25*25mm
201A03 Hex nut, M3
202B03 Lock washer, M3
200F04016 Flat head cap screw, M4*16
103B2348600 Transformer, 230V-48V
103B2330050 Transformer, 230V-30V
104C001 Main power switch, GN20 H-06-40U06,15A/600VAC
153FC45 Wire track C45
115B3815 Fuse, 15A-38mm 220V
115B3812 Fuse, 12A-38mm 220V
115B3816 Fuse, 16A-38mm 220V
115N-RT1832 Fuse seat,RT18-32
200E04035 Phillips head machine screw, M4*35
201A04 Hex nut, M4
101W12-5060450 Motor capacitance CBB61,12uF/450V,50/60Hz
20
FPH-204-066
