EXTENDGROUP EKH-455 Operation & Maintenance Manual page 21

PARTS LIST,FIGURE 5-8:SEALING BAR,TORSION SPRING,CABINET UNIT
KEY Q'TY
1 1
2 1
3 1
13 1
14 1
14.1 1
15 1
16 1
17 1
18 1
20 1
21 1
22 2
23 1
23.1 1
24 2
25 1
26 5
27 2
28 4
29 1
30 1
31 1
32 2
33 1
34 2
35 1
36 1
37 1
38 1
40 1
41 2
42 1
43 1
101 4
102 9
103 7
106 4
107 13
108 4
109 2
110 2
111 1
112 1
113 10
114 10
116 13
120 1
121 1
122 2
125 2
126 1
127 8
128 22
PART NO.
7-05101
7-05102
7-05104
7-05000-132
7-05000-140
7-05000-141
7-02000-152
7-02000-160
7-05800-170
7-05800-180
7-05000-200
7-05000-210
7-05000-220
7-05000-230
7-05000-231
7-05000-240
7-05000-250
7-02000-250
7-02000-190
7-02000-170
7-02000-141
YL-02A505004
7-02000-182
7-05000-321
7-05000-331
7-05000-340
7-05000-350
7-05000-360
7-05000-370
7-05000-380
7-05000-401
7-05300-410
7-05100-420
7-05800-430
201G05
200H04008
200H04008
201F12
200F04012
202A1224
200G08015
200A05025
201A08-1
200A08045B
200A06016
202A0612
200F03012
200R05016
200G03012
2211008022
200F03008
201A03
200E04008
200L04015
18
DESCRIPTION
SEALING UNIT
TORSION SPRING UNIT
CABINET UNIT
Sponge strip
Heating row(long)565mm
Heating row(short)515mm
Body
Bottom plate
Heating row fastener I
Heating row fastener II
Bronze joint
Joint seat
Limit block ABS
Plastic cover
Plastic cover
Heating thread clamping pilehead
Heating thread
Plastic plug
Film holder guide
Feet
Front frame
Liner
Lable
Torsion spring supporting cover
Torsion spring block
Torsion spring seat
Torsion spring adjuster
Rubber
Limit block
Tube
Torsion spring
Holder guide support
Heat insulation plate
Aluminum seat
Hex nut, M5
Truss head machine screw, M4*8
Truss head machine screw, M4*8
Thin nut M12
Flat head cap screw, M4*12
Plain washer, M12*24
Socket head set screw, M8*15
Socket head cap screw, M5*25
Hex nut, M8
Socket head cap screw, M8*45
Socket head cap screw, M6*16
Plain washer, M6*12
Flat head cap screw, M3*12
Star-type handle M5*16
Socket head sets screw M3*12
Press spring
Flat head cap screw, M3*8
Hex nut, M3
Phillips head machine screw, M4*8
Screw M4*15
FPH-204-058
