  • Page 1 GTVL19WDVD 19” LCD Television with DVD Player User Guide...

  • Page 2: Introduction

    GTVL19WDVD Introduction Thank you for purchasing this 19” LCD Television which has been designed and manufactured to give you many years of trouble-free service. You may already be familiar with using a similar product but please take time to read these instructions which have been written to ensure you get the very best from your purchase.

  • Page 3: Table Of Contents

    Contents Introduction .................... 2 Safety is Important ................. 2 Contents ....................3 Safety Information .................. 5 Electrical Information ................6 Wiring Instructions ..................6 Location of the Controls ................ 7 Front and Right Side Controls ..............7 Rear View and Connectors ..............8 Remote Control ..................9 Getting Started ..................
  • Page 4 Basics ....................... 42 JPEG Picture CD Playback ..............42 DVD Setup Menus ................45 Basics ....................... 45 General Setup Page .................46 Audio Setup Menus ..................48 Video Setup Page ..................48 Preferences Page ..................49 Password Setup Page ................50 Exit Setup ....................50 Using the Card Readers and USB Connection ........

  • Page 5: Safety Information

    19" LCD Television Safety Information WARNING! Ensure that you read all of the safety instructions before using your LCD TV. Power Source • The LCD TV uses a power supply adapter that requires a 230V AC, 50Hz mains supply. Do not use any other supply. Do not use any other power supply adapter than the one supplied with your TV.

  • Page 6: Electrical Information

    GTVL19WDVD Electrical Information This appliance is fitted with a BS1363/A 13 amp plug. If it is not suitable for your supply sockets it must be removed and replaced with an appropriate plug. If the plug becomes damaged and/or needs to be replaced please follow the wiring instructions below.

  • Page 7: Location Of The Controls

    19" LCD Television Location of the Controls Front and Right Side Controls Power Indicator Signal Source Remote Control Menu Sensor Channel Up Channel Down Volume Up Volume Down Play Stop Eject Power On/Off DVD/CD Slot Headphones SD/MS/MMC Memory Card USB Socket...

  • Page 8: Rear View And Connectors

    GTVL19WDVD Rear View and Connectors Connectors behind cover Cover removed Video Component Composite Video Audio Left Video Inputs Outputs Audio right Component Left Left Composite Audio Audio Inputs Right Right Inputs Composite Video Input S-Video Input Scart Aerial (RF IN)
  • Page 11 19" LCD Television The SCART connection will give the best video quality as it uses separate signals for the video RGB components. The RCA video connection carries the video components on a single composite signal. S-video is a compromise between component analogue video and the composite video.

  • Page 12: Installing The Remote Control Batteries

    GTVL19WDVD Installing The Remote Control Batteries Turn the remote control over, push the catch on the battery compartment door and lift it free. Insert the two AAA batteries following the polarity markings inside the battery compartment as shown below. We recommend the use of Ever Ready Energizer batteries.

  • Page 13: Selecting The Input Signal

    19" LCD Television Selecting the Input Signal In addition to receiving TV signals your LCD TV can also be used as a monitor for a number of other devices. The various input signals are selected using the SOURCE button on either the LCD TV or the remote control.

  • Page 14: Tuning The Tv Channels

    GTVL19WDVD Tuning the TV Channels 1. Press the DISPLAY button on the remote control and check that the LCD TV is showing the TV input. 2. If it is not, repeatedly press the SOURCE button until TV is displayed in the top left corner of the screen.

  • Page 15: Channel Naming

    19" LCD Television 6. Press the button to highlight ‘Auto Scan’ and press ENTER. The scan for channels will commence. The progress of the scan will be shown on a slide bar with the number of channels found as shown opposite. When the scan is complete the LCD TV will revert to the first channel found.

  • Page 16: Re-Organizing Channels

    GTVL19WDVD 5. Use the buttons to select the first character of the name. 6. Press to move the second character position and then the buttons to select the second character of the name. 7. Repeat steps 5 and 6 until the name is complete then press ENTER.

  • Page 17: Skipping Channels

    19" LCD Television Skipping Channels If the auto scan found channels that you do not intend to use they can be skipped so that they do not appear when using the CH+, CH- buttons. 1. Select the channel you wish to skip. 2.

  • Page 18: Fine Tuning

    GTVL19WDVD 2. Press the button to highlight ‘Manual Install’ and press ENTER. The Manual Install menu will be displayed with ‘Search’ highlighted as shown below. NOTE: The Colour System will default to PAL which is the system used in the UK. If you have selected a different country in the tuning process (see page 14) the system may default to one of the alternatives, NTSC or SECAM.

  • Page 19: Colour System

    19" LCD Television 2. Open the ‘PAL Europe Tuner’ menu as described previously. 3. Press the button to highlight ‘Manual Install’ and press ENTER. The Manual Install menu will be displayed with ‘Search’ highlighted. 4. Press the button twice to highlight ‘Fine Tune’ and use the buttons to adjust the tuning.

  • Page 20: Basic Operation

    GTVL19WDVD Basic Operation Selecting the TV source Press the TV button or repeatedly press the SOURCE button until ‘TV’ is displayed in the top left corner of the screen. Selecting Channels Press either the CH and CH buttons or use the numeric buttons to enter the channel number directly.

  • Page 21: Picture Mode

    19" LCD Television Sound Mode Your TV has an equalizer that can be set to enhance certain frequency bands to match the type of sound output, e.g. music, speech etc. Repeatedly press the SOUND button to switch between the various preset modes as listed below.

  • Page 22: Display

    GTVL19WDVD Display You can view the current channel and audio settings by pressing the DISPLAY button. An information window will open in the top right of the picture as shown opposite. The information gives the input signal source, the audio setting, channel number and name.

  • Page 23: Teletext

    19" LCD Television Teletext Teletext is an information system that displays text on your LCD TV. Using the teletext control buttons you can view pages of information that are listed in the teletext index. NOTE: No on screen menu display is available in text mode, but the volume controls will still operate.

  • Page 24: Text Cancel

    GTVL19WDVD To remove the hold and continue the rotation of the subpages, press the button again. Text Size Press the button to enlarge the text shown on the Teletext screen. Only the upper half of the page is shown. Press the button again to view the lower half of the page.
  • Page 25 19" LCD Television The coloured buttons will now open the page numbers you have selected. 888 Subtitles Some television programmes are broadcast with subtitles for the hearing impaired. The subtitles are on teletext page 888. To view the subtitles enter the teletext mode and search for page 888. When the page is found the television will automatically revert to the programme and the subtitles appear at the bottom of the screen.

  • Page 26: Tv Setup Menus

    GTVL19WDVD TV Setup Menus General Navigation 1. Press the MENU button to initially open the menu system. 2. Use the buttons to highlight selections. 3. Press ENTER to open submenus. 4. The MENU button is also used to go back up through the menu structure.

  • Page 27: Picture Settings

    19" LCD Television 2. Use the buttons to highlight one of the preset options or the User setting and press ENTER. NOTE: If you change any of the picture attributes (brightness, contrast etc.) as described in the following sections, the picture mode is automatically set to the User option.

  • Page 28: Audio Menus

    GTVL19WDVD Advanced Settings The Advanced menu is only available when you are in the DVD or PC monitor mode. It will be greyed out, i.e. unavailable, in the other modes of operation. For PC monitor mode refer to “PC Monitor Setup menus”...

  • Page 29: Auto Volume

    19" LCD Television Bass, Treble and Balance Your TV has a number of preset sound settings and a User setting as described in “Sound Mode” on page 29. If you change the bass and treble settings as described in this section the sound mode will automatically change to User.

  • Page 30: Setup

    GTVL19WDVD 3. Press MENU to return to the Audio menu or EXIT to exit the menu system. Setup 1. Press MENU and the button to highlight ‘Setup’. 2. Press ENTER to display the Setup menu options as shown opposite. Tuner/Channel Menus These are described in “Tuning...
  • Page 31 19" LCD Television 2. To carry out the reset, use the buttons to highlight ‘Yes’ and press ENTER. 3. Press MENU to return to the Setup menu or EXIT to exit the menu system. SCART Mode Your TV can be set to either automatically switch to the SCART input when a signal is detected or to require the SCART input to be manually selected.

  • Page 32: Using The Dvd Player

    GTVL19WDVD Using the DVD Player Inserting a Disc 1. Press the DVD button on the remote control. The DVD logo will be displayed. 2. Insert the disc with the label facing towards the front of the TV as shown opposite.

  • Page 33: Dvd Player Functions

    19" LCD Television Region code If the region code of the disc being played does not match the region code of this DVD player then the disc cannot be played. If you do try to do this a region violation notice will appear on the screen. The region code for this player is region 2 (refer to the symbols opposite).
  • Page 34 GTVL19WDVD To stop play to remove the disc: Press the stop ( ) button twice. displays on the screen with the DVD logo page. Press the play ( ) button. Play will start from the beginning of the disc. Fast Forward/Reverse...

  • Page 35: Special Dvd Functions

    19" LCD Television button at any time. The play symbol is briefly displayed on the TV screen. Special DVD Functions Menu To return to the main menu of the DVD disc while the DVD is playing, press the MENU button, .
  • Page 36 GTVL19WDVD The audio language selected is heard shortly after selection. The selected audio language overrides the audio language setting in the Preference Setup menu. See the DVD disc cover for a list of commentaries/audio language tracks. Angle The angle function is not supported on all DVD discs.
  • Page 37 19" LCD Television the disc by selecting the Title number and Chapter number or an elapsed time. 1. Press the GOTO button. The on screen display shown opposite will be displayed. The menu will show the current playback status. The title and chapter numbers show the current setting and the total on the disc, so in the example above there are three titles and 26 chapters on the disc.
  • Page 38 GTVL19WDVD 12.Use the numeric buttons to enter the required elapsed time. The DVD will jump to the specified time. 13.Press the down button to highlight ‘Ch Time’. This option enables you to jump to a specified elapsed time for the current Chapter. The total time of the chapter will be displayed in h:mm:ss.

  • Page 39: Playing Audio Cds

    19" LCD Television Playing Audio CDs Insert an audio CD into the DVD player as described previously with the label towards the front of the TV. Play will automatically start at the first track. The track number, total number of tracks and elapsed time will be displayed.
  • Page 40 GTVL19WDVD Skip to the Next/Previous Track To skip to the next Track during play, press the skip forward button, ). Play skips to the next track each time this button is pressed. To skip to the beginning of the current track, press the skip backwards button ( ) once.
  • Page 41 19" LCD Television If you require a track number greater than 9, press the +10 button, ( then the second digit, e.g. for track 13 press +10 then 3. The track number you enter is limited to the total number of tracks on the CD.

  • Page 42: Playing Picture Cds

    GTVL19WDVD Playing Picture CDs Basics The photos on a photo CD will be displayed in the form of a slide show, i.e. each photo is displayed for approximately 5 seconds. Switch the DVD player on and load a Kodak picture CD or a JPEG picture CD label side towards the front as described previously for.
  • Page 43 19" LCD Television Pausing the Slide Show Press the pause, ( ) button to pause the slide show. will be displayed on the TV screen. Press the play ( ) button to resume the slide show from the paused position. will be briefly displayed when play restarts.

  • Page 44: Rotating The Image

    GTVL19WDVD 3. Press the REPEAT repeatedly until the mode you require is displayed. 4. Press the play button ( ). 5. Press either the stop button ( ) or the MENU button to stop the slideshow. Rotating the Image When the image is displayed use the...

  • Page 45: Dvd Setup Menus

    19" LCD Television DVD Setup Menus Basics Various features of the DVD player can be adjusted in the Setup menus. The DVD setup menu structure is shown below. Press SET UP General Audio Video Password Exit Preference Setup Setup Setup Setup Setup Page...

  • Page 46: General Setup Page

    GTVL19WDVD 1. Ensure that the there is no disc in the DVD player. 2. Press the SET UP button. The general setup menu will be displayed as shown opposite. 3. Scroll through the Setup page symbols using the buttons until the required page is displayed.

  • Page 47: Screen Saver

    19" LCD Television • Wide: This is an aspect ratio of 16:9. With some DVDs you may not see the left and right edges of the picture and you may observe black borders to the above and below the picture. •...

  • Page 48: Audio Setup Menus

    GTVL19WDVD Audio Setup Menus Dolby Digital Setup Dual Mono: Hdcd Hdcd The Dolby Digital can be set • Stereo - stereo output • L-Mono - left channel only • R-Mono - right channel only • Mix-Mono - mono sound from both channels The default is Stereo.

  • Page 49: Preferences Page

    19" LCD Television • Brightness: This can be set to between + and - 20. The default is 0. • Contrast: Can be set to between + and - 16. The default is 0. Preferences Page Audio Language Some DVD discs contain audio commentaries and the audio track in different languages.

  • Page 50: Password Setup Page

    GTVL19WDVD Default This feature will reset the DVDs setup configuration to its factory default settings. It does not, however, reset the parental control or the password. Password Setup Page Password Mode You can turn the password control On or Off. The default is On.

  • Page 51: Using The Card Readers And Usb Connection

    19" LCD Television Using the Card Readers and USB Connection Your TV can read SD, MS and MMC memory cards. You can also connect USB memory devices using the USB connection. 1. Switch the TV to the DVD mode by pressing the DVD button. 2.

  • Page 52: Using Your Tv As A Pc Monitor

    GTVL19WDVD Using Your TV as a PC Monitor With your PC and the TV switched off, use a VGA cable to connect the PC monitor output to the TV, see “Rear View and Connectors” on page 8. The audio output from your PC can also be connected through the TV, however, you will need a separate cable from the PC’s audio output to...

  • Page 53: Image Position

    19" LCD Television 1. Press MENU, ENTER and button to display the Advanced Image menu as shown opposite. 2. The ‘Auto Adjust’ option will be highlighted. Press ENTER and the TV will automatically adjust the resolution and picture controls to the most suitable settings.
  • Page 54 GTVL19WDVD 3. Press MENU to return to the Advanced menu or EXIT to exit the menu system. Automatic Colour Adjustment The red (R), green (G) and blue (B) content of the display can be adjusted automatically. 1. In the Advanced menu press the button four times to highlight ‘Auto Colour’...

  • Page 55: Connecting External Equipment

    19" LCD Television Connecting External Equipment Refer also to the user guide of the external equipment for connection information. Input Signals The TV has a SCART connector, a set of RCA AV input sockets and an S-Video connection. All of these can be used to connect a DVD recorder, VCR, games console or satellite/cable decoder.

  • Page 56: Troubleshooting

    GTVL19WDVD Troubleshooting General Problem Possible Cause The TV does not Make sure that the power supply is connected and that work. the mains supply is switched on. If the green LED on the power supply adapter is not on check the fuse in the mains plug.

  • Page 58: Care And Maintenance

    GTVL19WDVD Care and Maintenance Care of the Screen • Clean the screen with a slightly damp, soft cloth. • Do not use abrasive solvents or cleaners as they may damage the TV screen coating layer. • Always unplug the TV from the mains while cleaning.

  • Page 59: How Do I Dispose Of This Product

    19" LCD Television How Do I Dispose of this Product? When your TV has reached the end of its life, contact your local council regarding available recycling or disposal options. Do not dispose of electrical products in the general waste. Please ensure that used batteries are disposed of safely.

  • Page 60: Technical Specification

    GTVL19WDVD Technical Specification Power Supply Adapter Input: 100 to 240 V AC 50/60 Hz Output: 12 V DC 5 A maximum Power Consumption: <60 W Fuse Rating: Remote Control Batteries:2 x AAA (supplied) Screen TFT-LCD Resolution: 1440 x 900 TFT-LCD Screen Size: 19”...

  • Page 61: Guarantee

    19" LCD Television Guarantee This product is guaranteed for 12 months from the date of original purchase. If any defect arises due to faulty materials or workmanship, the unit will either be replaced, a refund given or repaired free of charge (where possible) during this period by the dealer from whom you purchased the unit.
