- Page 1 Robotic Cleaner Troubleshooting Guide Copyright 2010 Hayward Industries Inc.
- Page 2 Table of Contents TigerShark & TigerShark QC Important safety instructions Page 1 Service Tools Page 2 Filter Removal/Cleaning and Drain Flaps Pages 4-6 Handle Removal Page 7 Venturi Removal Page 8 Bottom Lid Disassembly Pages 9-10 Side Cover Removal Pages 11-12...
- Page 3 Table of Contents Continued SharkVAC & E-Vac Service Tools Page Power Supply Page Filter Removal Pages 46-47 Filter Replacement Page Wheel and Tire Removal Page Side Cover Removal Page Drive Track and Idlers Page Main Drive Pulley Removal Page Wheel Tube Removal Page Wheel Tube Brush Page...
- Page 4 Safety Page 1...
- Page 5 Service Tools Pin Removal Tool Torque Driver Torx Bit Spanner Tool Torx Driver Scanner Page 2...
- Page 6 Power Supply On/Off Switch - Lighted Quick Clean LED (QC Models Only) Power Cord Full Cycle Button and LED (QC Models Only) Flotation Power Cord Connector Page 3...
- Page 7 Disassembly – Filter Removal Remove bottom lid by sliding Bottom lid removed providing LH and RH latch towards center. access to filter cartridge assembly Page 4...
- Page 8 Filter Removal Note the drain flaps, one per side. Not required to remove for filter cleaning, but visually inspect when filter is removed. Filter cartridge removed Page 5...
- Page 9 Filter Removal Note: Elements must be installed with support ribs facing outward Filter cartridge assembly Filter elements removed Note: Elements can be cleaned by gently spraying with a garden hose. Spring cleanup filter Be careful not to use high elements. For temporary use pressure or this may damage in heavy spring cleaning.
- Page 10 Handle Removal Handle removal Handle removed 1 screw each end Note: Handle is watertight. If water is heard sloshing around in handle it must be replaced. Page 7...
- Page 11 Venturi Removal Rotate CCW & lift out Removed, access to impeller Page 8...
- Page 12 Bottom Lid Disassembly Bottom lid assembly. Pull up Inlet cover removed to remove inlet cover. Page 9...
- Page 13 Bottom Lid Disassembly Inlet flaps, check for Inlet flaps removed free movement. for inspection. Page 10...
- Page 14 Side Cover Removal Motor output shaft. Motor assembly Power cord Power cord end Drive end. Note: Use Torx bit and power driver for removal. Bottom view with bottom lid 7 screws each end to remove and filter assembly removed. for side plate removal, drive side. Power cord end, 7 screws.
- Page 15 Side Cover Removal Screw removal Note that ‘drive side’ or motor output side is side opposite Side cover removed of where power cord enters unit. Page 12...
- Page 16 Drive Track & Idler Pulley Removal Drive Side Drive track removed Track idler pulley (2/side) Check for missing/broken drive Bearings should rotate smoothly cogs on inner loop of belt and also and freely. for cracks in belt. Note that flange faces inward. Page 13...
- Page 17 Main Drive Pulley Removal Note drive ‘key’ in pulley and how it mates to the output shaft drive pin of the motor. Main drive pulley, motor output side only Page 14...
- Page 18 Wheel Tube Removal Carefully pull wheel tube Both drive tubes removed. away from other side plate. Roller will slide off track. Page 15...
- Page 19 Drive Track & Idler Pulley Removal Non-drive Side Track idler pulleys, (3). Note this side does not have a keyed drive pulley at the center pulley since it is opposite the motor drive end. This pulley is simply an idler pulley similar to the ones to the left and right.
- Page 20 Power Cord & Motor Box Removal Remove strain relief Plate removed showing cover plate. strain relief system. Page 17...
- Page 21 Power Cord & Motor Box Removal Use spanner wrench and Threaded plug removed Torque driver to remove threaded plug securing power cord into motor assembly. CCW removal. Page 18...
- Page 22 Power Cord & Motor Box Removal Gently pull on cord to Note that plug has taper on bottom side disconnect and remove from motor. to mate with rubber seal taper. Note: Any time seal is removed it is recommended to replace special rubber seal.
- Page 23 Power Cord & Motor Box Removal While holding connector firmly, depress Carefully insert pin removal tool button on pin removal tool to remove into power cord connector. Push electrical connector pin from housing. wires up into connector as far as possible. Page 20...
- Page 24 Power Cord & Motor Box Removal Power cord electrical pins Connector, seals and removed from connector. Note that white washers removed. wire goes on tab side of connector. Page 21...
- Page 25 Power Cord & Motor Box Removal Connector must be installed with tab on Note the order of the seals and washers. connector placed in mating hole of motor Remember to mate the taper of the seal assembly. The white wire must be inserted and threaded plug.
- Page 26 Power Cord & Motor Box Removal Gently route power Power cord removed. cord out from unit. Page 23...
- Page 27 Power Cord & Motor Box Removal Location of motor screws when side cover is not removed. It is possible to remove motor assembly without removal of side cover. However, the 7 side cover screws must be loosened on the motor drive side.
- Page 28 Power Cord & Motor Box Removal When removing motor assembly without complete removal of side cover, gently separate motor output shaft from keyed drive gear using a screwdriver. The drive gear will remain in place. Be sure to remove all 4 motor securing screws, 2 each side and loosen side cover screws before attempting this.
- Page 29 Power Cord & Motor Box Removal Rotate motor slightly to remove drive output shaft from side of unit, then lift out motor assembly. Page 26...
- Page 30 Power Cord & Motor Box Removal Output shaft key on motor, mates with drive gear. Motor assembly removed. Note: The motor assembly is a sealed unit and cannot be serviced, only replaced. It does not contain oil and is water cooled. The impeller can be replaced.
- Page 31 Wheel Tube Bearings Remove wheel tube from machine Remove 2 small phillips screws securing roller bearing to tube Bearings should rotate smoothly and freely. Bearing assembly will slip off tube Page 28...
- Page 32 Wheel Tube Brush Brush replacement can be done leaving the machine assembled or broken down. Unsnap the tabs, these run length wise of the brush. Page 29...
- Page 33 Wheel Tube Brush Start in the center of the brush and put the post through the hole in the tab with the aid of a pair of needle nose pliers. Pull post slightly till taught then push down on tab until it locks into post.
- Page 34 Using The Scanner Tool Power switch on Scanner female end Initializing…………. Please wait Startup Screen Scanner Setup Scanner male end Power cord to cleaner Page 31...
- Page 35 Using The Scanner Tool Motor ON Time Power ON Time Hours Hours The combined total number of hours the Number of hours the unit has spent unit has spent with the power switch on. in the 4 hour cleaning cycle mode. Includes both hours accumulated in ‘Motor On Time’...
- Page 36 Using The Scanner Tool Out of Water Causes 1. Attempting to run the unit out of the water/pool. Out of Water 2. Air trapped in the filter after placing the unit in the water. Times 3. Bench testing in manufacture or repair. 4.
- Page 37 Using The Scanner Tool Drive Over Current Causes Drive Overcurrent 1. Unit caught under a ladder Times 2. Debris caught in traction drive belt and or pulleys under side cover. 3. Riding or standing on unit during operation. 4. Defective wheel tube bearings or side cover idler bearings 5.
- Page 38 Testing Power Supply & Flotation Cord Communication Failure Causes 1. Damaged power supply, check for 21-25 volts DC 2. Water inside power connection to motor box, check seal at motor box and for breaks in flotation hose Check Power and Communication 3.
- Page 39 Troubleshooting Startup • Machine will sequence between pump and drive motor for up to 1 minute. • During this time the microprocessor is sampling motors for proper electrical load. Mapping Sequence • At about 2 minutes the machine will begin mapping the immediate section of the pool. •...
- Page 40 Shutdown • The machine will shut down after 4 hours for the standard TigerShark. • TigerShark QC will shutdown after 90 minutes if the Quick Clean LED is illuminated, or after 4 hours if “Full Cycle” is selected. • The power supply will continue to supply low voltage to the unit and the diagnostic memory will continue to record hours until the power switch is turned off.
- Page 41 Resume use of TigerShark for pool maintenance as often as required. • Increase frequency of TigerShark filter cleaning, especially during the initial use. Filter may have to be cleaned 30 minutes to 3 hours in the first few cycles until the pool is in an acceptable condition.
- Page 42 Troubleshooting Will not climb walls Pool design or configuration Pool design or configuration • The pool bottom corner design may be too sharp. Some pool designs feature a sharp, 90 degree bottom corner. A guideline for the best machine performance is a corner radius similar in contour to a basketball.
- Page 43 Troubleshooting Will not climb walls Confusion on normal operation Confusion on normal operation • The startup of each 4 hour cycle may require up to 30 minutes as the machine measures the pool configuration before climbing the walls completely to the water line.
- Page 44 Troubleshooting Runs only a few seconds or minutes • Make sure the machine is submerged in the water. An out of water detection within a few minutes will cause the machine to stop if not completely submerged. • Check electrical source for proper voltage. •...
- Page 45 Troubleshooting No movement but impeller turns • Drive motor pin or drive motor is broken possible due to overload during use. To avoid repeat failure, follow-up with the customer for obstructions in the pool such as a ladder. The Scanner will display a Drive Over Current signal if the machine has been caught on an obstruction.
- Page 46 Troubleshooting Debris falls from unit when removed from pool • Filter overload, increase frequency of filter cleaning. • Large debris blocking intake. Remove large debris from pool before using machine. • Drain flaps out of place on bottom lid. Snap flaps back into place. Avoid dropping or throwing machine into the pool.
- Page 47 Service Tools Power Driver (not supplied) Pin Removal Torx Drivers Tool T-10 & T-25 (not supplied) Torx Bit T-20 (not supplied) Spanner Tool Belt Installation Tool Torque Driver Page 44...
- Page 48 Power Supply On/Off Switch - Lighted Installation and Care Instructions Power Cord Flotation Power Cord Connector Page 45...
- Page 49 Filter Removal Press Dome Button Lift to remove Filter Bucket to lift Dome for filter removal. Housing Filter cartridge removed Filter Bucket Housing Page 46...
- Page 50 Filter Removal Open filter doors by pushing the tabs Lift filter cartridges out. toward the outside and then pulling up. Note: Elements can be cleaned by gently spraying Spring cleanup filter with a garden hose. Be careful not to use high elements.
-
Page 51: Filter Replacement
Filter Replacement Hold both cartridges toward center. Push down cover and press tab towards fan to lock cartridges in place. Make sure cover snaps in place. Page 48... - Page 52 Wheel and Tire Removal Remove wheel cap to access screw Unscrew T25 screw holding wheel on axel. Remove wheel from axel. Notice how wheel and axel mate. Page 49...
- Page 53 Side Cover Removal Power cord Motor assembly Impeller Motor output shaft. Drive end. 4 T20 screws each side to remove for side plate removal. Top view with bottom lid and filter assembly removed. Drive side view with cover removed. Page 50...
- Page 54 Drive Track & Idler Pulley Removal Drive Side Check for missing/broken drive Track idler pulleys cogs on inner loop of belt and also for cracks in belt. Bearings should rotate smoothly and freely. Note that flange faces inward. Page 51...
- Page 55 Main Drive Pulley Removal Note drive ‘key’ in pulley and how it mates to the output shaft drive pin of the motor. Main drive pulley, motor output side only Page 52...
- Page 56 Wheel Tube Removal Rear Tube Carefully pull wheel tube away from Unscrew T20 screws from each side of roller. wheel axels. Front Tube Page 53...
- Page 57 Wheel Tube Brush Removal Replacement Brush replacement can be done Start in the center of the brush and put leaving the machine assembled or the post through the hole in the tab broken down. Unsnap the tabs that run with the aid of a pair of needle nose length wise of the brush.
- Page 58 Power Cord Removal Remove strain relief cover plate. Plate removed showing strain relief system. Use spanner wrench and Torque Threaded plug removed driver to remove threaded plug. Page 55...
- Page 59 Power Cord Removal Gently pull on cord to disconnect and remove from motor. Note that plug has taper on bottom side to mate with rubber seal taper. Note: Any time seal is removed it is recommended to replace special rubber seal. Page 56...
- Page 60 Power Cord Removal Push wires up into connector as far While holding connector firmly, depress as possible. Carefully insert pin removal tool button on pin removal tool to remove into power cord connector. electrical connector pin from housing. Page 57...
- Page 61 Power Cord Removal Power cord electrical pins Connector, seals and washers removed. removed from connector. Note that white wire goes on tab side of connector. Page 58...
- Page 62 Power Cord Removal Note the order of the seals and washers. Remember to mate the taper of the seal and threaded plug. Connector must be installed with tab on connector placed in mating hole of motor assembly. The white wire must be inserted on the tab side of the connector.
- Page 63 Power Cord Removal Gently route power Power cord removed. cord out from unit. Page 60...
- Page 64 Motor Box Removal Remove 4 T20 screws securing motor to base. When removing motor assembly without complete removal of side cover, gently separate motor output shaft from keyed drive gear using a screwdriver. The drive gear will remain in place. Be sure to remove all 4 motor securing screws.
- Page 65 Motor Box Removal Rotate motor slightly to remove drive output shaft Output shaft key on motor, mates from side of unit, then lift out motor assembly. with drive gear. Note: The motor assembly is a sealed unit and cannot be serviced, only replaced. It does not Impeller removal contain oil and is water cooled.
- Page 66 Testing Power Supply & Flotation Cord Communication Failure Causes 1. Damaged power supply, check for 21-25 volts DC 2. Water inside power connection to motor box, check seal at motor box and for breaks in flotation hose 3. Damaged flotation cord, check for ohms reading of .4 to .8 ohms Flotation cord test.
- Page 67 Troubleshooting Startup • Machine will sequence between pump and drive motor for up to 1 minute. • During this time the microprocessor is sampling motors for proper electrical load. Mapping Sequence • At about 2 minutes the machine will begin mapping the immediate section of the pool. •...
- Page 68 Troubleshooting Navigation • The unit navigates itself primarily by running in a diagonal direction at the water line. • This is the key to complete pool coverage. Shutdown • The machine will shut down after 2 hours. • The power supply will continue to supply low voltage to the unit and the diagnostic memory will continue to record hours until the power switch is turned off.
- Page 69 Troubleshooting Runs only a few seconds or minutes • Make sure the machine is submerged in the water. An out of water detection within a few minutes will cause the machine to stop if not completely submerged. • Check electrical source for proper voltage. •...
- Page 70 Troubleshooting No movement but impeller turns • Drive motor pin or drive motor is broken possible due to overload during use. To avoid repeat failure, follow-up with the customer for obstructions in the pool such as a ladder. • Check for belt or roller obstruction •...
- Page 71 Troubleshooting Debris falls from unit when removed from pool • Filter overload, increase frequency of filter cleaning. • Large debris blocking intake. Remove large debris from pool before using machine. • Drain flaps out of place on bottom lid. Snap flaps back into place. Avoid dropping or throwing machine into the pool.
